  • Page 1 ALTRAD8UD2-1L2Q User Manual Version 1.00 Published May 2024 Copyright©2024 ASRock Rack INC. All rights reserved.

  • Page 2: Copyright Notice

    In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of...
  • Page 3 ASRock Rack follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock Rack product is in line with global environmental regulations. In addition, ASRock Rack disclose the relevant in- formation based on regulation requirements.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU Installation of Memory Modules (DIMM) Expansion Slots (PCI Express Slots) Jumper Setup Onboard Headers and Connectors ATX PSU / DC-IN Power Connections Unit Identification purpose LED/Switch...
  • Page 5 3.1.1 UEFI Menu Bar 3.1.2 Navigation Keys Main Screen 3.2.1 Mother Board Information 3.2.2 Processor Information 3.2.3 Memory Information Advanced Screen 3.3.1 CPU Configuration 3.3.2 RAS Configuration 3.3.3 Chipset Configuration 3.3.4 NVMe Configuration 3.3.5 ACPI Configuration 3.3.6 USB Configuration 3.3.7 Serial Port Console Redirection 3.3.8 H/W Monitor 3.3.9 Network Stack Configuration 3.3.10 Driver Health...
  • Page 6 3.5.1 Key Management Boot Exit Screen Chapter 4 Software Support Download and Install Operating System Download and Install Software Drivers Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...

  • Page 7: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. Find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com Please visit the website for more specific information about the using model.

  • Page 8: Specifications

    1.2 Specifications ALTRAD8UD2-1L2Q Physical Status Form Factor Deep Micro-ATX Dimension 9.6” x 10.5” (24.4cm x 26.7cm) Processor System Supports Ampere® Altra® Max/Ampere® Altra® Processor Socket 1 Socket (LGA4926) Chipset System on Chip System Memory Supported DIMM 8 DIMM slots (1DPC) Quantity...
  • Page 9 System BIOS Type AMI UEFI BIOS; 256 Mb (32MB) SPI Flash ROM Features ASRock Rack Instant Flash, ACPI 6.2, SMBIOS 3.4.0 and above, Plug and Play(PnP) Internal Connectors/Headers PSU Connector 1 (4-pin, ATX PSU signal) w/ ATX 24-pin adapter cable, 3 (8-...
  • Page 10 LED Indicators Standby Power 1 (5VSB) Fan Fail LED BMC Heartbeat Supported OS - RHEL 8.5 aarch64 - RHEL 9.2 aarch64 - CentOS-Stream 8 aarch64 - CentOS-Stream 9 aarch64 Please refer to the website for the latest OS support list. Environment Temperature Operation temperature: 10°C ~ 35°C (50 - 95 degF)/ Non...

  • Page 11: Unique Features

    With this utility, press the <F6> key during the POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to the USB flash drive, floppy disk or hard drive, then update the BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 12: Motherboard Layout

    USB 3.2 ATX12V2 DDR4_E1 Gen1 Ports IPMI T:USB3_4 B:USB3_3 DDR4_F1 DDR4_G1 BIOS ATX12V3 SLIMLINE3 UID1 DDR4_H1 ® PCIE7 FAN1 SLIMLINE4 FAN2 ALTRAD8UD2-1L2Q PCIE6 FAN3 ASPEED AST2500 FAN4 PCIE5 CLRMOS1 FAN5 PCIE4 SATAPWR1 TPM_BIOS_PH1 BMC_DIS USB3_3_1 HSBP1 BMC_SMB1 AUX_PANEL1 PANEL1 IPMB1...
  • Page 13 ALTRAD8UD2-1L2Q Description Front VGA Header (FRNT_VGA1) OCuLink Connector (PCIe4.0 x4) (OCU2) OCuLink Connector (PCIe4.0 x4) (OCU1) 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_C1)* 2 x 288-pin DDR4 DIMM Slots (DDR4_B1, DDR4_D1)* Micro-Fit ATX 4Pin Power Connector (ATX4PIN1) ATX 12V Power Connector (ATX12V1)
  • Page 14 Description Intelligent Platform Management Bus Header (IPMB1) Serial Port Header (COM1) Front LAN LED Connector (LED_LAN3) PCI Express 4.0 x16 Slot (PCIE4) PCI Express 4.0 x16 Slot (PCIE5) PCI Express 4.0 x16 Slot (PCIE6) PCI Express 4.0 x16 Slot (PCIE7) 2 x 288-pin DDR4 DIMM Slots (DDR4_F1, DDR4_H1)* 2 x 288-pin DDR4 DIMM Slots (DDR4_E1, DDR4_G1)* *For DIMM installation and configuration instructions, please see p.23 (Installation of Memory Modules...

  • Page 15: Onboard Led Indicators

    ALTRAD8UD2-1L2Q 1.5 Onboard LED Indicators...
  • Page 16 Item Status Description LED_FAN1 FAN1 Fail LED_FAN2 FAN2 Fail LED_FAN3 FAN3 Fail LED_FAN4 FAN4 Fail LED_FAN5 FAN5 Fail Green CPLD Ready OVERTEMP CPU Fail Alert HIGHTEMP CPU SB_PWR1 Green STB PWR Ready LED6/LED5/LED4/LED3 0 : 0 : 0 : 0 Waiting for BMC Ready and Power Event.

  • Page 17: I/O Panel

    ALTRAD8UD2-1L2Q 1.6 I/O Panel No. Description No. Description VGA Port (VGA1) 1G LAN RJ-45 Port (LAN3)** 25G SFP28 (Fiber) USB 3.2 Gen1 Ports (USB3_3_4) (SFP1, shared NIC)*** 25G SFP28 (Fiber) (SFP2)*** LAN RJ-45 Port (IPMI)* USB 3.2 Gen1 Ports (USB3_1_2)
  • Page 18 **There is an LED on each side of 1G LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port 1G LAN Port LED Indications Activity / Link LED Speed LED Status Description Status...

  • Page 19: Block Diagram

    ALTRAD8UD2-1L2Q 1.7 Block Diagram ALTRAD8UD2-1L2Q Block Diagram 4×PCIe x16 Slot RCA2 PCIE SLOT4 DDR4 1DIMM/Channel DDR4 DDR4 DDR 0, 1, 2, 3 RCA3 PCIE SLOT5 DDR4 DDR4 RCA6 PCIE SLOT7 DDR4 RCA7 PCIE SLOT6 DDR4 DDR 4, 5, 6, 7...

  • Page 20: Chapter 2 Installation

    Chapter 2 Installation This is a deep micro-ATX form factor (9.6” x 10.5”) motherboard. Before installing the motherboard, study the configuration of the chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries and motherboard damages.

  • Page 21: Pre-Installation Precautions

    ALTRAD8UD2-1L2Q Do not over-tighten the screws! Doing so may damage the motherboard. 2.2 Pre-installation Precautions Take note of the following precautions before installing motherboard components or change any motherboard settings. 1. Unplug the power cord from the wall socket before touching any components.

  • Page 22: Installing The Cpu

    2.3 Installing the CPU LOTES SKT4926 5->4->3->2->1...
  • Page 23 ALTRAD8UD2-1L2Q Remove Socket Cap Insert CPU...
  • Page 24 1->2->3->4->5...
  • Page 25 ALTRAD8UD2-1L2Q...
  • Page 26 FOXCONN SKT4926 4->3->2->1...
  • Page 27 ALTRAD8UD2-1L2Q Remove Socket Cap Insert CPU...
  • Page 28 1->2->3->4...
  • Page 29 ALTRAD8UD2-1L2Q...

  • Page 30: Installation Of Memory Modules (Dimm)

    2.4 Installation of Memory Modules (DIMM) This motherboard provides eight 288-pin DDR4 (Double Data Rate 4) DIMM slots in two groups, and supports Single Channel Memory Technology. CPU1 DDR4_A1, B1, C1, D1 DDR4_E1, F1, G1 H1 1. For Eight channel configuration, it always needs to install identical (the same brand, speed, size and chip-type) DDR4 DIMM groups.
  • Page 31 ALTRAD8UD2-1L2Q...

  • Page 32: Expansion Slots (Pci Express Slots)

    2.5 Expansion Slots (PCI Express Slots) There are 4 PCI Express slots on this motherboard. PCIE slots: PCIE7 (PCIE 4.0 x16 slot, from CPU1) is used for PCI Express x8 or x16 lane width cards. PCIE6 (PCIE 4.0 x16 slot, from CPU1) is used for PCI Express x8 or x16 lane width cards. PCIE5 (PCIE 4.0 x16 slot, from CPU1) is used for PCI Express x16 lane width cards.

  • Page 33: Jumper Setup

    ALTRAD8UD2-1L2Q 2.6 Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.

  • Page 34: Onboard Headers And Connectors

    2.7 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header Connect the power switch, PLED+ PLED-...
  • Page 35 ALTRAD8UD2-1L2Q Auxiliary Panel Header This header supports multiple (18-pin AUX_PANEL1) functions on the front panel, (see p.6, No. 27) including the front panel SMB, internet status indicator and chassis intrusion pin. A. Front panel SMBus connecting pin (6-1 pin FPSMB) This header allows user to connect SMBus (System Management Bus) equipment.
  • Page 36 Thermal Sensor Header Please connect the thermal (3-pin TR1) sensor cable to this header (see p.6, No. 33) and the other end to the device which can monitor its temperature. PWM Configuration The header is used for PWM Header configurations. (3-pin PWM_CFG1) (see p.6, No.
  • Page 37 ALTRAD8UD2-1L2Q Backplane PCI Express This connector is used for the Hot-Plug Connector hot plug feature of HDDs on CPU_HP_SCL CPU_HP_SDA (5-pin HSBP1) the backplane. P0_HP_ALERT_L (see p.6, No. 30) Clear CMOS Pad This allows user to clear (CLRMOS1) the data in CMOS. To clear (see p.6, No.
  • Page 38 PSU SMBus Header PSU SMBus monitors the ALERT SMBCLK (5-pin PSU_SMB1) status of the power supply, fan (see p.6, No. 8) and system temperature. SMBDATA ATX 12V Power This motherboard provides Connectors three 8-pin ATX 12V power (8-pin ATX12V1) connectors. (see p.6, No.
  • Page 39 ALTRAD8UD2-1L2Q Intelligent Platform This 4-pin connector is IPMB_SDA IPMB_SCL Management Bus Header used to provide a cabled (4-pin IPMB1) base-board or front panel No connect (see p.6, No. 34) connection for value added features and 3rd-party add- in cards, such as Emergency...
  • Page 40 Slimline NVMe These connectors are used for B Side (Latch) Connectors the NVME PCIE devices. (SLIMLINE1) (see p.6, No. 9) (SLIMLINE2) (see p.6, No. 10) (SLIMLINE3) (see p.6, No. 14) (SLIMLINE4) (see p.6, No. 16) 77 79 78 80...
  • Page 41 ALTRAD8UD2-1L2Q 80-pin Defeinition Pin Defeinition GND_1 GDN12 RX0_DP TX0_DP RX0_DN TX0_DN GDN2 GDN13 RX1_DP TX1_DP RX1_DN TX1_DN GDN3 GDN14 SIDEBAND1 SMBCLK WAKE SMBDAT 100M Clock DP PERST# 100M Clock DN PRSNT# GDN4 GDN15 RX2_DP TX2_DP RX2_DN TX2_DN GDN5 GDN16 RX3_DP...

  • Page 42: Atx Psu / Dc-In Power Connections

    2.8 ATX PSU / DC-IN Power Connections This motherboard supports both +12V DC and ATX power input. Please refer to the table below for the required connections between the motherboard and the power supply. Connector DC-IN ATX PSU 12V 8pin ATX 4pin (with the bundled ATX 24pin-to-4pin converter cable)

  • Page 43: Unit Identification Purpose Led/Switch

    ALTRAD8UD2-1L2Q 2.9 Unit Identification purpose LED/Switch With the UID button, user can locate the server working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed, (UID1) the front/rear UID blue LED indicator will be turned on.

  • Page 44: Dual Lan And Teaming Operation Guide

    2.10 Dual LAN and Teaming Operation Guide Dual LAN with Teaming enabled on the motherboard allows two single connections to act as one single connection for twice the transmission bandwidth, making data transmission more effective and improving the quality of transmission of distant images. Fault tolerance on the dual LAN network prevents network downtime by transferring the workload from a failed port to a working port.

  • Page 45: Ssd Module Installation Guide

    ALTRAD8UD2-1L2Q 2.11 M.2 SSD Module Installation Guide The M.2 Socket (M2_1/M2_2, Key M) supports type 2230/2280 SATA3 6.0 Gb/s module or a M.2 PCI Express module up to Gen4 x4 (16GT/s x4). Installing the M.2 SSD Module Step 1 Prepare a M.2 SSD module and the screw.
  • Page 46 Step 3 Move the standoff based on the module type and length. Skip Step 3 and 4 and go straight to NUT80 NUT30 Step 5 when using the default nut. Otherwise, release the standoff by hand. Step 4 Peel off the protective film on the nut to be used.

  • Page 47: Host Console Debug Code

    ALTRAD8UD2-1L2Q 2.12 Host Console Debug Code Using Putty Configuration to see the boot progress before UEFI loading, which makes troubleshooting even easier. The screenshots in this user manual are examples and for references only. The actual im- ages may slightly vary depending on the ip and port used.
  • Page 48 3. The terminal window will list the boot process as below. Command for Example: >> ssh root@<bmcip> -p 2200: host console ssh root@<bmcip> -p 2201: ATF console ssh root@<bmcip> -p 2202: SCP console ssh root@<bmcip> -p 22 : BMC console...
  • Page 49 ALTRAD8UD2-1L2Q POST CODE Table: Code Description PEI Progress 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x2B PEI_MEMORY_SPD_READ 0x2C PEI_MEMORY_PRESENCE_DETECT 0x2D PEI_MEMORY_TIMING 0x2E PEI_MEMORY_CONFIGURING 0x2F PEI_MEMORY_INIT 0x31 PEI_MEMORY_INSTALLED 0x32 PEI_CPU_INIT 0x33 PEI_CACHE_INIT 0x34 PEI_CPU_AP_INIT 0x35 PEI_CPU_BSP_SELECT 0x36 PEI_CPU_SMM_INIT 0x37 PEI_MEM_NB_INIT...
  • Page 50 0x3B PEI_MEM_SB_INIT 0x4F PEI_DXE_IPL_STARTED PEI Errors 0x50 PEI_MEMORY_INVALID_TYPE, PEI_MEMORY_INVALID_SPEED 0x51 PEI_MEMORY_SPD_FAIL 0x52 PEI_MEMORY_INVALID_SIZE, PEI_MEMORY_MISMATCH 0x53 PEI_MEMORY_NOT_DETECTED, PEI_MEMORY_NONE_USEFUL 0x54 PEI_MEMORY_ERROR 0x55 PEI_MEMORY_NOT_INSTALLED 0x56 PEI_CPU_INVALID_TYPE, PEI_CPU_INVALID_SPEED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED, PEI_CPU_CACHE_ERROR 0x59 PEI_CPU_MICROCODE_UPDATE_FAILED, PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_INTERNAL_ERROR, PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE...
  • Page 51 ALTRAD8UD2-1L2Q DXE Progress 0x60 DXE_CORE_STARTED 0x61 DXE_NVRAM_INIT 0x62 DXE_SBRUN_INIT 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM...
  • Page 52 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD...
  • Page 53 ALTRAD8UD2-1L2Q 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET DXE Errors 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE...
  • Page 54 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE...

  • Page 55: Chapter 3 Uefi Setup Utility

    ALTRAD8UD2-1L2Q Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure the system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. Run the UEFI SETUP UTILITY when starting up the computer. Please press <F2> or <Del> during the Power- On-Self-Test (POST) to enter the UEFI SETUP UTILITY;...

  • Page 56: Navigation Keys

    3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 57: Main Screen

    ALTRAD8UD2-1L2Q 3.2 Main Screen Once entering the UEFI SETUP UTILITY, the Main screen will appear and display the system overview. The Main screen provides system overview information and allows user to set the system time and date.

  • Page 58: Mother Board Information

    3.2.1 Mother Board Information Press <Enter> to view the information of the motheboard. 3.2.2 Processor Information Press <Enter> to view the information of the processor.

  • Page 59: Memory Information

    ALTRAD8UD2-1L2Q 3.2.3 Memory Information Press <Enter> to view the information of the memory.

  • Page 60: Advanced Screen

    3.3 Advanced Screen In this section, set the configurations for the following items: CPU Configuration, RAS Configuration, Chipset Configuration, NVME Configuration, ACPI Configuration, USB Configuration, Serial Port Console Redirection, H/W Monitor, Trusted Computing, Net- work Stack Configuration, Driver Health, Tls Auth Configuration and Instant Flash. Setting wrong values in this section may cause the system to malfunction.

  • Page 61: Cpu Configuration

    ALTRAD8UD2-1L2Q 3.3.1 CPU Configuration Enable number of cores Use this item to enable the number of cores for the sysem. ARM ERRATA 1542419 workaround This item includes Disable, Workaround and Disable options used for trapping each IC IVAU to EL3.
  • Page 62 SLC as L3$ Use this item to enable or disable PPTT to indicate SLC as L3$ (Cache). This is limited to only 1P Monolithic mode.

  • Page 63: Ras Configuration

    ALTRAD8UD2-1L2Q 3.3.2 RAS Configuration Hardware EINJ Use this item to enable or disable hardware EINJ support. If disabled, the EINJ is software simulated. DRAM EINJ No Trigger Avoid triggering DRAM errors with Hardware EINJ. If enabled, DRAM Hardware EINJ requests will only flip bits at the desired DRAM address and not force the hardware to immediately detect those bit flips.
  • Page 64 Processor OS-first Use this item to enable the operating system to prioritize processor errors through the AEST ACPU table. DDR CE Threshold This specifies the Number of DDR CEs to occur before using interrupt based notification to the OS rather than allowing the OS to poll for CEs. Processor CE Threshold This specifies the Number of processor CEs to occur before using interrupt based notification to the OS rather than allowing the OS to poll for CEs.

  • Page 65: Chipset Configuration

    ALTRAD8UD2-1L2Q 3.3.3 Chipset Configuration PCI Subsystem Settings Use this item to enable or disable PCI Subsystem Settings. Re-Size BAR Support If system has Resizable BAR capable PCIe Devices, this option enables or disables Resizable BAR support. SR-I0V Support If system has SR-I0V capable PCIe Devices, this option enables or disables Single Root IO Virtualization Support.
  • Page 66 PCIE5 Link Width Use this item to select PCIE5 Link Width. The default value is [Auto]-x16. PCIE7/PCIE6 Link Width Use this item to select PCIE7/PCIE6 Link Width. The default value for Altra CPU is [Auto]-x8x8, for Altra Max CPU is [Auto]-x16 . BCM57414 Link Width Use this item to select BCM57414 Link Width.

  • Page 67: Nvme Configuration

    ALTRAD8UD2-1L2Q 3.3.4 NVMe Configuration NVMe Configuration The NVMe Configuration displays the NVMe controller and Drive information. Launch NVMe driver Select this item to enable or disable launch NVMe driver.

  • Page 68: Acpi Configuration

    3.3.5 ACPI Configuration RTC Alarm Power On Configuration Use this item to set RTC Alarm Power On Time. RTC Alarm Power On Use this item to enable or disable RTC (Real Time Clock) to power on the system. RTC Alarm Date Use this item to set Date of RTC power on feature.

  • Page 69: Usb Configuration

    ALTRAD8UD2-1L2Q 3.3.6 USB Configuration USB Configuration The USB Configuration displays the USB Controllers and USB Device informations.

  • Page 70: Serial Port Console Redirection

    3.3.7 Serial Port Console Redirection COM1 Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, user can select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings, and specify how the computer and the host computer to which are connected exchange information.

  • Page 71: Flow Control

    ALTRAD8UD2-1L2Q Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200].
  • Page 72 Out-of-Band Mgmt Port Microsof t Windows Emergency Management Services (EMS) allows for remote management of a Windows Server OS through a serial port. Terminal Type EMS Use this item to select the preferred terminal emulation type for out-of-band management. It is recommended to select [VT-UTF8]. Option Description VT100...

  • Page 73: H/W Monitor

    ALTRAD8UD2-1L2Q 3.3.8 H/W Monitor In this section, it allows user to monitor the status of the hardware on the system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 74: Network Stack Configuration

    3.3.9 Network Stack Configuration Network Stack Enable UEFI network stack can prevents user from performing single-user network boots and network installation. If disabled, the host does not use the network interface. IPv4 PXE Support Enable IPv4 PXE Boot support. If disabled, IPv4 PXE Boot Option is not supported. IPv4 HTTP Support Enable IPv4 HTTP Boot support.

  • Page 75: Driver Health

    ALTRAD8UD2-1L2Q 3.3.10 Driver Health Interl (R) PRO/1000 Open Source 9.2.06 PCI-E Healthy This provides Health Status for the drivers and controllers. Driver At Handle F1C71318 Healthy This provides Health Status for the drivers and controllers. Driver At Handle F34CF818 Healthy...

  • Page 76: Tls Auth Configuration

    3.3.11 Tls Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Client Cert Configuration Enroll Cert Press <Enter> to enroll cert. Delete Cert Press <Enter> to delete cert.

  • Page 77: Instant Flash

    ALTRAD8UD2-1L2Q 3.3.12 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows user to update system UEFI without entering operating systems. Just save the new UEFI file to the USB flash drive, floppy disk or hard drive and launch this tool, then updating the UEFI only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 78: Server Mgmt

    3.4 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 90 seconds to initialize Host to BMC interfaces. Redfish Use this item to enable or disable AMI Redfish. FRB-2 Timer Use this item to enable or disable FRB-2 timer (POST timer).
  • Page 79 ALTRAD8UD2-1L2Q OS Wtd Timer Timeout Configure the OS Boot Watchdog Timer Expiration between 1 to 30 min value. If the OS Boot Watchdog Timer is disabled, this item is not available. OS Wtd Timer Policy Configure how the system should respond if the OS Boot Watchdog Timer expires. If the OS Boot Watchdog Timer is disabled, this item is not available.

  • Page 80: Bmc Network Configuration

    3.4.1 BMC Network Configuration Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If using a static IP address, toggle to [Yes], and the changes take effect after the system reboots. The default value is [No]. Configuration Address Source Select to configure BMC network parameters statically or dynamically(by BIOS or BMC).

  • Page 81: Ipv6 Support

    ALTRAD8UD2-1L2Q When [DHCP] or [Static] is selected, do NOT modify the BMC network settings on the IPMI web page. The default login information for the IPMI web interface is: Username: root Password: 0penBmc For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: https://www.asrockrack.com/support/faq.asp...

  • Page 82: System Event Log

    3.4.2 System Event Log SEL Components Change this item to enable ro disable event logging for error/progress codes during boot. Erase SEL Use this item to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL. Log EFI Status Codes Use this item to disable the logging of EFI Status Codes or log only error code or only progress code or both.

  • Page 83: Bmc Tools

    ALTRAD8UD2-1L2Q 3.4.3 BMC Tools Restore AC Power Loss Select the power state after a power failure. If [Power Off] is selected, the power will remain off when the power recovers. If [Power On] is selected, the system will start to boot up when the power recovers.

  • Page 84: Security

    3.5 Security This section allows user to set or change the supervisor/user password for the system. For the user password also can clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility. Leave it blank and press enter to remove the password.

  • Page 85: Key Management

    ALTRAD8UD2-1L2Q 3.5.1 Key Management In this section, expert users can modify Secure Boot Policy variables without full authenti- cation. Factory Key Provision Allow to provision factory default Secure Boot keys when System is in Setup Mode. Install Default Secure Boot Keys Please install default secure boot keys if it’s the first time to use secure boot.
  • Page 86 Remove 'UEFI CA' from DB Device Guard ready system must not list ‘Microsoft UEFI CA’ Certificate in Autho- rized Signature database (db). Restore DB Defaults Restore DB variable to factory defaults. Platform Key (PK) Enroll Factory Defaults or load certificates from a file: 1.

  • Page 87: Authorized Signatures

    ALTRAD8UD2-1L2Q Authorized Signatures Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed Forbidden Signatures Enroll Factory Defaults or load certificates from a file: 1.

  • Page 88: Osrecovery Signatures

    2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed OsRecovery Signatures Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3.

  • Page 89: Boot

    ALTRAD8UD2-1L2Q 3.6 Boot In this section, it will display the available devices on the system for user to configure the boot settings and the boot priority. Boot Option #1 Use this item to set the system boot order. Boot Option #2 Use this item to set the system boot order.

  • Page 90: Uefi Application Boot Priorities

    UEFI Application Boot Priorities Specifies the Boot Device Priority sequence from available UEFI Application. Setup Prompt Timeout Configure the number of seconds to wait for the UEFI setup utility. Bootup NumLock State If this item is set to [On], it will automatically activate the Numeric Lock function after boot-up.

  • Page 91: Exit Screen

    ALTRAD8UD2-1L2Q 3.7 Exit Screen Save Changes and Exit When selecting this item, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY. Discard Changes and Exit When selecting this item, the following message “Discard changes and exit setup?”...

  • Page 92: Chapter 4 Software Support

    4.3 Contact Information Contact ASRock Rack or want to know more about ASRock Rack, welcome to visit ASRock Rack’s website at http://www.ASRockRack.com; or contact the dealer for further information.

  • Page 93: Chapter 5 Troubleshooting

    ALTRAD8UD2-1L2Q Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot the system. Always unplug the power cord before adding, removing or changing any hardware compo- nents. Failure to do so may cause physical injuries and motherboard damages.
  • Page 94 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether the power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to the problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 95: Technical Support Procedures

    ALTRAD8UD2-1L2Q 5.2 Technical Support Procedures If the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Contact information 2. Model name, BIOS version and problem type. 3. System configuration. 4. Problem description. Contact ASRock Rack’s technical support at: http://www.asrockrack.com/support/tsd.asp...

  • Page 96: Contact Information

    Contact Information If it needs to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or contact the dealer for further information. For technical questions, please submit a support request form at https://event.asrockrack.com/tsd.asp...
