- Page 1 XPL 201 X-DIAS LED Module Instruction Manual Date of creation: 12.07.2024 Version date: 06.02.2025 Article number: 21-018-201-E...
- Page 2 (print, photocopy, microfilm or in any other process) without express permission. We reserve the right to make changes in the content without notice. SIGMATEK GmbH & Co KG is not responsible for technical or printing errors in this handbook and assumes no responsibility for damages that occur through...
- Page 3 XPL 201 2x RGB pixel LED strip control with 5 V supply The X-DIAS LED Module XPL 201 can be used to control two RGB pixel LED strips with a maximum of 512 pixel LEDs. The +5 V supply for the pixel LEDs is generated by means of an internal switching regulator from the externally supplied +24 V supply.
-
Page 4: Table Of Contents
5.4 Environmental Conditions 5.5 Miscellaneous 6 Mechanical Dimensions 7 Connector Layout 7.1 Status LEDs 7.2 Applicable Connectors 8 Label Field 9 Module Coding 9.1 Module Coding XPL 201 9.2 Coding Hole Positions on Wiring Board (TOP View) Page 2 06.02.2025... - Page 5 X-DIAS LED MODULE XPL 201 10 Wiring 10.1 ESD Protection 10.2 Wiring Example 10.3 Note 11 Assembly/Installation 11.1 Mounting 12 Supported Cycle Times 12.1 Cycle Times below 1 ms (in µs) 12.2 Cycle Times equal to or higher than 1 ms (in ms)
-
Page 6: Introduction
Please see our website for our hotline number and business hours. 1.2 Important Reference Documentation X-DIAS Designguide This and additional documents can be downloaded from our website or obtained through support. 1.3 Contents of Delivery 1x XPL 201 Page 4 06.02.2025... -
Page 7: Basic Safety Directives
X-DIAS LED MODULE XPL 201 2 Basic Safety Directives 2.1 Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes. DANGER Danger indicates that death or serious injury will occur, if the specified measures are not taken. - Page 8 XPL 201 X-DIAS LED MODULE CAUTION Caution indicates that moderate to slight injury can occur, if the specified measures are not taken. To avoid moderate to slight injuries, observe all guidelines. Attention indique une situation dangereuse qui, faute de prendre les mesures adéquates, peut entraîner des blessures assez graves ou...
-
Page 9: Disclaimer
Please thoroughly read the corresponding documents and this operating manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations. -
Page 10: General Safety Directives
Regarding the requirements for Safety and health connected to the use of machines, the manufacturer must perform a risk assessment in accordance with machine directives 2006/42/EG before introducing a machine to the market. Operate the unit with devices and accessories approved by SIGMATEK only. Page 8 06.02.2025... - Page 11 X-DIAS LED MODULE XPL 201 CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened! Manipulez l’appareil avec précaution et ne le laissez pas tomber.
-
Page 12: Standards And Directives
The product was constructed in compliance with the following European Union directives and tested for conformity. 3.1.1 EU Conformity Declaration EU Declaration of Conformity The product XPL 201 conforms to the following European directives: 2014/35/EU Low-voltage Directive 2014/30/EU Electromagnetic Compatibility (EMC Directive) 2011/65/EU “Restricted use of certain hazardous substances in electrical and electronic equipment”... -
Page 13: Type Plate
X-DIAS LED MODULE XPL 201 4 Type Plate HW: Hardware version SW: Software version FW: Firmware version LD: Logic Device version 06.02.2025 Page 11... -
Page 14: Technical Data
XPL 201 X-DIAS LED MODULE 5 Technical Data 5.1 Pixel LED Output Specifications Number Short-circuit and overload protection Supported pixel LEDs WS2812B, WS2813 Maximum number of pixel LEDs 512 pixel LEDs Data rate pixel LED control 800 kB/s Update frequency approx. -
Page 15: Voltage Monitoring
X-DIAS LED MODULE XPL 201 INFORMATION For USA and Canada: The supply must be limited to: a) max. 5 A at voltages from 0-20 V DC, or b) 100 W at voltages from 20-60 V DC The limiting component (e.g. transformer, power supply or fuse) must be certified by an NRTL (Nationally Recognized Testing Laboratory). -
Page 16: Environmental Conditions
XPL 201 X-DIAS LED MODULE 5.4 Environmental Conditions Storage temperature -40 ... +85 °C Environmental temperature -25 ... +55 °C Humidity 0-95 %, non condensing Installation altitude above sea 0-2000 m without derating level > 2000 m up to a maximum of 5000 m with derating of the maximum environmental temperature by 0.5 °C per 100 m... -
Page 17: Mechanical Dimensions
X-DIAS LED MODULE XPL 201 6 Mechanical Dimensions Measurements 12.5 x 101.8 x 62.7 mm (W x H x D) Weight 0.2 kg 06.02.2025 Page 15... -
Page 18: Connector Layout
XPL 201 X-DIAS LED MODULE 7 Connector Layout Signal Description +24 V bus +24 V bus S-DIAS bus The +24 V voltage supply is provided by the S-DIAS CPU or RxD- OUT RxD- IN the S-DIAS interface module. RxD+ OUT... -
Page 19: Status Leds
X-DIAS LED MODULE XPL 201 7.1 Status LEDs 06.02.2025 Page 17... -
Page 20: Applicable Connectors
XPL 201 X-DIAS LED MODULE Module status green module active no supply available BLINKING (5 Hz) no communication User yellow adjustable by application (e.g. the module LED can be set to blinking through the visualization so that the module is easily found in... -
Page 21: Label Field
X-DIAS LED MODULE XPL 201 8 Label Field The labeling field is printed directly on the module. 06.02.2025 Page 19... -
Page 22: Module Coding
9 Module Coding X-DIAS modules have module coding by means of coding pins on the module housing. In combination with coding holes on the wiring board, a mismating protection can be realized. 9.1 Module Coding XPL 201 Position 1 Position 2... -
Page 23: Wiring
X-DIAS LED MODULE XPL 201 10 Wiring 10.1 ESD Protection CAUTION The operator must ensure that no ESD interference affects the product. L'opérateur doit s'assurer qu'aucune interférence due à des décharges électrostatiques n'affecte le produit. 10.2 Wiring Example 06.02.2025 Page 21... -
Page 24: Note
XPL 201 X-DIAS LED MODULE 10.3 Note The functional grounding of the X-DIAS modules is carried out via their GND connection on the wiring board. The wiring board must be connected to the grounded switch cabinet mounting plate with low resistance via the mounting screws. -
Page 25: Assembly/Installation
X-DIAS LED MODULE XPL 201 11 Assembly/Installation 11.1 Mounting The S-DIAS modules are designed for installation into the control cabinet. To mount the modules, a DIN-rail is required. The DIN rail must establish a conductive connection with the back wall of the control cabinet. The individual S-DIAS modules are mounted on the DIN rail as a block and secured with latches. - Page 26 XPL 201 X-DIAS LED MODULE Recommended minimum distances between the S-DIAS modules and the surrounding components or control cabinet wall: a, b, c … distances in mm (inches) Page 24 06.02.2025...
-
Page 27: Supported Cycle Times
X-DIAS LED MODULE XPL 201 12 Supported Cycle Times 12.1 Cycle Times below 1 ms (in µs) x = supported 12.2 Cycle Times equal to or higher than 1 ms (in ms) x = supported x = supported 06.02.2025 Page 25... -
Page 28: Transport/Storage
XPL 201 X-DIAS LED MODULE 13 Transport/Storage INFORMATION This device contains sensitive electronics. During transport and storage, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport. -
Page 29: Storage
X-DIAS LED MODULE XPL 201 14 Storage INFORMATION When not in use, store the operating panel according to the storage conditions. See chapter 13 Transport/Storage. During storage, ensure that all protective covers (if available) are placed correctly, so that no contamination, foreign bodies or fluids enter the device. -
Page 30: Maintenance
XPL 201 X-DIAS LED MODULE 15 Maintenance INFORMATION During maintenance as well as servicing, observe the safety instructions from chapter 2 Basic Safety Directives. Lors de l'entretien et de la maintenance, respectez les consignes de sécurité du chapitre 2 Basic Safety Directives. -
Page 31: Disposal
X-DIAS LED MODULE XPL 201 16 Disposal INFORMATION Should you need to dispose of the device, the national regulations for disposal must be followed. The device appliance must not be disposed of as household waste. 06.02.2025 Page 29... -
Page 32: Change History
XPL 201 X-DIAS LED MODULE Change History Change Affected Chapter Note date page(s) 04.09.2024 Introduction short name XPL 201 added 30.09.2024 Document Revision 13.12.2024 5.1 Pixel LED Output Specifications Ambient temperature 60 °C removed 5.4 Environmental Conditions 17.12.2024 Document Layout changes 03.02.2025...
