- Page 1 PX803-T PxArt+ XL Mono Track User manual...
-
Page 2: Table Of Contents
8 RDM – available parameters..............14 9 Connection scheme.................16 10 Dimensions.....................17 11 Technical data..................18 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
Description PX803-T is a professional LED illuminator designed to illuminate museum or exhibition displays. By using semiconductor light sources SSL LED COB type and advanced control electronics, a high-class illuminator has been created that meets very high requirements concerning museum and exposition lighting. Its most advantages include the total lack of ultraviolet radiation, trace amounts of infrared radiation, very high CRI color rendering index, high brightness and low energy consumption. -
Page 4: Safety Conditions
Safety conditions Caution! Before installing, connecting and using the lamp you have to absolutely read this document. The following symbols are used to underline important information on security on the product and in this manual. Danger! Warning! Warning! Warning! Warning! Risk of loss of life Fire hazard LED light emission,... - Page 5 The PX803-T device is powered directly from 230V power grid. Failure to comply with the safety rules may result in electric shock and may endanger the user’s life. Therefore it is necessary to observe the following: 1. Installation should be performed by a person holding the appropriate qualifications, according to the instruction manual.
-
Page 6: Connectors And Control Elements
Connectors and control elements Brightness adjustment PX277 parameter programming connector Information on version The PX803-T lamp is available in several versions that differ, for example, in the angle of the lenses used. Below is a description of the PX803-T markings and their explanation: PX803-T –... - Page 7 XX – reflector angle: 15 – 15° 36 – 36° 51 – 51° YYY – CRI and color temperature: X30 – CRI 95, temp. 3000K 930 – CRI 90, temp. 3000K 950 – CRI 90, temp. 5000K 830 – CRI 80, temp. 3000K 850 –...
-
Page 8: Dmx Connection
DMX connection PX803-T is a device attached to the GLOBAL Trac ® Pulse Control rail by using the GAC 600 adapter included in the kit. 5.1 GLOBAL Trac ® GAC 600 adapter DMX contacts DMX - (on the opposite side DMX +) MAINS POWER SUPPLY protective phase 1 (on the opposite... -
Page 9: Control
Control 6.1 Button The lamp has been equipped with button which allow for changing the brightness level. The button have been placed at the bottom part of the junction box, above the lamp reflector. Depending on a situation, the diode signal the following: •... -
Page 10: Dmx Signal
the control button for a moment. The diode will signal the change of adjustment direction. The pressing of the adjustment button again will cause the dimming of the lamp (brightness decrease). While the lamp operates, the diode stays switched off (excluding situations mentioned above). -
Page 11: Available Parameters
7.1 Available parameters DMX Addr. – changing the DMX address of the color temperature and brightness channel in the range 1 – 512, No Signal – behavior of the device when the DMX signal disappears: Scene – setting the scene displayed when the DMX signal disappears, •... - Page 12 Control Mode: 1ch MONO • Firmware version – software version, Serial Number – serial number.
-
Page 13: The Px803-T Menu Diagram In Px277
7.2 The PX803-T menu diagram in PX277 PX803-XL PX803-XM PX803-XS PxArt+ XL MONO PxArt+ XM MONO PxArt+ XS MONO NEXT ENTER DMX Addr. DMX Addr. 001 (1ch) 001 (1ch) * NEXT NEXT DMX Addr. 512 (1ch) * ENTER No Signal No Signal Channel: 1 Off *... -
Page 14: Rdm - Available Parameters
RDM – available parameters The PX803-T supports the DMX-RDM protocol. DMX protocol allows only of a one-way data transmission, while extension the RDM protocol can transmit information in two directions. This makes possibility of monitoring activities of the compatible devices. Thanks to RDM some available settings of compatible devices may be programmed using this protocol. - Page 15 Parameter name Description FACTORY_DEFAULTS 0x0090 device default settings PERSONALITY * 0x00E0 DMX operational mode PERSONALITY_ description of individual 0x00E1 DESCRIPTION operational modes information on the selected SENSOR_DEFINITION 0x0200 temperature sensor SENSOR_VALUE 0x0201 information about sensors SMOOTH_OFF/1/2/3/4 * 0x801A selection of smoothing options NO_SIGNAL_OFF/ON/HLD/S behavior of the device when the 0x801C...
-
Page 16: Connection Scheme
Connection scheme 3-phase GLOBAL Trac® Pulse Control bus-bar end feed power supply cable DMX+ DMX- DMX wire (2 wires in screen) GLOBAL Trac® GAC600 adapter... -
Page 17: Dimensions
10 Dimensions Ø87... -
Page 18: Technical Data
11 Technical data type PX803-T power supply 230V AC number of LEDs 1 (COB) power PX803-T-XL: 26W PF (power factor) 0.94 max. increase of the housing temperature +50°C color rendering index CRI min. 80 lifetime of diodes 50000h reflector angles 15°, 36°, 51°... - Page 19 Podłęże, 04.11.2020 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: PxArt+ XS / XM / XL Mono Track Product code: PX803-T meets the requirements of the following standards, as well as harmonised...
