Summary of Contents for PXM PxLine 230V

  • Page 1 PX 221 PxLine 230V MANUAL...
  • Page 2 8. Declaration of Conformity....................Manufacturer reserves the right to make modifications in order to improve device operation. tel.: +48 12 626 46 92 fax: +48 12 626 46 94 ul. Przemysłowa 12 E-mail: info@pxm.pl 30-701 Kraków Internet: www.pxm.pl POLAND Rev.1.3.
  • Page 3 1. General description The PX221 lamp is designed as an elevations' illuminator and architectural details. Linear LED lamp PxLine 230V is produced in a housing of IP65 (Ingress Protection). PxLine 230V is used in installations where constant light is required.
  • Page 4 The housing of the lamp heats up to 70°C during normal work in open air. You should make sure that contact with the device is not possible. In the case of improper use the product can cause a risk of serious injury or death because of the fire threat.
  • Page 5 4. Available versions of the PX221 The PX221 lamp is made in few versions that differ from each other in beam angles lenses or LEDs color. Below you can find a description of the PX221 model designations and their explanation. PX221-XX-YYY-ZZ-RR-S-TT-WWW 1.
  • Page 6 5. Dimensions...
  • Page 7 The table below shows length of the PxLine lamp according to diffrent LEDs number: LEDs number Length of the lamp 1002 1193 7. TECHNICAL DATA Type PX221 PxLine 230V Light Source LED LUXEON® REBEL Performance max. 2250 lumens (for 700mA version) Beam angles 10 , 25 , 45 , eliptical...
  • Page 8 2004/108/EC and 2006/95/EC Name of producer: PXM s.c. Address of producer: ul. Przemysłowa 12 30-701 Kraków, Poland declares that the product: PxLine 230V Name of product: PX221 Type: answers the following product specifications: PN-EN 60825-1 SAFETY:...
