Multi-Angle Ball Sorter
Operating Instructions
Make sure to read this manual carefully before using, and start using only after you have
understood all the product's functions, safety information and precautions.
After reading the instructions, store the booklet in a designated location for readily accessing at
any time.
Thank you for purchasing the Multi-Angle Ball Sorter Module (hereinafter referred
to as "this product").
※This product refers to all products including standard accessories.
This User Manual is intended to be written under control using not network
communications, but digital I/O, such as PLC signals.
2 Great Valley Blvd., Wilkes-Barre, PA 18706
Office Ph: 570-820-8811
Fax: 570-820-8838
www.itohdenki.com
Specifications subject to change without notice
Revised 2/19/2025
