Infant Scale
USER MANUAL
MS2400
Infant Scale
Please keep the instruction manual at hand and follow instruction for use.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS2400 and is the answer not in the manual?

Questions and answers

Related Manuals for Charder MS2400

Summary of Contents for Charder MS2400

  • Page 1 Infant Scale USER MANUAL MS2400 Infant Scale Please keep the instruction manual at hand and follow instruction for use.

  • Page 3: Table Of Contents

    CONTENTS Explanation of Graphic Symbols on Label/Packaging ..4 I. Safety Notes ............... 7 A. General Information ...........7 B. EMC Guidance and Manufacturer's Declaration ..11 II. Installation.............. 15 A. Height Measure Attachment ......15 B. Inserting Batteries ........... 17 C.

  • Page 4: Explanation Of Graphic Symbols On Label/Packaging

    Explanation of Graphic Symbols on Label/Packaging Meaning Text/Symbol Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
  • Page 6 Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. Charder reserves the right to correct misprints in the manual without prior notice, and modify the exterior of the device for quality purposes without customer consent.

  • Page 7: Safety Notes

    I. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.

  • Page 8: Intended User Profile

    and maximum capacity) (b) Weight: no restrictions within device weight capacity (c) Patient Conditions: require measurement of body weight. Can fit upon device. Intended user profile (a) At least 20 years old (b) Minimum knowledge: - To be able to read at a high-school level and understand Arabic numerals (e.g.

  • Page 9: Safety Instructions

    ◼ void. Observe permissible ambient temperatures for use ◼ Maintenance Please contact your local Charder distributor for regular maintenance and calibration, regular checking of accuracy is recommended; frequency to be determined by level of use and state of device. Cleaning Device surface should be cleaned using alcohol-based wipes.

  • Page 10: Incident Reporting

    All maintenance, technicalinspections, and repairs should be conducted by an authorized Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty.

  • Page 11: Emc Guidance And Manufacturer's Declaration

    B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Electromagnetic Emission test Compliance...
  • Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 Compliance Electromagnetic test level environment-guidance...
  • Page 13 Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance Electromagnetic level level environment-guidance...
  • Page 14 Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,amateurradio,AMandFMradiobroadcastandTVbroadcastcannotbepredictedtheoreticall ywithaccuracy.To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the product is used exceedstheapplicable RF compliance level above, the product should be observed to verify normal operation.

  • Page 15: Installation

    II. Installation A. Height Measure Attachment 1. Attach bracket to device, and fasten screws using screwdriver. Version with rubber head pad Rubber head Attach bracket here Version without rubber head pad Attach bracket here...
  • Page 16 2、Connect height measure attachment (HM80D or HM80M) to bracket. A clicking noise will be heard. 3、To detach height measure, find the latch located at the rear of the attachment. Press down on the buckle, and gently remove the attachment from bracket.

  • Page 17: Inserting Batteries

    B. Inserting Batteries 1. Locate battery cover 2. Remove battery cover 3. Insert 9V battery 4. Put the battery cover back C. Using AC Adapter Device can be powered using AC adapter located at rear of device. Plug adapter into device before plugging into mains.

  • Page 18: Indicator

    III. Indicator A. Indicator and Key Functions B. Key Functions 1. MEMORY: Recall and release weight stored in memory 2. kg/lb: Press this key to switch unit between kg, lb, oz, and lb: oz. 3. ON/ZERO/OFF: When device is off, press to power on. When device is on, press to zero weight (under 2% of max capacity).

  • Page 19: Using Device

    IV. Using Device A. Basic Operation Switch on the device using [ON/ZERO/OFF] key. The device will automatically perform self-calibration, displaying software version. Once "0.00 kg" appears on indicator, device is ready for measurement. Note: If "0.00 kg" does not display on indicator, press [ZERO] key to zero the device.

  • Page 20: Recall

    C. Recall Weight value can be stored (>1 kg) and recalled. If weight on platform is greater than 1 kg, press [RECALL] key to store weight value. If weight on platform is less than 1 kg, press [RECALL] key to recall stored weight value. To return to normal weighing mode, press [ON/ZERO/OFF] key.

  • Page 21: Device Setup

    V. Device Setup When the device is switched on, press and hold the [TARE] key until the display shows "SET" followed by"A.OFF” (first option in setting menu). In device setup: [TARE] to toggle menu option [RECALL] to confirm selection / enter submenu Auto Power-Off:Instruct device to shut off automatically after a certain period of time.
  • Page 22 Bluetooth (optional): If device has Bluetooth module installed, Bluetooth function can be turned on or off. Press [TARE] to toggle between on/off, and [RECALL] key to confirm selection. Wi-Fi Setting (optional): If device has Wi-Fi module installed, Wi-Fi function can be turned on or off. Press [TARE] to toggle between on/off, and [RECALL] key to confirm selection.

  • Page 23: Troubleshooting

    Warranty Program & Return Policy. 1. If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit. Should the repairs or replacement delivery fail, statutory provisions shall be valid.
  • Page 24 Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key ◼ Broken or damaged wires causing short circuit or faulty ◼...
  • Page 25 2. Indicator damage Possible hardware defects include: uneven brightness in ◼ LCD screen, blurred text, smeared rainbow screen, incorrect decimal display Unable to save or read data ◼ Indicator shows "ERRL" after device is switched on ◼ Keys not responding ◼...

  • Page 26: Product Specifications

    VII. Product Specifications A. Device Information Model MS2400 Capacity 20kg x 10g Weight Accuracy ± 20g Measurement 1.0-inch LCD screen LCD Screen (4 1/2 digits) Device 640(W) x 355(D) x 60(H) plus Handle Dimensions Platform 500(W) x 350(D) mm Surface Device Weight 2.8 kg...

  • Page 27: Power Adapter Standards

    B. Power Adapter Standards Warning The device is only compatible with themanufacturer's power adapters specified below CE APPROVED DRAWI Adapter TYPE NO. / TYPE VOLTAGE NG NO. plug MODEL NO. CD-AD- UES06WOCP-1200 12V 0.5A 00011 50SPA...

  • Page 28: Declaration Of Conformity

    VIII. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
