DXV Randall D35102980 Installation Instructions

INSTALLATION INSTRUCTIONS

Randall
®
Exposed Tub Filler
with Hand Shower
Cross Handle
Model D35102980
Thank you for selecting DXV. To ensure that your
installation proceeds smoothly, please read these
instructions carefully before you begin.
RECOMMENDED TOOLS AND MATERIALS
Most of the procedures require the use of common tools and materials, which are available from hardware and plumbing
supply stores. It is essential that the tools and materials be on hand before work is begun.
Tubing Cutter Channel Locks
ROUGHING-IN DIMENSIONS:
• For reference
8-5/8"
(218 mm)
2-7/8 "
(73 mm)
(126 mm)
In the United States:
DXV
One Centennial Avenue
Piscataway, New Jersey 08855
Attention: Director of Customer Care
For residents of the United States, warranty
information may also be obtained by calling
the following toll free number: (800) 227-2734
www.DXV.com
Product names listed herein are trademarks of AS America, Inc.
© AS America, Inc. 2015
Adjustable Wrench
1/2" NPT
(13 mm)
2-3/4" DIA.
5"
7/8"
2-7/8"
(23 mm)
(72 mm)
Level
3-1/2"
(89 mm)
3-1/8"
(80 mm)
(70 mm)
MOUNTING HOLES
ARE 1/38" DIA. (35 mm)
In Canada:
DXV
5900 Avebury Road
Mississauga, Ontario
L5R 3M3
Canada
Toll Free: 1-800-387-0369
Local: 905-306-1093
Fax: 1-800-395-1498
www.DXV.ca
- 1 -
Phillips Screwdriver
Flat Blade Screwdriver
9-5/8"
(244 mm)
30°
6"
(152 mm)
In Mexico:
DXV
Via Morelos 330
Col. Santa Clara Coatitla
Ecatepec, Estado de México 55540
Toll Free: 01-800-8391200
www.DXV.mx
M965523 Rev. 1.5 (4/17)
Sealing Tape
