ASROCK Rack B650D4U3 User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
B650D4U3
B650D4U3-2L2Q/BCM
User Manual
Version 1.0
Published November 2023
Copyright©2023 ASRock Rack INC. All rights reserved.

Advertisement

loading
Need help?

Need help?

Do you have a question about the B650D4U3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ASROCK Rack B650D4U3

Summary of Contents for ASROCK Rack B650D4U3

  • Page 1 B650D4U3 B650D4U3-2L2Q/BCM User Manual Version 1.0 Published November 2023 Copyright©2023 ASRock Rack INC. All rights reserved.

  • Page 2: Copyright Notice

    In no event shall ASRock Rack, its directors, officers, employees, or agents be liable for any indirect, special, incidental, or consequential damages (including damages for loss of...
  • Page 3 ASRock Rack follows the green design concept to design and manufacture our products, and makes sure that each stage of the product life cycle of ASRock Rack product is in line with global environmental regulations. In addition, ASRock Rack disclose the relevant in- formation based on regulation requirements.

  • Page 4: Table Of Contents

    Contents Chapter 1 Introduction Package Contents Specifications Unique Features Motherboard Layout Onboard LED Indicators I/O Panel Block Diagram Chapter 2 Installation Screw Holes Pre-installation Precautions Installing the CPU Installing the Heatsink Installing Memory Modules (DIMM) Expansion Slots (PCI Express Slots) Jumper Setup Onboard Headers and Connectors Dr.
  • Page 5 3.1.1 UEFI Menu Bar 3.1.2 Navigation Keys Main Screen Advanced Screen 3.3.1 CPU Configuration 3.3.2 Chipset Configuration 3.3.3 Storage Configuration 3.3.4 NVMe Configuration 3.3.5 ACPI Configuration 3.3.6 USB Configuration 3.3.7 Super IO Configuration 3.3.8 Serial Port Console Redirection 3.3.9 H/W Monitor 3.3.10 PCI Subsystem Settings 3.3.11 AMD CBS 3.3.12 Trusted Computing...
  • Page 6 3.4.2 Key Management Server Mgmt 3.5.1 BMC Network Configuration 3.5.2 DNS Configuration 3.5.3 System Event Log 3.5.4 BMC Tools Boot Screen Exit Screen Chapter 4 Software Support Download and Install Operating System Download and Install Software Drivers Contact Information Chapter 5 Troubleshooting Troubleshooting Procedures Technical Support Procedures Returning Merchandise for Service...

  • Page 7: Chapter 1 Introduction

    In case any modifications of this manual occur, the updated version will be available on ASRock Rack website without further notice. Find the latest memory and CPU support lists on ASRock Rack website as well. ASRock Rack’s Website: www.ASRockRack.com About this motherboard technical support, please visit the website for specific information http://www.asrockrack.com/support/...

  • Page 8: Specifications

    1.2 Specifications B650D4U3, B650D4U3-2L2Q/BCM Physical Status Form Factor Micro-ATX Dimension 9.6" x 9.6" (244mm x 244mm) Processor System Supports AMD Ryzen 7000 Series Processors Socket 1 Socket AM5 (LGA1718) Thermal Design 120W (Air) / 170W (Liquid) Power (TDP) Chipset AMD B650E...
  • Page 9 B650D4U3 B650D4U3-2L2Q/BCM Controller/Hub AMD B650E, CPU External: Connectors/ Headers 4 Type-A (USB3.2 Gen1) Internal: 1 header (19-pin, 2 USB3.2 Gen1) 1 header (9-pin, 2 USB2.0) Graphics ASPEED AST2600: Controller 1 DB15 (VGA) AMD Processors with Graphics: 1 HDMI Security 1 (13-pin, SPI)
  • Page 10 System Panel 1 (9-pin): power switch, reset switch, system power LED, HDD Header activity LED SFP+1/SFP+2 LED B650D4U3-2L2Q/BCM: Header B650D4U3: Speaker Header Fan Header 7 (6pin) co-lay 7 (4-pin) Buzzer TPM Header 1 (13-pin, SPI) 80 Debug Port Header SMbus Header...
  • Page 11 B650D4U3 B650D4U3-2L2Q/BCM This motherboard supports Wake from on Board LAN. To use this function, please make sure that the “Wake on Magic Packet from power off state” is enabled in Device Manager > Intel® Ethernet Connection > Power Management. And the “PCI Devices Power On” is enabled in UEFI SETUP UTILITY >...

  • Page 12: Unique Features

    . With this utility, press the <F6> key during the POST or the <F2> key to enter into the BIOS setup menu to access ASRock Rack Instant Flash. Just launch this tool and save the new BIOS file to the USB flash drive, floppy disk or hard drive, then update the BIOS only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 13: Motherboard Layout

    24.4 cm (9.6 in) PSU_SMB1 BAT1 ATX12V1 ATX12V2 ATXPWR1 CLRCMOS1 DDR5_B1 FAN1 DDR5_B2 NUT110_2 FAN7 DDR5_A1 DDR5_A2 FAN6 NUT80_2 (B650D4U3-2L2Q/BCM only) SFP+1 SFP_CON1 CPU1 SFP+2 SFP_CON2 BCM57502 UID1 LED_SFP+1_2 PWM_CFG1 M2_2 TPM_BIOS_PH1 (B650D4U3 only) PCIE7 BIOS B650D4U3 B650D4U3-2L2Q/BCM PCIE6 ASPEED...
  • Page 14 PCI Express 5.0 x16 Card Slot (PCIE6) PCI Express 4.0 x1 Card Slot (PCIE7) M.2 Socket (M2_2) (Type 2280/22110) ( B650D4U3 only) Front LAN LED Connector (LED_SFP+1_2) ( B650D4U3-2L2Q/BCM only) *For DIMM installation and configuration instructions, please see p.21 (Installation of Memory Modules...

  • Page 15: Onboard Led Indicators

    B650D4U3 B650D4U3-2L2Q/BCM 1.5 Onboard LED Indicators The layout below is only for B650D4U3-2L2Q/BCM reference, both B650D4U3 Series LED locations are the same.
  • Page 16 Item Status Description SB_PWR1 Green STB PWR ready FAN_LED1 Amber FAN1 failed FAN_LED7 Amber FAN7 failed FAN_LED6 Amber FAN6 failed FAN_LED2 Amber FAN2 failed FAN_LED4 Amber FAN4 failed FAN_LED3 Amber FAN3 failed FAN_LED5 Amber FAN5 failed BMC_LED1 Green BMC heartbeat LED...

  • Page 17: I/O Panel

    No. Description No. Description VGA Port (VGA) HDMI Port (HDMI1) 25G SFP28 Port (SFP+1, shared NIC)*** Serial Port (COM1) B650D4U3-2L2Q/BCM only) 25G SFP28 Port (SFP+2, shared NIC)*** USB 3.2 Gen1 Ports (USB3_1_2) B650D4U3-2L2Q/BCM only) LAN RJ-45 Port (IPMI_LAN)* UID Switch (UID1) USB 3.2 Gen1 Port (USB3_3)
  • Page 18 ***There is an LED on each side of SFP28 LAN port. Please refer to the table below for the LAN port LED indications. ACT/LINK LED SPEED LED LAN Port SFP28 LAN Port (SFP+1, SFP+2) LED Indications (B650D4U3-2L2Q/BCM only) Activity / Link LED Speed LED Status Description Status...

  • Page 19: Block Diagram

    B650D4U3 B650D4U3-2L2Q/BCM 1.7 Block Diagram B650D4U3:...
  • Page 20 B650D4U3-2L2Q/BCM:...

  • Page 21: Chapter 2 Installation

    B650D4U3 B650D4U3-2L2Q/BCM Chapter 2 Installation This is a micro-ATX form factor (9.6” x 9.6”, 24.4 cm x 24.4 cm) motherboard. Before installing the motherboard, study the configuration of the chassis to ensure that the motherboard fits into it. Make sure to unplug the power cord before installing or removing the motherboard. Failure to do so may cause physical injuries and motherboard damages.

  • Page 22: Installing The Cpu

    2.3 Installing the CPU 1. Before inserting the 1718-Pin CPU into the socket, please check if the PnP cap is on the socket, if the CPU surface is unclean, or if there are any bent pins in the socket. Do not force to insert the CPU into the socket if above situation is found.
  • Page 23 B650D4U3 B650D4U3-2L2Q/BCM Carefully place the CPU in as flat as possible. Do not drop it.
  • Page 24 Make sure the CPU is aligned with the socket before locking it into place. Make sure the black cover plate is always in place until it pops off when closing the socket lever. Please save the cover if the processor is removed. The cover must be placed when returning the motherboard for after service.

  • Page 25: Installing The Heatsink

    B650D4U3 B650D4U3-2L2Q/BCM 2.4 Installing the Heatsink After installing the CPU into this motherboard, it is necessary to install a larger heatsink and cooling fan to dissipate heat. It also needs to spray thermal grease between the CPU and the heatsink to improve heat dissipation. Make sure that the CPU and the heatsink are securely fastened and in good contact with each other.

  • Page 27: Installing Memory Modules (Dimm)

    B650D4U3 B650D4U3-2L2Q/BCM 2.5 Installing Memory Modules (DIMM) This motherboard provides four 288-pin DDR5 (Double Data Rate 5) DIMM slots, and supports Dual Channel Memory Technology. 1. For dual channel configuration, it always needs to install identical (the same brand, speed, size and chip-type) DDR5 DIMM pairs.
  • Page 28 The DIMM only fits in one correct orientation. It will cause permanent damage to the motherboard and the DIMM if forcing the DIMM into the slot at incorrect orientation.

  • Page 29: Expansion Slots (Pci Express Slots)

    B650D4U3 B650D4U3-2L2Q/BCM 2.6 Expansion Slots (PCI Express Slots) There are 3 PCI Express slots on this motherboard. PCIE slots: PCIE4 (PCIE 4.0 x4 slot, from FCH) is used for PCI Express x4 lane width cards. PCIE6 (PCIE 5.0 x16 slot, from CPU) is used for PCI Express x16 lane width cards.

  • Page 30: Jumper Setup

    2.7 Jumper Setup The illustration shows how jumpers are setup. When the jumper cap is placed on the pins, the jumper is “Short”. If no jumper cap is placed on the pins, the jumper is “Open”. The illustration shows a 3-pin jumper whose pin1 and pin2 are “Short” when a jumper cap is placed on these 2 pins.

  • Page 31: Onboard Headers And Connectors

    B650D4U3 B650D4U3-2L2Q/BCM 2.8 Onboard Headers and Connectors Onboard headers and connectors are NOT jumpers. Do NOT place jumper caps over these headers and connectors. Placing jumper caps over the headers and connectors will cause permanent damage to the motherboard. System Panel Header...
  • Page 32 Auxiliary Panel Header This header supports multiple (18-pin AUX PANEL1) functions on the front panel, (see p.7, No. 18) including the front panel SMB, internet status indicator and chassis intrusion pin. A. Front panel SMBus connecting pin (6-1 pin FPSMB) This header allows user to connect SMBus (System Management Bus) equipment.
  • Page 33 B650D4U3 B650D4U3-2L2Q/BCM USB 3.2 Gen1 Header Besides two default USB 3.2 IntA_PA_D+ IntA_PA_D- (19-pin USB3_5_6) Gen1 ports on the I/O panel, IntA_PA_SSTX+ IntA_PA_SSTX- (see p.7, No. 21) there is one USB 3.2 Gen1 IntA_PA_SSRX+ header on this motherboard. IntA_PA_SSRX- Vbus This USB 3.2 Gen1 header can...
  • Page 34 ATX Power Connector This motherboard provides a (24-pin ATXPWR1) 24-pin ATX power connector. (see p.7, No. 7) To use a 20-pin ATX power supply, please plug it along Pin 1 and Pin 13. ATX 12V Power This motherboard provides Connectors two 8-pin ATX 12V power (8-pin ATX12V1) connectors.
  • Page 35 6.0 Gb/s data transfer (SATA_2) rate. SATA_2 SATA_0 (SATA_3) (see p.7, No. 15) Front LAN LED This 4-pin connector is used SFP+2_LINK LED_PWR Connector for the front LAN status (LED_SFP+1_2) indicator. (see p.7, No. 33) SFP+1_LINK LED_PWR (B650D4U3-2L2Q/BCM only)

  • Page 36: Dr. Debug

    2.9 Dr. Debug Dr. Debug is used to provide code information, which makes troubleshooting even easier. Please see the diagrams below for reading the Dr. Debug codes. Code Description 0x10 PEI_CORE_STARTED 0x11 PEI_CAR_CPU_INIT 0x15 PEI_CAR_NB_INIT 0x19 PEI_CAR_SB_INIT 0x31 PEI_MEMORY_INSTALLED 0x32 PEI_CPU_INIT 0x33 PEI_CPU_CACHE_INIT...
  • Page 37 B650D4U3 B650D4U3-2L2Q/BCM 0x63 DXE_CPU_INIT 0x68 DXE_NB_HB_INIT 0x69 DXE_NB_INIT 0x6A DXE_NB_SMM_INIT 0x70 DXE_SB_INIT 0x71 DXE_SB_SMM_INIT 0x72 DXE_SB_DEVICES_INIT 0x78 DXE_ACPI_INIT 0x79 DXE_CSM_INIT 0x90 DXE_BDS_STARTED 0x91 DXE_BDS_CONNECT_DRIVERS 0x92 DXE_PCI_BUS_BEGIN 0x93 DXE_PCI_BUS_HPC_INIT 0x94 DXE_PCI_BUS_ENUM 0x95 DXE_PCI_BUS_REQUEST_RESOURCES 0x96 DXE_PCI_BUS_ASSIGN_RESOURCES 0x97 DXE_CON_OUT_CONNECT 0x98 DXE_CON_IN_CONNECT...
  • Page 38 0x99 DXE_SIO_INIT 0x9A DXE_USB_BEGIN 0x9B DXE_USB_RESET 0x9C DXE_USB_DETECT 0x9D DXE_USB_ENABLE 0xA0 DXE_IDE_BEGIN 0xA1 DXE_IDE_RESET 0xA2 DXE_IDE_DETECT 0xA3 DXE_IDE_ENABLE 0xA4 DXE_SCSI_BEGIN 0xA5 DXE_SCSI_RESET 0xA6 DXE_SCSI_DETECT 0xA7 DXE_SCSI_ENABLE 0xA8 DXE_SETUP_VERIFYING_PASSWORD 0xA9 DXE_SETUP_START 0xAB DXE_SETUP_INPUT_WAIT 0xAD DXE_READY_TO_BOOT 0xAE DXE_LEGACY_BOOT...
  • Page 39 B650D4U3 B650D4U3-2L2Q/BCM 0xAF DXE_EXIT_BOOT_SERVICES 0xB0 RT_SET_VIRTUAL_ADDRESS_MAP_BEGIN 0xB1 RT_SET_VIRTUAL_ADDRESS_MAP_END 0xB2 DXE_LEGACY_OPROM_INIT 0xB3 DXE_RESET_SYSTEM 0xB4 DXE_USB_HOTPLUG 0xB5 DXE_PCI_BUS_HOTPLUG 0xB6 DXE_NVRAM_CLEANUP 0xB7 DXE_CONFIGURATION_RESET 0xF0 PEI_RECOVERY_AUTO 0xF1 PEI_RECOVERY_USER 0xF2 PEI_RECOVERY_STARTED 0xF3 PEI_RECOVERY_CAPSULE_FOUND 0xF4 PEI_RECOVERY_CAPSULE_LOADED 0xE0 PEI_S3_STARTED 0xE1 PEI_S3_BOOT_SCRIPT 0xE2 PEI_S3_VIDEO_REPOST...
  • Page 40 0xE3 PEI_S3_OS_WAKE 0x50 PEI_MEMORY_INVALID_TYPE 0x53 PEI_MEMORY_NOT_DETECTED 0x55 PEI_MEMORY_NOT_INSTALLED 0x57 PEI_CPU_MISMATCH 0x58 PEI_CPU_SELF_TEST_FAILED 0x59 PEI_CPU_NO_MICROCODE 0x5A PEI_CPU_ERROR 0x5B PEI_RESET_NOT_AVAILABLE 0xD0 DXE_CPU_ERROR 0xD1 DXE_NB_ERROR 0xD2 DXE_SB_ERROR 0xD3 DXE_ARCH_PROTOCOL_NOT_AVAILABLE 0xD4 DXE_PCI_BUS_OUT_OF_RESOURCES 0xD5 DXE_LEGACY_OPROM_NO_SPACE 0xD6 DXE_NO_CON_OUT 0xD7 DXE_NO_CON_IN...
  • Page 41 B650D4U3 B650D4U3-2L2Q/BCM 0xD8 DXE_INVALID_PASSWORD 0xD9 DXE_BOOT_OPTION_LOAD_ERROR 0xDA DXE_BOOT_OPTION_FAILED 0xDB DXE_FLASH_UPDATE_FAILED 0xDC DXE_RESET_NOT_AVAILABLE 0xE8 PEI_MEMORY_S3_RESUME_FAILED 0xE9 PEI_S3_RESUME_PPI_NOT_FOUND 0xEA PEI_S3_BOOT_SCRIPT_ERROR 0xEB PEI_S3_OS_WAKE_ERROR...

  • Page 42: Unit Identification Purpose Led/Switch

    2.10 Unit Identification purpose LED/Switch With the UID button, user can locate the server working on from behind a rack of servers. Unit Identification When the UID button on the purpose LED/Switch front or rear panel is pressed, (UID1) the front/rear UID blue LED indicator will be truned on.

  • Page 43: Dual Lan And Teaming Operation Guide

    B650D4U3 B650D4U3-2L2Q/BCM 2.11 Dual LAN and Teaming Operation Guide Dual LAN with Teaming enabled on this motherboard allows two single connections to act as one single connection for twice the transmission bandwidth, making data transmission more effective and improving the quality of transmission of distant images. Fault tolerance on the dual LAN network prevents network downtime by transferring the workload from a failed port to a working port.

  • Page 44: Ssd Module Installation Guide

    The M.2 Socket (M2_1, Key M) supports type 2242/2280 M.2 PCI Express module up to Gen5 x4 (32GT/s x4). Another M.2 Socket (M2_2, Key M) supports type 2280/22110 M.2 PCI Express module up to Gen4 x4 (16GT/s x4) (for B650D4U3 only) Installing the M.2 SSD Module Step 1 Prepare a M.2 SSD module and the...
  • Page 45 B650D4U3 B650D4U3-2L2Q/BCM Step 3 Move the standoff based on the module type and length. Skip Step 3 and 4 and go straight to Step 5 if using the default nut. Otherwise, release the standoff by hand. Step 4 Peel off the yellow protective film on the nut to be used.

  • Page 46: Chapter 3 Uefi Setup Utility

    Chapter 3 UEFI Setup Utility 3.1 Introduction This section explains how to use the UEFI SETUP UTILITY to configure the system. The UEFI chip on the motherboard stores the UEFI SETUP UTILITY. Run the UEFI SETUP UTILITY when starting up the computer. Please press <F2> or <Del> during the Power- On-Self-Test (POST) to enter the UEFI SETUP UTILITY;...

  • Page 47: Navigation Keys

    B650D4U3 B650D4U3-2L2Q/BCM 3.1.2 Navigation Keys Please check the following table for the function description of each navigation key. Navigation Key(s) Function Description Moves cursor left or right to select Screens Moves cursor up or down to select items + / - To change option for the selected items <Tab>...

  • Page 48: Main Screen

    3.2 Main Screen Once entering the UEFI SETUP UTILITY, the Main screen will appear and display the sys- tem overview. The Main screen provides system overview information and allows user to set the system time and date.

  • Page 49: Motherboard Information

    B650D4U3 B650D4U3-2L2Q/BCM 3.2.1 Motherboard Information Press [Enter] to view the information of the motheboard. 3.2.2 Processor Information Press [Enter] to view the information of the processor.

  • Page 50: Memory Information

    3.2.3 Memory Information Press [Enter] to view the information of the memory.

  • Page 51: Advanced Screen

    B650D4U3 B650D4U3-2L2Q/BCM 3.3 Advanced Screen In this section, set the configurations for the following items: CPU Configuration, Chipset Configuration, Storage Configuration, NVMe Configuration, ACPI Configuration, USB Configuration, Super IO Configuration, Serial Port Console Redirection, H/W Monitor, PCI Subsystem Settings, AMD CBS, Trusted Computiong, Network Stack Configuration, Driver Health, Tls Auth Configuration, AMD PBS, AMD Overclocking and Instant Flash.

  • Page 52: Cpu Configuration

    3.3.1 CPU Configuration PSS Support Use this item to enable or disable the generation of ACPI _PPC, _PSS, and _PCT objects. NX Mode Use this item to enable or disable No-execute page protection Function. SVM Mode Use this item to enable or disable CPU Virtualization.

  • Page 53: Chipset Configuration

    B650D4U3 B650D4U3-2L2Q/BCM 3.3.2 Chipset Configuration SPI/fTPM TPM Switch To select 0:AMD CPU fTPM or 2: SPI TPM.

  • Page 54: Storage Configuration

    3.3.3 Storage Configuration SATA Hot Plug Use this item to enable or disable SATA Hot Plug.

  • Page 55: Nvme Configuration

    B650D4U3 B650D4U3-2L2Q/BCM 3.3.4 NVMe Configuration NVMe Configuration The NVMe Configuration displays the NVMe controller and Drive information.

  • Page 56: Acpi Configuration

    3.3.5 ACPI Configuration PCIE Devices Power On This Allows the system to be waked up by a PCIE device and enable wake on LAN. RTC Alarm Power On This Allows the system to be waked up by the real time clock alarm. Set it to By OS to let it be handled by the operating system.

  • Page 57: Usb Configuration

    B650D4U3 B650D4U3-2L2Q/BCM 3.3.6 USB Configuration USB Configuration The USB Configuration displays the USB Controllers and USB Devices informations.

  • Page 58: Super Io Configuration

    3.3.7 Super IO Configuration Serial Port 1 Configuration Use this item to set parameters of Serial Port 1 (COM1). Serial Port Use this item to enable or disable the serial port. Serial Port Address Use this item to select an optimal setting for Super IO device. SOL Configuration Use this item to set parameters of SOL.

  • Page 59: Serial Port Console Redirection

    B650D4U3 B650D4U3-2L2Q/BCM 3.3.8 Serial Port Console Redirection COM1 / SOL Console Redirection Use this option to enable or disable Console Redirection. If this item is set to Enabled, select a COM Port to be used for Console Redirection. Console Redirection Settings Use this option to configure Console Redirection Settings, and specify how the computer and the host computer to which are connected exchange information.

  • Page 60: Flow Control

    Bits Per Second Use this item to select the serial port transmission speed. The speed used in the host computer and the client computer must be the same. Long or noisy lines may require lower transmission speed. The options include [9600], [19200], [38400], [57600] and [115200]. Data Bits Use this item to set the data transmission size.
  • Page 61 B650D4U3 B650D4U3-2L2Q/BCM Out-of-Band Mgmt Port Microsof t Windows Emergency Management Services (EMS) allows for remote management of a Windows Server OS through a serial port. Terminal Type EMS Use this item to select the preferred terminal emulation type for out-of-band management.

  • Page 62: H/W Monitor

    3.3.9 H/W Monitor In this section, it allows user to monitor the status of the hardware on the system, includ- ing the parameters of the CPU temperature, motherboard temperature, CPU fan speed, chassis fan speed, and the critical voltage.

  • Page 63: Pci Subsystem Settings

    B650D4U3 B650D4U3-2L2Q/BCM 3.3.10 PCI Subsystem Settings Re-Size BAR Support If system has Resizable BAR capable PCIe Devices, this option Enables/Disables Resizable BAR support. SR-IOV Support If system has SR-IOV capable PCIe Devices, this option Enables/Disables Single Root IO Virtualization Support.

  • Page 64: Amd Cbs

    3.3.11 AMD CBS CPU Common Options Use this item to configure CPU common options. DF Common Options Use this item to configure DF common options. UMC Common Options Use this item to configure UMC common options. NBIO Common Options Use this item to configure NBIO common options. FCH Common Options Use this item to configure FCH common options.

  • Page 65: Trusted Computing

    B650D4U3 B650D4U3-2L2Q/BCM 3.3.12 Trusted Computing NOTE: Options vary depending on the version of the connected TPM module. Security Device Support Enable to activate Trusted Platform Module (TPM) security for the hard diskdrives. SHA256 PCR Bank Use this item to enable or disable SHA256 PCR Bank SHA384 PCR Bank Use this item to enable or disable SHA384 PCR Bank.

  • Page 66: Device Select

    TPM 2.0 InterfaceType Select the Communication Interface to TPM 2.0 Device Device Select Use this item to select the TPM device to be supported. TPM 1.2 will restrict support to TPM 1.2 devices. TPM 2.0 will restrict support to TPM 2.0 devices. Auto will support both with the default set to TPM 2.0 devices.

  • Page 67: Network Stack Configuration

    B650D4U3 B650D4U3-2L2Q/BCM 3.3.13 Network Stack Configuration Network Stack Enable UEFI network stack can prevents you from performing single-user network boots and network installation. If disabled, the host does not use the network interface. IPv4 PXE Support Enable IPv4 PXE Boot support. If disabled, IPv4 PXE Boot Option is not supported.

  • Page 68: Driver Health

    3.3.14 Driver Health Intel(R) PRO/1000 9.8.09 PCI-E Healthy Provides Health Status for the Drivers/Controllers. Broadcom NXE Gigabit Ethernet Driver Healthy Provides Health Status for the Drivers/Controllers. Broadcom NXE Gigabit Ethernet Driver Healthy Provides Health Status for the Drivers/Controllers. AMD GOP X64 Rel Driver Rev.3.4.6OCt 18 2022.05:39:00 Healthy Provides Health Status for the Drivers/Controllers.

  • Page 69: Tls Auth Configuration

    B650D4U3 B650D4U3-2L2Q/BCM 3.3.15 Tls Auth Configuration Server CA Configuration Press <Enter> to configure Server CA. Client Cert Configuration Enroll Cert Press <Enter> to enroll cert. Delete Cert Press <Enter> to delete cert.

  • Page 70: Amd Pbs

    3.3.16 AMD PBS AMD Firmware Version Show all of AMD Firmware Version. Graphics Features Graphics Features - HG, DGPU Features, BOMAC0. Platform Firmware Update Use this item to process Platform Firmware Update Discrete USB4 Features Discrete USB4 Features - PCIe resource, D3 support, Native USB4 suport and so on. Unused GPP Clocks Off Turn Unused GPP Clocks Off.
  • Page 71 B650D4U3 B650D4U3-2L2Q/BCM PCIe/GFX Lanes Configuration Use this item to configure J10 Slot PCIe Lanes. UCSI Support Enable for UCSI (USB Type-C Connector System Software Interface). MITT/WITT Selection Use this item to configure MITT/WITT Selection ACP Power Gating Use this item to enable or disable ACP Power Gating.
  • Page 72 Thunderbolt in SLOT Use this item to select Thunderbolt Slot. Legacy/Native RTD3 Use this item to select Thunderbolt Legacy/Native/RTD3 Mode. Thunderbolt L1SS Support Use this item to select Thunderbolt PCIE L1SS Support. Thunderbolt Wake Up Command Use this item to select Thunderbolt Wake Up Command. VDDIO_MEM_S3 Voltage Control Use this item to configure voltage control for VDDIO_MEM_S3 with Auto or Manual selections.

  • Page 73: Amd Overclocking

    B650D4U3 B650D4U3-2L2Q/BCM 3.3.17 AMD Overclocking The AMD Overclocking menu accesses options for configuring CPU frequency and voltage.

  • Page 74: Instant Flash

    3.3.18 Instant Flash Instant Flash is a UEFI flash utility embedded in Flash ROM. This convenient UEFI update tool allows user to update system UEFI without entering operating systems first like MS- ® DOS or Windows . Just save the new UEFI file to the USB flash drive, floppy disk or hard drive and launch this tool, then update the UEFI only in a few clicks without preparing an additional floppy diskette or other complicated flash utility.

  • Page 75: Security

    B650D4U3 B650D4U3-2L2Q/BCM 3.4 Security This section allows user to set or change the supervisor/user password for the system. For the user password item is allowed user to clear it. Supervisor Password Set or change the password for the administrator account. Only the administrator has authority to change the settings in the UEFI Setup Utility.

  • Page 76: Install Default Secure Boot Keys

    3.4.1 Install Default Secure Boot Keys Please install default secure boot keys if it is the first time to use secure boot. Select Clear Secure Boot keys item to clear the asigned secure boot keys.

  • Page 77: Key Management

    B650D4U3 B650D4U3-2L2Q/BCM 3.4.2 Key Management In this section, expert users can modify Secure Boot Policy variables without full authentica- tion. Factory Key Provision Install factory default Secure Boot Keys after the platform reset and while the system is in Setup mode.
  • Page 78 Platform Key (PK) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed Key Exchange Keys (KEK) Enroll Factory Defaults or load certificates from a file: 1.
  • Page 79 B650D4U3 B650D4U3-2L2Q/BCM 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed Forbidden Signatures (dbx) Enroll Factory Defaults or load certificates from a file: 1. Public Key Certificate in: a) EFI_SIGNATURE_LIST b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2.
  • Page 80 b) EFI_CERT_X509 (DER) c) EFI_CERT_RSA2048 (bin) d) EFI_CERT_SHAXXX 2. Authenticated UEFI Variable 3. EFI PE/COFF Image(SHA256) Key Source: Factory, Modified, Mixed...

  • Page 81: Server Mgmt

    B650D4U3 B650D4U3-2L2Q/BCM 3.5 Server Mgmt Wait For BMC Wait For BMC response for specified time out. BMC starts at the same time when BIOS starts during AC power ON. It takes around 90 seconds to initialize Host to BMC interfaces.
  • Page 82 OS Wtd Timer Timeout Enter value between 1 to 30 min for OS Boot Watchdog Timer Expiration. Not available if OS BootWatchdog Timer is disabled. OS Wtd Timer Policy Use this item to configure how the system should respond if the OS Watchdog Timer expires.

  • Page 83: Bmc Network Configuration

    B650D4U3 B650D4U3-2L2Q/BCM 3.5.1 BMC Network Configuration Bonding Setting Use this item to enable or disable bonding. If you want to enable bonding, please enable all Lan channels first. Lan channel (Failover) Manual Setting IPMI LAN If [No] is selected, the IP address is assigned by DHCP. If you prefer using a static IP address, toggle to [Yes], and the changes take effect after the system reboots.

  • Page 84: Ipv6 Support

    When [DHCP] or [Static] is selected, do NOT modify the BMC network settings on the IPMI web page. The default login information for the IPMI web interface is: Username: admin Password: admin For more instructions on how to set up remote control environment and use the IPMI man- agement platform, please refer to the IPMI Configuration User Guide or go to the Support website at: http://www.asrockrack.com/support/faq.asp VLAN...

  • Page 85: Dns Configuration

    B650D4U3 B650D4U3-2L2Q/BCM 3.5.2 DNS Configuration Manual DNS Configuration Select this item to manual configure DNS. If [YES] is selected, configure the items below. DNS Service Select this item to enable or disable DNS Service Configuration. Host Name Settings Select this item to automatic or manual Host Name Settings.

  • Page 86: System Event Log

    3.5.3 System Event Log SEL Components Change this to enable ro disable event logging for error/progress codes during boot. Erase SEL Use this to choose options for earsing SEL. When SEL is Full Use this to choose options for reactions to a full SEL. Log EFI Status Codes Use this item to disable the logging of EFI Status Codes or log only error code or only progress code or both.

  • Page 87: Bmc Tools

    B650D4U3 B650D4U3-2L2Q/BCM 3.5.4 BMC Tools KCS Control Select this KCS interface state after POST end. If [Enabled] us selected, the BMC will remain KCS interface after POST stage. If [Disabled] is selected, the BMC will disable KCS interface after POST stage.

  • Page 88: Boot Screen

    3.6 Boot Screen In this section, it will display the available devices on the system for user to configure the boot settings and the boot priority. Boot Option #1/#2/#3/#4/#5/#6 Use this item to set the system boot order. UEFI Application Boot Priorities Use this item to specifies the Boot Device Priority sequence from available UEFI Application.

  • Page 89: Exit Screen

    B650D4U3 B650D4U3-2L2Q/BCM 3.7 Exit Screen Save Changes and Exit When selecting this option, the following message “Save configuration changes and exit setup?” will pop-out. Press <F10> key or select [Yes] to save the changes and exit the UEFI SETUP UTILITY.

  • Page 90: Boot Override

    Save Configuration in BMC Select this to save BIOS Configuration in BMC. Restore Configuration from BMC Select this to restore BIOS Configuration from BMC. Boot Override These items displays the available devices. Select an item to start booting from the selected device.

  • Page 91: Chapter 4 Software Support

    Please download the operating system from the OS manufacturer. Please refer to the OS documentation for more instructions. * Please download the Intel® SATA Floppy Image driver from the ASRock Rack’s website (www.asrockrack.com) to the USB drive while installing OS in SATA RAID mode.

  • Page 92: Chapter 5 Troubleshooting

    Chapter 5 Troubleshooting 5.1 Troubleshooting Procedures Follow the procedures below to troubleshoot the system. Always unplug the power cord before adding, removing or changing any hardware components. Failure to do so may cause physical injuries and damages to motherboard components. 1.
  • Page 93 1. Verify if the battery on the motherboard provides ~3VDC. Install a new battery if it does not. 2. Confirm whether the power supply provides adaquate and stable power. Other problems... 1. Try searching keywords related to the related problem on ASRock Rack’s FAQ page: http://www.asrockrack.com/support...

  • Page 94: Technical Support Procedures

    5.2 Technical Support Procedures If the problems are still unsolved, please contact ASRock Rack’s technical support with the following information: 1. Contact information 2. Model name, BIOS version and problem type. 3. System configuration. 4. Problem description. Contact ASRock Rack’s technical support at: http://www.asrockrack.com/support/tsd.asp...
  • Page 95 Contact Information If it needs to contact ASRock Rack or want to know more about ASRock Rack, you’re welcome to visit ASRock Rack’s website at http://www.asrockrack.com; or contact the dealer for further information. For technical questions, please submit a support request form at https://event.asrockrack.com/tsd.asp...

This manual is also suitable for:

B650d4u3-2l2q/bcm
