- Page 1 Quick-change pallet system VERO-S NSE mikro 49-13 Assembly and Operating Manual Translation of Original Operating Manual...
- Page 2 Best regards, Your SCHUNK team Customer Management Tel. +49-7572-7614-1300 Fax +49-7572-7614-1039 cmm@de.schunk.com Please read the operating manual in full and keep it close to the product. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691...
-
Page 3: Table Of Contents
4.4 Clamping pins SPA mikro 10, SPB mikro 10, SPC mikro 10 ....... 18 4.5 Pneumatic circuit diagram NSE mikro 49-13, NSE mikro 49-13-V10 ....20 4.6 Screw tightening torques ..............21 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... - Page 4 9 Seal kit and parts list ................26 10 Assembly drawing ................27 10.1 NSE mikro 49-13, NSE mikro 49-13-V10 ............. 27 11 Manufacturer certificate................. 28 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691...
-
Page 5: General
Denotes a hazard with a low degree of risk that, if not avoided, could result in a minor or moderate injury. CAUTION Information about avoiding material damage. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 6: Applicable Documents
(see catalog or data sheets when ordering separately) Clamping pins SPA mikro, SPB mikro, SPC mikro Indexing pin IXB V10 PAL mikro Fitting screw Protection cover SDE mikro 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 7: Basic Safety Notes
Structural changes should only be made with the written approval of SCHUNK. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 8: Spare Parts
Personnel must have read and understood the complete manual before beginning any work on the product. Observe country-specific accident prevention regulations and the general safety notes. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 9: Personal Protective Equipment
All work must only be performed by appropriately qualified personnel. Secure the system against accidental operation during all work. Use suitable assembly and transport equipment and take precautions to prevent jamming and crushing. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 10: Protection During Commissioning And Operation
Incorrect handling of disposal can make the product unsafe and lead to risks of environmental harm. Follow local regulations on dispatching product components for recycling or proper disposal. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 11: Fundamental Dangers
For modules with media transfer units, ensure the loading weight on the change interface is sufficient to ensure the surface of the interface is level with the module. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... - Page 12 Do not control the media transfer units until the device is clamped on the quick-change pallet systems. Take suitable protective measures to secure the danger zone. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691...
-
Page 13: Technical Data
If the quick-change pallet system is to be used outside the specified welding currents, please contact your SCHUNK contact person. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 14: Assembly
ð via the hose-free direct connection, OR ð via supply lines on the side M3 connections – unscrew set-screws – screw air connections Connect turbo connection if necessary. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 15: Fastening And Connection
One pressure pulse is sufficient to increase the force. The pressure line can be 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 16: Nse Mikro 49-13
O-rings Ø 2 x 1 and placement on a flat surface. ⑤ Air connection for monitoring "Clamping slide open". ⑥ Air connection for monitoring "Clamping slide closed". ⑦ Alternative ventilation method. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 17: Nse Mikro 49-13-V10
O-rings Ø 2 x 1 and placement on a flat surface. ⑥ Air connection for monitoring "Clamping slide open". ⑦ Air connection for monitoring "Clamping slide closed". ⑧ Alternative ventilation method. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 18: Clamping Pins Spa Mikro 10, Spb Mikro 10, Spc Mikro 10
SPC mikro 10 0436630 > 5 > 8 > 5 > 6 * The length of the inserted thread must not be lower than the "G" dimension! 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... - Page 19 Positioning direction, perpendicular to the positioning axis Select the positioning axis with the greatest possible distance 1 clamping area 3 clamping areas 2 clamping areas 4 clamping areas 6 clamping areas 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691...
-
Page 20: Pneumatic Circuit Diagram Nse Mikro 49-13, Nse Mikro 49-13-V10
Slide monitoring for module "CLAMPED" Actuation of the quick-change pallet system with 6 bar Clamping slide monitoring at 2 bar Limit volumetric flow for clamping slide monitoring to 5 l/min 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 21: Screw Tightening Torques
(Screw quality 12.9) Screw size Tightening torque M (Nm) Tightening torques for mounting the clamping modules (Screw quality ≥ 10.9) Screw size Tightening torque M (Nm) 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 22: Operation
Do not reach into the clamping module. Use pressure maintenance valves. Use loading devices. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 23: Maintenance And Care
The system may only be commissioned again once the faults have been corrected. For example, by replacing the damaged unit. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 24: Storage
Only store the product in dry rooms. Protect the product from major temperature fluctuations. NOTE: Before recommissioning, clean the product and all attachments, check for damage, functionality and leaks. 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 25: Troubleshooting
The clamping faces on the clamping slides Remove the clamping pin and clean the and on the clamping pin are dirty clamping faces on the clamping slides and on the clamping pin 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 26: Seal Kit And Parts List
O-ring Ø 32 x 1 O-ring Ø 19 x 1 O-ring Ø 15 x 1 O-ring Ø 2 x 1 Set-screw Compression spring Countersunk screw Fitting screw 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 27: Assembly Drawing
Assembly drawing 10 Assembly drawing 10.1 NSE mikro 49-13, NSE mikro 49-13-V10 *Contained exclusively in NSE mikro 49-13-V10 (ID 1357110) 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... -
Page 28: Manufacturer Certificate
VDMA 34192:2019 Safety requirements for clamping devices for use on machines Mengen, 19th of July 2023 p.p. Philipp Schräder p.p. Alexander Koch Head of Development standard products Head of Engineering Design special products 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691... - Page 29 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691...
- Page 30 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691...
- Page 31 06.00 | VERO-S NSE mikro 49-13 | Quick-change pallet system | en | 1416691...
