User Guide
EVALUATION BOARD SOFTWARE
Single Tone Mode
Open the Single Tone Mode folder to access the single tone mode of operation example setup files. This section discusses the All Channels
on @ 10_20_30_40MHz_RURD enabled.stp file.
The Chip Level Control window
operation enabled. In the RU/RD box, Use Profile Pins 2 & 3 has been selected to control the RU/RD feature.
In the Channel Control window
Modulation Output Type box.
In the Channel Output Config window
frequency of 20 MHz, Channel 2 an output frequency of 30 MHz, and Channel 3 has a frequency output of 40 MHz. Because the RU/RD
operation is enabled, the Enable ASF and Enable Auto ASF boxes are checked. The amplitude scalar factor (ASF) is set to 1 (full scale).
Therefore, the output signal will be 0 MHz until the correct profile pin is selected to ramp the frequency up to full scale. When this setup file
is loaded, profile pins P0, P1, P2, and P3 are pressed as shown in the Profile and RURD Pin Control Section. P0 controls Channel 0, P1
analog.com
(Figure 37) from this particular setup shows that a 500 MHz System Clock is running, with the RU/RD
(Figure 38), each channel has None (Single Tone) selected for their modulation output as shown in the
(Figure 39), Channel 0 has a frequency output of 10 MHz (Frequency 00 box), Channel 1 an output
Figure 37.
Figure 38.
EVAL-AD9959
Rev. A | 18 of 27
