1.5 Components
1.5.1 Features
Fiber Bulkhead (2 Places)
2.0 mm Narrow Key
Label Indicates PC or
APC Compatibility
Selector: 1310 nm,
1550 nm, or User
Bi-Stable Lock
Power Adjustment
1.5.2 Fiber Interface & Utility Panels
Page 4
Digital Display
Wavelength
Button
Knob
Figure 2
Output
Bulkhead
Connector Label
Figure 3
Front View
Fiber Interface Panel (Top View)
Chapter 1: Introduction
Utility
Panel
Rocker
Power
Switch
Input
Bulkhead
