- Page 1 15-06-2020 Elev8 - Boardroom Tables EVTBT Pack A: ASSEMBLY 1 X TABLE TOP INSTRUCTIONS Elev8 Touch Pack B: Boardroom Table 1 x UNDER FRAME...
- Page 2 1 x Pozi screwdriver 1 x 4mm Allen key 1 x 5mm Allen key 1,2,3...
-
Page 3: Fittings Supplied
Please check that you have all the components PACK A: 1800mm = ED 1 x TABLE TOP 2000mm = ED 2400mm = ED PACK B: Leg pack code = ST-T-* 1 x UNDER FRAME FITTINGS SUPPLIED Size Size M6 x 16mm Ø4 x 25mm M10 x 16mm Ø5 x 20mm... - Page 4 ELEV8 TOUCH SINGLE DESK ASSEMBLY Step 1 Unpack your new height adjustable table frame and place on a flat surface. Step 2 Unfold both legs into their upright position. Step 3 Insert the 2 desktop end rails into the frame cross sections.
- Page 5 Step 4 Once inserted tighten the bolts at points A & B. Step 5 Attach both feet to the leg using the 8 x bolts provided. Step 6 Once attached, turn the desk over into its upright position. 2 person lift, do not attempt to do this without assistance as this could result in injury or damage to the product.
- Page 6 Step 7 Extend the frame to your desired length (1800 , 2000 2400 ). Once extended tighten all of the grub screws on the inside face of the cross section. Step 8 Now that your table frame is assembled you can proceed with the wiring.
- Page 7 Step 10 The table top controller can be positioned on either side of the desktop. Ensure that once the controller is connected to the control box the wires are neatly tucked into the cable management clips. Insert the wire protector into the recessed cut out in the top of the cross section and ensure the wire passes through the protector.
- Page 8 Step 12 Now position the table top onto the framework. Align the holes in the desktop end rails with the pre-drilled holes on the underside of the table top. Use the wood screws supplied to attach the top to the frame, if you are using a cordless/power driver make sure it is on a low torque setting.
- Page 9 Step 14 Your boardroom table is now ready to be connected to the mains outlet. Before you proceed with operating your new desk it is recommended that you perform a full reset of the controller to calibrate the height of each leg. This can be done using the following steps;...
-
Page 10: Normal Operation
Step 15 Upgrading to the Digital control unit Make sure that your height adjustable table is turned off and unplugged from the mains. Unplug the controller supplied with your height adjustable boardroom table and replace with the digital control unit. Fix this to your top using the wood screws provided. After connecting the digital control unit you will need to perform a reset. -
Page 11: Troubleshooting Information
Trouble shooting information Error Beeps- Protection Situation Solution Code Buzzer alert Press both up & down buttons at the same time for 3 seconds. Continue Press both up & down buttons at the same time for pressing the buttons until both 3 seconds.
