DXV Landfair D35107430 Installation Instructions

INSTALLATION INSTRUCTIONS
®
Landfair
Cross Handle Trim Kit for
2 Way or 3 Way In-Wall Diverter
Model D35107430
To be used with
D35000420.191 - 3/2 Way In-Wall Diverter
D35000430.191 - 4/3 Way In-Wall Diverter
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully
before you begin.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before workhas begun.
Plumbers' Putty or Caulking
ROUGHING-IN DIMENSIONS:
• For reference
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 227-2734
www.DXV.com
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
Phillips Screwdriver
1-1/4" DIA.
(32 mm)
1-3/4" to 2-3/4"
(44 mm-70 mm)
