  • Page 1 PX801-T PxArt+ 06 Mono Track PxArt+ 12 Mono Track PxArt+ 18 Mono Track User manual...
  • Page 2: Table Of Contents

    8 RDM – available parameters..............14 9 Connection scheme.................16 10 Dimensions.....................17 11 Technical data..................18 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0 BDO register number 000005972 www.pxm.pl...
  • Page 3: Description

    Description PX801-T is a professional LED illuminator designed for illumination of museum exhibitions or displays. Thanks to the application of the most modern semiconductor SSL LED light sources and advanced control electronics, a high class illuminator was created which meets very high requirements for museum and exhibition lighting.
  • Page 4: Safety Conditions

    Safety conditions Caution! Before installing, connecting and using the lamp you have to absolutely read this document. The following symbols are used to underline important information on security on the product and in this manual. Danger! Warning! Warning! Warning! Warning! Risk of loss of life Fire hazard LED light emission,...
  • Page 5 The PX801-T device is powered directly from 230V power grid. Failure to comply with the safety rules may result in electric shock and may endanger the user’s life. Therefore it is necessary to observe the following: 1. Installation should be performed by a person holding the appropriate qualifications, according to the instruction manual.
  • Page 6: Connectors And Control Elements

    Connectors and control elements Brightness adjustment PX277 parameter programming connector...
  • Page 7: Information On Version

    Information on version Below is a description of the PX 801-T model designations with their explanation PX801-T – AA – XX – YYY – Z AA – version: XX – beam angle: YYY – CRI and Z – housing 06 – 6 LEDs 10 –...
  • Page 8: Dmx Connection

    DMX connection PX801-T is a device attached to the GLOBAL Trac ® Pulse Control rail by using the GAC 600 adapter included in the kit. 5.1 GLOBAL Trac ® GAC 600 adapter DMX contacts DMX - (on the opposite side DMX +) MAINS POWER SUPPLY protective phase 1 (on the opposite...
  • Page 9: Control

    Control 6.1 Button The lamp has been equipped with button which allow for changing the brightness level. The button have been placed at the bottom part of the junction box, above the lamp reflector. Depending on a situation, the diode signals the following: •...
  • Page 10: Dmx Signal

    adjustment direction. The pressing of the adjustment button again will cause the dimming of the lamp (brightness decrease). While the lamp operates, the diode stays switched off (excluding situations mentioned above). 6.2 DMX signal The PX801-T lamp can be controlled via DMX channels: Channel 1 –...
  • Page 11: Cooperating With The Px277 Configurator

    Cooperating with the PX277 configurator Lamp settings can be changed by connecting the PX277 configurator (PxArt+ Settings Controller) to it. It allows in connection with PX801-T to define the following parameters: DMX addresses for brightness (in the range of 1 – 512) and device behavior in the absence of DMX signal (programmable scene).
  • Page 12 Module temp. – a list of the lowest, highest and current operating temperature of the module with LEDs, PWR time / ACT time – total lamp operation time / total lamp lighting time, Factory Default – factory reset in PX801-T: DMX Addr: 001 •...
  • Page 13: Scheme Of The Px801-T Menu In Px277

    7.2 Scheme of the PX801-T menu in PX277 PX801-06 PX801-12 PX801-18 PxArt+ 06 PxArt+ 12 PxArt+ 18 NEXT ENTER DMX Addr. DMX Addr. 001 (1ch) 001 (1ch) * NEXT NEXT DMX Addr. 512 (1ch) * ENTER No Signal No Signal Channel: 1 Off * Value: 0 *...
  • Page 14: Rdm - Available Parameters

    RDM – available parameters The PX801-T supports the DMX-RDM protocol. DMX protocol allows only of a one-way data transmission, while extension the RDM protocol can transmit information in two directions. This makes possibility of monitoring activities of the compatible devices. Thanks to RDM some available settings of compatible devices may be programmed using this protocol.
  • Page 15 Parameter name Description FACTORY_DEFAULTS 0x0090 device default settings PERSONALITY * 0x00E0 DMX operational mode PERSONALITY_ description of individual 0x00E1 DESCRIPTION operational modes information on the selected SENSOR_DEFINITION 0x0200 temperature sensor SENSOR_VALUE 0x0201 information about sensors SMOOTH_OFF/1/2/3/4 * 0x801A selection of smoothing options NO_SIGNAL_OFF/ON/HLD/S behavior of the device when the 0x801C...
  • Page 16: Connection Scheme

    Connection scheme 3-phase GLOBAL Trac® Pulse Control bus-bar end feed power supply cable DMX+ DMX- DMX wire (2 wires in screen) GLOBAL Trac® GAC600 adapter...
  • Page 17: Dimensions

    10 Dimensions PxArt+ 06 Mono Track PxArt+ 12 Mono Track Ø 92...
  • Page 18: Technical Data

    PxArt+ 18 Mono Track ø148 11 Technical data type PX801-T power supply 230V AC number of diodes 6 / 12 / 18 PX801-T-06: 10W power consumption PX801-T-12: 17,5W PX801-T-18: 25W max. temperature rise housing +30°C LEDs lifespan 50000h 10°, 20°, 30°, 40°, EL* (10 x 45°), WW** beam angle (50 x 110°) color temperature...
  • Page 19 range of brightness adjustment 0 – 100% CRI index min. 90 control DMX, RDM programmable scenes mounting GLOBAL Trac Pulse Control ® available housing colors gray, black, white PX801-T-06: 1.3kg weight PX801-T-12: 1.7kg PX801-T-18: 2.4kg height PX801-T-06: 225mm diameter PX801-T-06: 92mm height PX801-T-12: 235mm dimensions diameter PX801-T-12: 122mm...
  • Page 20 Podłęże, 01.10.2020 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: PxArt+ 06/12/18 Mono Track Product code: PX801-T meets the requirements of the following standards, as well as harmonised standards:...
