Page 1: Table Of Contents
September, 2024 NA - R5II For Canon R5II Camera PN 17341 User Manual Housing FF- MIL Introduction Package Contents Important Instructions Part Names and Functions Housing Mount Opening the housing Closing the housing Preparation for Use Optional Accessories Care/Storage Warranty Specifications... -
Page 2: Introduction
PACKAGE CONTENTS Make sure that you have all the included items listed below before using this product. If some items are missing or damaged, contact your local Nauticam dealer. NA-R5II Padded Travel Case... -
Page 3: Important Instructions
O-ring renewal between the atmosphere and inside the and port change. housing. Only the accesories specified by Use only Nauticam lubricant on silicone Nauticam must be used. Third-party rubber O-ring. accessories may result in malfunctions or damage to the product. -
Page 4: Part Names And Functions
PART NAMES AND FUNCTIONS Rear View TTL Indicator window Viewfinder Menu button Rating/Voice memo button Housing unlock button Moisture alarm window AF point selection button AE lock button Multi selector Info button Set button Access lamp Fan ON/OFF button Delete button Menu/Set button... - Page 5 PART NAMES AND FUNCTIONS Top + Front Views M24 Accessory port Optical fiber cable connection M16 Accessory port Still photo / movie recording switch LCD/Viewfinder lever M10 Accessory port Main switch Mode dial M16 Accessory port Quick control dial 2 TTL flash on/off Accessory mounting ball Port lock safety button...
- Page 6 PART NAMES AND FUNCTIONS Back + Side Views 1/4” Threaded tripod holes Sacrificial zinc anodes Playback lever Zoom/Focus knob release Zoom/Focus knob Display lever Control ring mount adaptor Fn AF-ON lever M-Fn lever REC lever Shutter release lever Quick control dial 1 Main dial Quick control lever Preview lever...
-
Page 7: Housing Mount
HOUSING MOUNT Housing mount Compatible accessories 1/4” -20 mounting threads 17959 Housing Mounting ball with 1/4’’ screws M16 Accessory port 25625 M16 Vacuum Valve II (Optional) M10 Accessory port 25221 M10 Strobe mounting ball 25224 M10 Strobe mounting ball with hole M16 Accessory port 25017 M14 6 pin bulkhead for Canon system... -
Page 8: Opening The Housing
OPENING THE HOUSING * drawings as illustrations only depress housing unlock button turn housing lock outward lift up the back housing... -
Page 9: Closing The Housing
CLOSING THE HOUSING * drawings as illustrations only before closing the housing, clean and lubricate the main O-ring make sure nothing is caught between front and back housing and that they are fully aligned before locking turn housing lock inward until you hear and feel it click into place housing locked in place securely... -
Page 10: Preparation For Use
PREPARATION FOR USE * drawings as illustrations only Installing the Camera - housing tray attachment unlock camera tray lever and remove the tray from the housing attach the camera tray by tightening the tray screw into the tripod socket of the camera place the actuator on the camera tray in place and make sure it is engaged with the camera... - Page 11 PREPARATION FOR USE * drawings as illustrations only Installing the Camera - RF mount/ EF mount lens installment RF mount lens make sure the small lever is in vertical make sure the small gear engagement knob position before RF mount lens installment on housing tray is on the left EF mount lens (w/ mount adaptor EF-R)
- Page 12 PREPARATION FOR USE * drawings as illustrations only Installing the Camera - RF mount/ EF mount lens installment EF mount lens with Canon Drop-in filter mount adpator EF-EOS R with variable ND filters remove the original control kit from the replace it with 26320 control kit for Canon camera tray drop-in filter mount adaptor...
- Page 13 PREPARATION FOR USE * drawings as illustrations only Port Mounting depress safety button and rotate anti-clockwise lubricant the port O-ring before mounting align index mark push port assembly straight in rotate locking lever clockwise to lock Do not operate the red lever with force, make sure the port is aligned correctly and pushed in fully and securely...
- Page 14 PREPARATION FOR USE * drawings as illustrations only Coating housing O-ring Main O-ring remove the main O-ring using an O-ring remover clean the O-ring groove with a cloth and ensure that it is free from salt or other foreign materials lightly coat it with provided lubricant return the main O-ring by slowly pressing from one corner to the whole perimeter...
- Page 15 PREPARATION FOR USE * drawings as illustrations only Setting up moisture alarm CR2032 Battery Alarm ON/OFF remove battery press the battery down until it insulation film click into place switch on the alarm test the alarm - the moisture alarm - connect the wires with a window will flash in dampened cotton bud;...
- Page 16 PREPARATION FOR USE * drawings as illustrations only Changing lens/port without opening the housing If using with vacuum valve : remove the cap from the vacuum valve and press the red button to release pressure before unlocking port lock If using without vacuum valve, please follow from step 2 unlock port lock and remove port assembly...
-
Page 17: Optional Accessories
OPTIONAL ACCESSORIES * drawings as illustrations only Vacuum valve system remove the plug of M16 accessory port from the housing remove the cap from the vacuum valve hand pump slightly lubricate the o-ring and vacuum valve make sure the o-ring is in place accesory port then tighten the vacuum valve to on housing... - Page 18 OPTIONAL ACCESSORIES * drawings as illustrations only Installing cooling fan set install the cooling fan railing assembly onto the housing as shown unlock the locking lever then slide the cooling fan system into the tray rail lock the cooling fan assembly...
- Page 19 OPTIONAL ACCESSORIES * drawings as illustrations only Installing Apple AirTag remove the two screws and take out the Airtag holder cover place the AirTag into the holder close the holder cover...
- Page 20 OPTIONAL ACCESSORIES * drawings as illustrations only Installing Surface USB-PD Power Bank unscrew the M24 accessory port cap from the camera housing and screw the M24-M16 adaptor into M24-M16 Adaptor the housing port plug the USB-C Bulkhead into the accessory port, gently push the connection head into the accessory port until it cannot go further then tighten it by turning the locking nut...
- Page 21 OPTIONAL ACCESSORIES * drawings as illustrations only Strobe Mounting Ball Installing M5 Strobe Mounting Ball - RECOMMENDED M5 screw remove M5 screw with the allen key provided in the screw #25228 M5 Strobe mounting ball directing onto housing package the M5 thread * the anti-corrosion screw may also be Anti-corrosion unscrewed while removing M5 screw, if this...
- Page 22 OPTIONAL ACCESSORIES Installing Viewfinder firstly remove the pre-installed 0.66x viewfinder gently push the 0.66x viewfinder from the inside of from the housing by removing the retainer o-ring the housing inside rear housing remove the retainer o-ring from the viewfinder align the viewfinder alignment pins with the LCD lightly lubricate the retainer o-ring and place it back display window and push the viewfinder into the from inside the housing...
-
Page 23: Care/Storage
CARE/STORAGE Soak the housing system in fresh water Operate all controls and buttons at after salt water usage least 3 times while immersed in fresh water We recommand cleaning and inspecting Protect the housing with robust and the main O-ring each time after diving for shock-proof travel case during trans- any damage and every time the housing portation. -
Page 24: Warranty
NAUTICAM accepts no liability for any damage to and defects in the housing caused by improper use and/or poor maintenance; it is the responsibility of the own- er to carefully follow the instructions in our manuals. -
Page 25: Specifications
25413 27cm Lanyard with 2 Snap Hooks Display window Abrasion Resistant Polycarbonate Viewfinder Dimensions 32212 Nauticam Full Frame Straight Viewfinder 40°/ 0.8:1 32214 Nauticam Full Frame Angle Viewinder 40°/ 0.8:1 Width 357 mm 87213 Reverse Angled Viewfinder for EMWL 40°/ 0.8:1... - Page 26 WET LENS COMPATIBILITY *please refer to Nauticam port charts for more setup information Nauticam optical lenses Optional accessories Macro 81201 Super Macro Convertor 1 25101 M67 Flip Diopter Holder for M67 Macro ports 81202 Super Macro Convertor 2 25108 M67 Double Flip Holder for M67 Macro Ports Macro 86201 Macro to Wideangle Lens 1 (MWL-1, 150 deg.
- Page 27 Nauticam Internationl Ltd. Rm 2203, CCT Telecom Bldg, 11 Wo Shing St, Fo Tan, Hong Kong Tel. +852 - 26902711 Fax. +852 - 26909778 URL. www.nauticam.com Gallery. www.nauticam.smugmug.com...
