- Page 1 PX809 Uni-Flood User manual...
-
Page 2: Table Of Contents
7 RDM – available parameters..............16 8 Connection scheme..................18 9 Technical data....................19 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0... -
Page 3: Description
Description The PX809 lamp has been designed to illuminate stages and for use in TV studios. Uni-Flood has a built-in system for tuning the frequency of the control signal ("flicker free" technology), which prevents the flickering effect in TV cameras. It is controlled by the DMX signal. -
Page 4: Safety Conditions
Safety conditions The PX809 is a device powered directly from power grid 100 – 240V AC, what may result in electric shock in case of not following safety rules. During its installation and use the following rules must be strictly observed: 1. -
Page 5: Control Elements
Control elements display power supply input DMX input PowerCON TRUE1 5-pin XLR DMX output power supply output programming keyes 5-pin XLR PowerCON TRUE1 and knob Navigating the menu - allows to exit the parameter being programmed without saving any changes or to move to higher menu level (next) - scrolls the menu down or increases the values to be set (prev) -
Page 6: Programming The Device
Programming the device The device has two modes for changing parameters. Basic (in the absence of DMX signal – the so-called No Signal), allowing to change the brightness and color temperature of the light using the buttons (parameter selection) and knob (value change), and the advanced one, used to change other operating parameters such as: DMX address, smoothing, etc. -
Page 7: Basic Device Control Mode
5.1 Basic device control mode Basic mode that is responsible for the scene in the absence of DMX signal (so-called No Signal). First, the device is controlled by the DMX signal. In case of its disappearance or absence, the device is controlled by buttons and knob –... -
Page 8: Advanced Parameter Change Mode
5.2 Advanced parameter change mode 5.2.1 Description of information parameters Information parameters displayed on the device screen may be: current brightness, color temperature and DMX address, model, device operation time (PWR – total operation time, ACT – active operation time), version of the software installed in PX809 and serial number. -
Page 9: Dmx Address
5.2.2 DMX address In PX809 it is possible to change the address of both channels at the same time (2ch DW Basic operating mode) or separately for the channel controlling the brightness and color temperature of light (2ch DW Adv. operating mode). -
Page 10: Operating Mode
10.2% 2700K Smooth DMX Adr 1 OFF * Pressed Esc + Enter Px809 Smooth Stage lamp Level 1 * Enter Smooth Smooth Level 4 Level 4 * Smooth Level 5 * 5.2.4 Operating mode The selection of the operating mode is nothing more than deciding whether the DMX address is to be set "in groups"... -
Page 11: Temperature Limit
5.2.5 Temperature limit The module is factory fitted with a temperature sensor, in addition it is possible to connect an external NTC 4K7 thermistor. After exceeding +80°C the module will start to limit the output power. After exceeding +90°C it will start operating with a maximum power of 10%. The external sensor works very similarly to the sensor in the driver, but the power reduction is already at +75°C and is also linear to 10% at +90°C. - Page 12 In the device menu, it is possible to read the temperature in the PX809 and on the external sensor. Additionally, if the external sensor is not connected, the temperature has been exceeded or is short-circuited, an error is displayed – the temperature symbol °C flashes on the main 10.2% °C 2700K...
-
Page 13: Screen Saving
5.2.6 Screen saving The device has been equipped with the ability to turn off the screen backlight and diode. This is possible with the Screensaver option. Thanks to its use, the display and DMX diode are turned off after ~20 seconds (from the moment of not pressing the buttons / using the knob). -
Page 14: Setting The Display Contrast
PX809 default settings: No Signal: 25% / 2700K (basic control mode) • DMX Addr.: 001 • Smooth: Level 4 • Control Mode: 2ch DW Basic • • Screensaver: Enabled 5.2.8 Setting the display contrast If the device has a problem with the readability of messages displayed on the screen, it is possible to change its settings. -
Page 15: Menu Scheme In Px809
5.2.9 Menu scheme in PX809 DMX Addr. 10.2% 2700K DMX Adr 1 001 001 (2ch) ** Pressed Esc + Enter Pressed Esc Enter Enter Px809 DMX Addr. DMX Addr. DMX Addr. 001 002 (2ch) 001 002 (2ch) * 001 002 (2ch) ** Stage lamp Enter DMX Addr. -
Page 16: Dmx Signal Connection
DMX signal connection 1. The recommended cable for the connection is RS485 (two wires in a shield). 2. Devices must always be connected in series. 3. To split the DMX line, use the Splitter DMX (e.g. PX716). 4. For more devices (over 32) or long distances (more than 300 meters) use DMX Repeater (e.g. - Page 17 List of RDM parameters supported by the PX 809 : Parameter name Description SUPPORTED_PARAMETERS 0x0050 all supported parameters description of additional PARAMETER_DESCRIPTION 0x0051 parameters DEVICE_INFO 0x0060 information concerning the device SOFTWARE_VERSION_LABEL 0x00C0 firmware version of the device DMX_ADDRESS * 0x00F0 DMX starting address of the device device identification;...
-
Page 18: Connection Scheme
Parameter name Description setting channel 1 in the scene NOS_SCENE_1 * 0x8021 (color) setting channel 2 in the scene NOS_SCENE_2 * 0x8022 (brightness) SERIAL_NUMBER 0x8030 device serial number * - editable parameter Connection scheme DMX Controller... -
Page 19: Technical Data
Technical data type PX809 power supply 100 – 240V AC DMX channels RDM support brightness adjustment range 0.001 – 100% 2700K – 7179lm lamp brightness 50/50 – 7752lm 6500K – 7422lm color control range (DW) 2700 – 6500K control screen + buttons + knob / DMX / RDM power consumption max. - Page 20 Podłęże, 11.03.2025 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: Uni-Flood Product code: PX809 meets the requirements of the following standards, as well as harmonized standards: PN-EN IEC 63000:2019-01...
