- Page 1 06-01-2022 Encore - Meeting Booth ENC-POD02 - ENC-POD04 - ENC-POD06 ENCOP-POD02 - ENCOP-POD04 - ENCOP-POD06 Pack 1: 2x Sofas ASSEMBLY INSTRUCTIONS Pack 2: 1x Linking Panel Encore Meeting Booths Pack 3: 1x Top Pack...
- Page 2 **mm **mm 1,2,3...
-
Page 3: Fittings Supplied
Please check that you have all the parts PACK 1: PACK 2: 2 x Sofas 1 x Link Panel 800 x 800mm = EN-BU-MOD01H 1300 x 1150mm = 1400 x 800mm = EN-BU-MOD02H EN-BU-LINK 2000 x 800mm = EN-BU-MOD03H PACK 3: 1 x Top Pack 600 x 700mm = EN-BU-1P-TOP 1200 x 700mm = EN-BU-2P-TOP... - Page 4 TILLY MEETING BOOTH ASSEMBLY Step 1 Unpack your new Encore booth seating unit and please recycle all packaging. Step 2 Locate and attach the leg aligning the holes located as shown using the M6 x 20(MF) / 50(WF)bolts. Step 3 Align the button fixtures and drop into place attaching each sofa one at a time.
- Page 5 Step 4 Locate the brackets to the fixing holes and attach using the M6 x 20mm bolts as shown. Step 5 Attach the top fixing bracket using the M6 x 50mm bolts as shown. Step 6 Attach the M6 x 20mm bolts as shown to secure the frame to the top.
