Summary of Contents for PXM PxAqua 3 SF

  • Page 1 PX278 PxAqua 3 SF User manual...
  • Page 2: Table Of Contents

    3 Information on version................6 4 Connection scheme...................7 5 Dimensions....................8 6 Technical data.....................9 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-3 BDO register number 000005972 www.pxm.pl...
  • Page 3: Description

    Description PxAqua 3 SF LED lamp is designed for underwater lighting. It can also be used to illuminate the interior or exterior architectural details. The lamp uses three high-performance LEDs LUXEON REBEL power of ® 1W each, what ensures its excellent lighting performance. It can be equipped with the optics of different beam angles: 10°, 25°...
  • Page 4: Safety Conditions

    Safety conditions Before installing, connecting and using the lamp you have to absolutely read this document. The following symbols are used to underline important information on security conditions on the product and in this manual. Danger! Warning! Warning! Warning! Warning! Risk of loss of life Fire hazard.
  • Page 5 During its installation and use PX 278 the following rules must be strictly observed: 1. Installation should be performed by a person holding the appropriate qualifications, according to the instruction manual. 2. Lamp may only be connected to stabilized voltage with current-carrying capacity compatible with technical data.
  • Page 6: Information On Version

    Information on version The PX278 lamp is available in several versions that differ in the angle of the lenses used and the color of the LEDs. Below there is a description of designation of the PX278 models and their explanation: PX278 –...
  • Page 7: Connection Scheme

    Connection scheme a) connecting monochrome lamps to the driver Current driver + (red) – (black) power supply 12 - 48V DC V- V+ b) connecting a monochrome lamp to the power supply current power supply 350 - 700mA V- V+...
  • Page 8: Dimensions

    c) connecting RGB lamps in series to the driver LED lamp Current driver LED lamp R– (red/black) power supply 12 - 48V DC R+ (red) V- V+ G– (green/black) G+ (green) LED lamp G– (blue/black) G+ (blue) Dimensions NOTE! When installing the lamp, remember to leave enough space for the cable gland from which the power cable exits.
  • Page 9: Technical Data

    Technical data type PX278 RGB – 3 x 350mA (3 x 700mA in underwater mounting) power supply Mono – 1 x 350mA (1 x 700mA w in underwater mounting) IP rate IP68 beam angles 10°*, 25°, 45°* brightness (25° distance 1m) ~1000lx (white color) LED colors 2700K, 3000K, 4000K, 5000K, 5700K, RGB...
  • Page 10 Podłęże, 31.03.2021 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: PxAqua 3 SF Product code: PX278 meets the requirements of the following standards, as well as harmonised standards: PN-EN IEC 63000:2019-01...
