- Page 1 PX329 PxSpotBar User manual...
-
Page 2: Table Of Contents
7 Diagram of the PX329 menu in PX277..........15 8 Connection scheme.................16 9 Dimensions....................17 10 Technical data..................17 Manufacturer reserves the right to make modifications in order to improve device operation. PXM Marek Żupnik sp.k. Podłęże 654 tel. +48 12 385 83 06 32-003 Podłęże mail: info@pxm.pl Rev.1-0 BDO register number 000005972 www.pxm.pl... -
Page 3: Description
Description The PxSpotBar lamp is designed for illumination of museums exhibitions or displays. Thanks to the use of advanced control electronics, a high-quality illuminator was created, meeting the high requirements for museum and exhibition lighting. Its most important advantages include a complete lack of ultraviolet radiation emission, trace amounts of infrared radiation, a very high factor of CRI color capturing, large brightness and small energy consumption. -
Page 4: Safety Conditions
Safety conditions Caution! Before installing, connecting and using the lamp you have to absolutely read this document. The following symbols are used to underline important information on security conditions on the product and in this manual. Danger! Warning! Warning! Warning! Warning! Risk of loss of life Fire hazard. - Page 5 PX329 is powered directly from standard 230V grid, what can cause electric shock when safety rules are not observed. Therefore it is necessary to observe the following: 1. Installation should be performed by a person holding the appropriate qualifications, according to the instruction manual. 2.
-
Page 6: Information On Version
Information on version Below there is a description of designation of the PX329 models and their explanation: PX329-UU-WW-XYY-Z UU – version: Z – housing colors: X2 – double spot 1 – gray X3 – triple spot 2 – black X4 – quadruple spot 3 –... -
Page 7: Device Programming
Device programming The PxSpotBar settings can be changed by connecting to the PX277 (PxArt+ Settings Controller). It allows in connection with PX329 to define following parameters: the start DMX address of the lamp, device behavior in the absence of DMX signal, Smooth parameter and refresh rate. -
Page 8: Setting The Dmx Address
The user gives the address of the first spot, subsequent spots will be addressed automatically – with subsequent DMX addresses. The following diagram shows the setting of the DMX address for a lamp with four spots. PX329 PX329 PxSpotBar NEXT ENTER ENTER DMX Addresses DMX Start Addr. - Page 9 DMX line. The diagram below shows the setting of the response to the lack of DMX signal for a lamp with four spots. PX329 PX329 PxSpotBar 2 x NEXT ENTER No Signal No Signal...
-
Page 10: Smooth
Level 1 – 4 – level of smoothing adjustable in the range from 1 to 4 (1 – fast, 4 – very fluent) Smooth Level OFF * PREV Smooth Level 1 * PREV PX329 Smooth PX329 PxSpotBar Level 2 * 4 x NEXT PREV ENTER Smooth Smooth Level 3 Level 3 * NEXT... -
Page 11: Restoring Factory Settings
Low and High, which correspond to the following frequencies: 366Hz and 1.4kHz. The High frequency value allows to avoid the flickering effect visible in the cameras. PX329 PX329 PxSpotBar 5 x NEXT ENTER PWM Frequency PWM Frequency Low *... -
Page 12: Number Of Sports
1 to 4. Incorrect setting of the number of spots in the lamp may cause incorrect operation of the lamp. Output Channels PREV PX329 Output Channels PX329 PxSpotBar 10 x NEXT PREV ENTER Output Channels Output Channels... - Page 13 List of the supported RDM parameters by PX329: Parameter name Description SUPPORTED_PARAMETERS 0x0050 all supported parameters description of additional PARAMETER_DESCRIPTION 0x0051 parameters DEVICE_INFO 0x0060 information concerning the device SOFTWARE_VERSION_LABEL 0x00C0 firmware version of the device DMX starting address of the device; DMX_ADDRESS * 0x00F0 Range 1 –...
- Page 14 Parameter name Description NO_SIGNAL_OFF_0/ON_1/ selection of operating mode if no 0x801C SC_2/HLD_3 * DMX signal is available time of entry of selected reaction NOS_TIME * 0x804D after DMX signal loss, 0 – 10 seconds the value of the scene after DMX NO_SCENE * 0x8022 signal decay in the range of 0 –...
-
Page 15: Diagram Of The Px329 Menu In Px277
Diagram of the PX329 menu in PX277 Lamp Status 025%065%000%100% PREV PX329 PX329 PxSpotBar NEXT ENTER ENTER DMX Addresses DMX Start Addr. DMX Start Addr. 001 002 003 004 NEXT NEXT ENTER No Signal No Signal DMX Start Addr. Off *... -
Page 16: Connection Scheme
Connection scheme DMX for subsequent devices 230V power supply dmx- DMX- dmx+ DMX+ dmx- dmx+ DMX- DMX+ DMX controller... -
Page 17: Dimensions
Dimensions dmx- dmx+ dmx- dmx+ 10 Technical data type PX329 number of sport 2 / 3 / 4* beam angle 25°, 40° power supply 230V AC colour temperature version 3000K CRI index min. 90 control DMX, RDM, PX277 housing material aluminum / stainless steel available housing colors gray, black, white... - Page 18 Podłęże, 21.05.2019 DECLARATION OF CONFORMITY PXM Marek Żupnik spółka komandytowa Podłęże 654, 32-003 Podłęże we declare that our product: Product name: PxSpotBar Product code: PX329 meets the requirements of the following standards, as well as harmonised standards: PN-EN 60598-1:2015 EN 60598-1:2015...
