XBL 011
X-DIAS Blind Module
Instruction Manual
Date of creation: 11.07.2024
Version date: 06.02.2025
Article number: 21-015-011-E

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XBL 011 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for SIGMATEK XBL 011

  • Page 1 XBL 011 X-DIAS Blind Module Instruction Manual Date of creation: 11.07.2024 Version date: 06.02.2025 Article number: 21-015-011-E...
  • Page 2 (print, photocopy, microfilm or in any other process) without express permission. We reserve the right to make changes in the content without notice. SIGMATEK GmbH & Co KG is not responsible for technical or printing errors in this handbook and assumes no responsibility for damages that occur through...
  • Page 3 X-DIAS BLIND MODULE XBL 011 X-DIAS Blind Module XBL 011 The X-DIAS Blind Module XBL 011 can be used as a placeholder for a later system expansion. The blind module is an active X-DIAS module on the bus. 06.02.2025 Page 1...
  • Page 4: Table Of Contents

    5.3 Miscellaneous 6 Mechanical Dimensions 7 Connector Layout 7.1 Status LEDs 7.2 Applicable Connectors 8 Label Field 9 Module Coding 9.1 Module Coding XBL 011 9.2 Coding Hole Positions on Wiring Board (TOP View) 10 Assembly/Installation 10.1 Mounting Page 2 06.02.2025...
  • Page 5 X-DIAS BLIND MODULE XBL 011 11 Transport/Storage 12 Storage 13 Maintenance 13.1 Service 13.2 Repair 14 Disposal 06.02.2025 Page 3...
  • Page 6: Introduction

    Please see our website for our hotline number and business hours. 1.2 Important Reference Documentation X-DIAS Designguide This and additional documents can be downloaded from our website or obtained through support. 1.3 Contents of Delivery 1x XBL 011 Page 4 06.02.2025...
  • Page 7: Basic Safety Directives

    X-DIAS BLIND MODULE XBL 011 2 Basic Safety Directives 2.1 Symbols Used The following symbols are used in the operator documentation for warning and danger messages, as well as informational notes. DANGER Danger indicates that death or serious injury will occur, if the specified measures are not taken.
  • Page 8 XBL 011 X-DIAS BLIND MODULE CAUTION Caution indicates that moderate to slight injury can occur, if the specified measures are not taken. To avoid moderate to slight injuries, observe all guidelines. Attention indique une situation dangereuse qui, faute de prendre les mesures adéquates, peut entraîner des blessures assez graves ou...
  • Page 9: Disclaimer

    Please thoroughly read the corresponding documents and this operating manual before handling a product. SIGMATEK GmbH & Co KG is not liable for damages caused through, non-compliance with these instructions or applicable regulations.
  • Page 10: General Safety Directives

    Regarding the requirements for Safety and health connected to the use of machines, the manufacturer must perform a risk assessment in accordance with machine directives 2006/42/EG before introducing a machine to the market. Operate the unit with devices and accessories approved by SIGMATEK only. Page 8 06.02.2025...
  • Page 11 X-DIAS BLIND MODULE XBL 011 CAUTION Handle the device with care and do not drop or let fall. Prevent foreign bodies and fluids from entering the device. The device must not be opened! Manipulez l’appareil avec précaution et ne le laissez pas tomber.
  • Page 12: Standards And Directives

    The product was constructed in compliance with the following European Union directives and tested for conformity. 3.1.1 EU Conformity Declaration EU Declaration of Conformity The product XBL 011 conforms to the following European directives: 2014/35/EU Low-voltage Directive 2014/30/EU Electromagnetic Compatibility (EMC Directive) 2011/65/EU “Restricted use of certain hazardous substances in electrical and electronic equipment”...
  • Page 13: Type Plate

    X-DIAS BLIND MODULE XBL 011 4 Type Plate HW: Hardware version SW: Software version FW: Firmware version LD: Logic Device version 06.02.2025 Page 11...
  • Page 14: Technical Data

    XBL 011 X-DIAS BLIND MODULE 5 Technical Data 5.1 Electrical Requirements Voltage supply from S-DIAS bus +24 V DC ±20 % (SELV/PELV) UL: NEC Class 2 Protection class Current consumption on the typically 11 mA maximum 15 mA S-DIAS bus (+24 V supply)
  • Page 15: Environmental Conditions

    X-DIAS BLIND MODULE XBL 011 5.2 Environmental Conditions Storage temperature -40 ... +85 °C Environmental temperature -25 ... +60 °C Humidity 0-95 %, non condensing Installation altitude above sea 0-2000 m without derating level > 2000 m up to a maximum of 5000 m with derating of the maximum environmental temperature by 0.5 °C per 100 m...
  • Page 16: Mechanical Dimensions

    XBL 011 X-DIAS BLIND MODULE 6 Mechanical Dimensions Measurements 12.5 x 101.8 x 62.7 mm (W x H x D) Weight 0.2 kg Page 14 06.02.2025...
  • Page 17: Connector Layout

    X-DIAS BLIND MODULE XBL 011 7 Connector Layout Signal Description 24 V 24 V S-DIAS bus The +24 V voltage supply is provided by the S-DIAS CPU or RxD- OUT RxD- IN the S-DIAS interface module. RxD+ OUT RxD+ IN...
  • Page 18: Status Leds

    XBL 011 X-DIAS BLIND MODULE 7.1 Status LEDs Module status green module active no supply available BLINKING (5 Hz) no communication User yellow adjustable by application (e.g. the module LED can be set to blinking through the visualization so that the module is easily found in...
  • Page 19: Label Field

    X-DIAS BLIND MODULE XBL 011 8 Label Field The labeling field is printed directly on the module. 06.02.2025 Page 17...
  • Page 20: Module Coding

    X-DIAS modules have module coding by means of coding pins on the module housing. In combination with coding holes on the wiring board, a mismating protection can be realized. 9.1 Module Coding XBL 011 The module has no coding pins, as it is intended to serve as a placeholder for each X-DIAS module.
  • Page 21: Assembly/Installation

    X-DIAS BLIND MODULE XBL 011 10 Assembly/Installation 10.1 Mounting The S-DIAS modules are designed for installation into the control cabinet. To mount the modules, a DIN-rail is required. The DIN rail must establish a conductive connection with the back wall of the control cabinet. The individual S-DIAS modules are mounted on the DIN rail as a block and secured with latches.
  • Page 22 XBL 011 X-DIAS BLIND MODULE Recommended minimum distances between the S-DIAS modules and the surrounding components or control cabinet wall: a, b, c … distances in mm (inches) Page 20 06.02.2025...
  • Page 23: Transport/Storage

    X-DIAS BLIND MODULE XBL 011 11 Transport/Storage INFORMATION This device contains sensitive electronics. During transport and storage, high mechanical stress must therefore be avoided. For storage and transport, the same values for humidity and vibration as for operation must be maintained! Temperature and humidity fluctuations may occur during transport.
  • Page 24: Storage

    XBL 011 X-DIAS BLIND MODULE 12 Storage INFORMATION When not in use, store the operating panel according to the storage conditions. See chapter 11 Transport/Storage. During storage, ensure that all protective covers (if available) are placed correctly, so that no contamination, foreign bodies or fluids enter the device.
  • Page 25: Maintenance

    X-DIAS BLIND MODULE XBL 011 13 Maintenance INFORMATION During maintenance as well as servicing, observe the safety instructions from chapter 2 Basic Safety Directives. Lors de l'entretien et de la maintenance, respectez les consignes de sécurité du chapitre 2 Basic Safety Directives.
  • Page 26: Disposal

    XBL 011 X-DIAS BLIND MODULE 14 Disposal INFORMATION Should you need to dispose of the device, the national regulations for disposal must be followed. The device appliance must not be disposed of as household waste. Page 24 06.02.2025...
  • Page 27: Change History

    X-DIAS BLIND MODULE XBL 011 Change History Change Affected Chapter Note date page(s) 30.09.2024 Document Revision 17.12.2024 Document Layout changes 03.02.2025 Document Layout changes 06.02.2025 5.2 Environmental Conditions Environmental and storage temperature changed 06.02.2025 Page 25...
