POSIFLEX GT-7116A User Manual

POSIFLEX GT-7116A User Manual

Fanless touch pos terminal
Hide thumbs

Advertisement

Table of Contents

GT-7116A
Fanless Touch POS Terminal
User Manual
SOME IMPORTANT NOTES
FCC NOTES
This equipment has been tested and found to comply with the limits for a Class A digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference when the equipment is operated in a
commercial environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a residential
area is likely to cause harmful interference in which case the user will be required to correct
the interference at his own expense.
This device complies with part 15 of the FCC Rules. Operation is subject to the following
two conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
CE CLASS A WARNING
This equipment is compliant with Class A of CISPR 32. In a residential environment this
equipment may cause radio interference.
AVERTISSEMENT CE CLASSE A
Cet équipement est conforme à la classe A de CISPR 32. Dans un environnement
résidentiel, cet équipement peut provoquer des interférences radio.
WARRANTY LIMITS
Warranty will terminate automatically when the machine is opened by any person other than
the authorized technicians. The user should consult his/her dealer for the problem happening.
Warranty voids if the user does not follow the instructions in application of this merchandise.
The manufacturer is by no means responsible for any damage or hazard caused by improper
application.
LIMITES DE GARANTIE
La garantie prend fin automatiquement lorsque la machine est ouverte par une personne
autre que les techniciens autorisés. L'utilisateur doit consulter son revendeur pour le
problème qui se produit. La garantie s'annule si l'utilisateur ne suit pas les instructions
d'application de cette marchandise. Le fabricant n'est en aucun cas responsable de tout
dommage ou danger causé par une mauvaise application.
GT-7116A Ver. A0
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GT-7116A and is the answer not in the manual?

Questions and answers

Related Manuals for POSIFLEX GT-7116A

Summary of Contents for POSIFLEX GT-7116A

  • Page 1 L'utilisateur doit consulter son revendeur pour le problème qui se produit. La garantie s'annule si l'utilisateur ne suit pas les instructions d'application de cette marchandise. Le fabricant n'est en aucun cas responsable de tout dommage ou danger causé par une mauvaise application. GT-7116A Ver. A0...

  • Page 2: Battery Warning

    警告使用者 為避免電磁干擾，本產品不應安裝或使用於住宅環境。 SAFETY INSTRUCTIONS This equipment is not suitable for use in locations where children are likely to be present. CONSIGNES DE SÉ CURITÉ Cet équipement ne convient pas à une utilisation dans des lieux pouvant accueillir des enfants. WARNING Power cord shall be connected to a socket-outlet with earthing connection.
  • Page 3 Package Contents  GT-7116A 15.6” fanless touch terminal...……………...……………..(x1)  Power adapter………………………………………………………..(x1)  Power cord………………………………………………………….…(x1) Views of GT-7116A Front View P-Cap Touch Panel Rear View System Back Cover Attachment Bay Attachment Bay Stand Cover Cable Exit...
  • Page 4 Release Lever for System Back Cover Left-Side View Power Button Brightness Adjustment Button ＋ Brightness Adjustment Button － Status LED Indicator View of I/O Interface of GT-7116A Bottom Side View Switch for USB DB9 COM Port USB 2.0 Ports Type-C Port OTG Port USB 2.0 Port...
  • Page 5 Please do NOT press on the LCD panel while setting up the tilt angle. Installing Power Adapter and Cables for GT-7116A The following provides instructions required to install your cables. Lay the terminal with its rear facing towards you and tilt the screen all the way down.
  • Page 6 Remove the system back cover. If the system back cover is fire-resistant, first locate the screw as indicated in the figure, and then remove it. Screw for Fire-Resistant System Back Cover Hold down the release lever at the bottom of the system back cover and then pulling the cover outwards.
  • Page 7 For Type-C cable, locking the screw is required. Please tilt your screen monitor to flat type, and then you can fix the screw of the Type-C cable. Note: Please use the type-C cable certified/provided by Posiflex. Please DO NOT use the cables from other unknown sources.
  • Page 8 Neatly arrange the cables. Locate the cable holder inside the base as shown in the figure. Push down the lever to release if from the hook, pass the cable through cable holder, and then press down the lever again to lock it onto the hook. Cable holder For poweredUSB cables, please arrange the cables like the below picture.
  • Page 9 Make sure the cord can be held into place and passed through the cable exit after sliding back the stand cover. 10.1 Place back the sytem back cover. Make sure it is well locked into place with a click sound. 10.2 For the fire-resistant system back cover, please insert another screw into the screw hole indicated in the figure, and secure it.
  • Page 10 à la terre. Installing Optional Upgrade Kits and Peripherals GT-7116A is an expandable model which allows you to upgrade its own capacity by additionally installing multiple peripheral devices, such as magnetic stripe reader (MSR), fingerprint or iButton sensors, and 2 rear- mount POS monitor, according to your preference.
  • Page 11  Installing PoweredUSB or USB Hub for GT-7116A Please go through the below steps to complete the installation of PoweredUSB or USB hub. After tilting the screen all the way down, remove the system back cover. If the system back cover is fire-resistant, first locate the screw as indicated in the figure, and then remove it.
  • Page 12 For GT-470, the cable can be connected after installation. For GT-570, please connect the 5-pin USB cable and 6-pin power cable to the GT-570/580 module before installing the module. GT-470 GT-570 The installation steps are the same for GT-470 and GT-570. The following installation steps take GT-470 as an example.
  • Page 13 Install power adaptor extension cable, USB cable, and power adaptor for GT-470. Insert one end of the provided power adaptor extension cable to DC Input port of PoweredUSB hub and another end to DC- in power jack of the terminal. Insert mini-USB connector of the USB cable to PoweredUSB hub and another end to USB3.0 port of the terminal.

  • Page 14: Status Led Indicator

    Description System power OFF Green System standby Blue System power ON Powering ON/OFF GT-7116A Power Power ON the POS Terminal Button Press down the power button to power on the POS. Power OFF the POS Terminal In most cases, press the power button of the POS to power the system off.

  • Page 15: Operation Environment

    Operation Environment To prevent GT-7116A from overheating, it is suggested to position your terminal in a well-ventilated working environment. In doing so, please be advised to keep the POS terminal at least 25mm away from other devices to ensure the machine is properly cooled down and functioning normally.

  • Page 16: Outline Dimension

    USB port replicator (USB2.0 x 4 + RJ50 x 2, installed GT-570 in base stand) Outline Dimension ※ The product information and specifications are subject to change without prior notice. To get the detailed information on the GT-7116A, please check this model from Posiflex Global Website.
  • Page 17 Manufacturer: Posiflex Technology Inc. 4F-8F, No. 23, Datong St., Tucheng Dist., New Taipei City 236044, Taiwan Tel : +886 2 2268 5577 製造商資訊 振樺電子股份有限公司 新北市土城區大同街 23 號 4 樓~8 樓 電話：02-2268-5577...
