Connecting to the Exhaust System
(Required on Protector Work Station for
Remote Exhaust)
ATTENTION: The weight of the exhaust ductwork
!
system must be supported independently of the
enclosure superstructure or damage may occur.
The exhaust system should be installed by a qualified
HVAC contractor.
The exhaust connection on the remote Protector Work Station Enclosure
has been designed to accept a 2" x 10" (5.1cm x 25.4cm) nominal
transition adapter. See Chapter 7 for ordering accessory Transition
Adapters. Labconco manufactures transition adapters for either top or
bottom exhaust and for both 5" dia. hose or 6" dia. duct. Review Chapter
2 for remote blower and FilterMate Portable Exhauster exhaust
prerequisites and review Chapter 7 for ordering blower exhaust
equipment. For your convenience several exhaust options are shown in
Figures 3-2 and 3-3. Consult Labconco Customer Service should you
require help sizing your blower for the exhaust volume and system static
pressure loss.
! To ensure compatibility, the selected exhaust duct
material should match the enclosure, procedures and
chemical applications.
