INSTALLATION INSTRUCTIONS
Randall
®
Handle Trim Kit for
2 Way or 3 Way In-Wall Diverter
Model D35102430
To be used with
D35000420.191 - 3/2 Two Way In-Wall Diverter
D35000430.191 - 4/3 Three Way In-Wall Diverter
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully before you begin.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
Flat Blade Screwdriver
ROUGHING-IN DIMENSIONS:
• NOTE: NO CONCEALED PIPING FURNISHED
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 227-2734
www.DXV.com
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2017
Phillips Screwdriver
FINISHED
WALL
3-1/4"
(83 mm)
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: 1-800-395-1498
www.DXV.ca
- 1 -
Plumbers' Putty or Caulking
2-3/4" D.
(70 mm)
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
M965552 Rev. 1.5 (2/17)
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for DXV Randall D35102430
Summary of Contents for DXV Randall D35102430
- Page 1 To be used with D35000420.191 - 3/2 Two Way In-Wall Diverter D35000430.191 - 4/3 Three Way In-Wall Diverter Thank you for selecting DXV. To ensure that your installation proceeds smoothly, please read these instructions carefully before you begin. RECOMMENDED TOOLS AND MATERIALS Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing supply stores.
- Page 2 INSTALL CROSS HANDLE Turn off hot and cold water CAUTION supplies before beginning. • Install ESCUTCHEON (1) onto ESCUTCHEON HOLDER (2). Apply sealant to groove on back side of ESCUTCHEON (1). Thread ESCUTCHEON HOLDER (2) with ESCUTCHEON (1) onto DIVERTER VALVE (3) until ESCUTCHEON (1) is flush against finished wall.
