Summary of Contents for Charder MS2350
- Page 1 Wheel chair scale USER MANUAL MS2350 Please keep the instruction manual at hand and follow instruction for use.
-
Page 2: Table Of Contents
CONTENTS I.Explanation of Graphic Symbols on Label/Packaging ..... 3 II. Copyright Notice ..............5 III. Safety Notes ............... 6 A. General Information ............6 B. EMC Guidance and Manufacturer's Declaration ...... 10 IV. Installation ................ 14 A. Bracket Assembly ............. 14 B. -
Page 3: I.explanation Of Graphic Symbols On Label/Packaging
I.Explanation of Graphic Symbols on Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 4 M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
-
Page 5: Copyright Notice
Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. -
Page 6: Safety Notes
III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. -
Page 7: Safety Instructions
- To be able to read at a high-school level and understand Arabic numerals (e.g. 1, 2, 3, 4...) - Basic hygiene knowledge - Trained in device's operation - Read the instruction manual (c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required... -
Page 8: Maintenance
Warranty/Liability If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit. Should the repairs or replacement delivery fail, statutory provisions shall be valid. -
Page 9: Incident Reporting
Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty. Disposal This product is not to be treated as regular household waste, but ... -
Page 10: Emc Guidance And Manufacturer's Declaration
B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic... - Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity IEC 60601 Compliance level Electromagnetic test level environment-guida...
- Page 12 Conducte 3 Vrms 3 Vrms Portable and mobile RF communications 150 KHz to 80 150 KHz to 80 d RF IEC equipment should be used no closer to 61000-4- any part of the product including cables, than the recommended separation 6 V in ISM bands 6 V in ISM distance calculated from the equation...
- Page 13 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help preventelectromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximumoutput power of the communications equipment.
-
Page 14: Installation
IV. Installation A. Bracket Assembly wall Fixed plate Tapping Plastic Knob Spacer Fixed plate (top) Screw (bottom) Screw anchor... -
Page 15: Cable Connection
B. Cable Connection Connector with green sticker is for cable connecting the beams to one another Connector with blue sticker is for cable connecting from beam to indicator C. Inserting Batteries 1. Open battery housing cover... - Page 16 2. Accessing batteries Take out the battery housing 3. Use either rechargeable battery pack, or AA batteries 4. Ensure batteries are installed into the housing correctly Rechargeable Battery Housing AA-size Battery Housing...
- Page 17 5. Install the battery housing into the compartment, and make sure the right side of housing pin is facing towards inside of the connecting position 6. Slide back the cover to close the battery housing compartment. Turn on power to confirm that battery is correctly installed.
- Page 18 Using Rechargeable Battery (optional) The rechargeable battery should be recharged at least once every 3 months, regardless of if the device has been used. Battery can be charged by plugging device's exclusive adapter into AC Connector Port. After a long period in storage (e.g. >3 months), the battery should run a full cycle (charge/discharge) to allow it to restore full capacity.
-
Page 19: Indicator
V. Indicator A. Indicator and Key Functions (Wireless functionality optional) Key Function 1. ON/OFF: Power on or power off. 2. ZERO: Reset display to 0.0 kg display (can be used if within ±2% of full capacity). Press and hold for 3 seconds to enter device settings. 3. - Page 20 B. Display layout Definitions Stable symbol: Indicate that weight is stable. Zero symbol: Weight is at zero Minor weight: Weight under zero. Low battery: Battery needs to be charged or replaced.
-
Page 21: Using Device
VI. Using Device A. Basic Operation Switch on the device using [ON/OFF] key. The device will automatically perform self-calibration, displaying software version. Once "0.00 kg" appears on indicator, device is ready for measurement. Note: If "0.00 kg" does not display on indicator, press [ZERO] key to zero the device. -
Page 22: Bmi
C. BMI 1. In normal mode, press the [BMI] key to enter BMI mode. 2. Display will show last recorded height. Left-most digit will flash. 3. Enter height using numeral keys (ex: 170 cm) (accepted values: 0-250 cm). Input will automatically move to next digit. Press [CLEAR] key to re-input. -
Page 23: Pre-Tare
E. Pre-Tare The Pre-Tare function is used to subtract the known weight of a substance prior to weighing. The MS2350 can store 5 sets of pre-tare values. (ex: 5 different wheelchair weights) Pre-tare values can be stored using two different methods: "Load Weight", or "Input Manually". - Page 24 A. Load Weight DESCRIPTION EXAMPLE Press M1-5 key after loading weight on the platform; the indicator will display blinking "m" symbol. Press numeral key 1 ~ 5 to assign this number with the current pre-tare weight. Press [ENTER] key to store pre-tare weight;...
- Page 25 While digit is blinking: Enter pre-tare weight using 0~9 keys. Ex: to pre-tare 5.0 kg of weight, press 0-0-5-0. Press [ENTER] key to confirm the pre-tare weight. Indicator will display minus sign to the left of pre-tare weight value. To save this pre-tare weight value in memory: Press M1-5 key;...
-
Page 26: Print
C. Recall Pre-Tare Weight DESCRIPTION EXAMPLE Press and hold [PRE-TARE] key for 3 seconds. Indicator will display pre-tare value M1 first. The pre-tare value will flash. Press numeral keys 1 ~ 5 to choose pre-tare value Press [ENTER] key to confirm which pre-tare weight to select;... -
Page 27: Device Setup
VII. Device Setup A. Setting Time & Date Press and hold [HOLD] key for 3 seconds to enter Time Setting mode. Example: Inputting 2008, Dec 25, 8:00am Year Setting Enter year using numeral keys 0-9. Press [HOLD] key once completed to proceed to month &... -
Page 28: Device Setup
B. Device Setup When the device is switched on, press and hold the [ZERO] key for about 3 seconds, until the display shows the "SETUP”, followed by "A.OFF” (first option in setting menu). In device setup menu: [TARE] to toggle next menu option [ZERO] to toggle previous menu option [HOLD] to confirm selection / enter submenu Auto Power-Off: Instruct device to shut off automatically after a certain... - Page 29 Language: Set thermal printer language Press [HOLD] to toggle between English, Italian and Polish. Press [TARE] key to confirm selection. Font size: Set thermal printer font size. Press [HOLD] to toggle between normal and double (larger). Press [TARE] key to confirm selection. BT / Wifi (optional) : If device has BT or Wifi module installed,the function can be turned OFF/BT/Wifi.
-
Page 30: Setup Usb Connection To Pc
USB 2.0 or above. Operators should select a USB cable length that is most suitable to the operating environment. 1. Charder Smart Data Manager can be used to connect the device to a PC. The software program can be downloaded from the Charder website: [LINK URL] https://www.chardermedical.com/download.htm... - Page 31 Conducting Measurement 1. Input subject's first name, last name, patient ID, date of birth (DD/MM/YYYY), gender, and height (for BMI calculation) into software if needed. Press [Clear] to clear all input. NOTE: information can also be input after weight measurement. 2.
- Page 32 Saving & Printing Results 1. Press [Save as] to save measurement results as .csv file on PC. Default file name is same as user ID. (ex: 20190201.csv) To track changes and multiple measurements for the same subject, we recommend not changing the default file name. 2.
-
Page 33: Wireless Connection
3. Press the printer icon to print out result using a printer connected to the PC. IX. Wireless Connection If the device has wireless or BT module installed, the indicator can transmit measurement results wirelessly. Please see Charder wireless or BT software instructions for details. -
Page 34: Troubleshooting
Warranty Program & Return Policy. 1. If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit. - Page 35 properly as indicated in this manual Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key Broken or damaged wires causing short circuit or faulty connection ...
- Page 36 Error Messages Error Message Reason Action Low battery warning Replace batteries, or Voltage of battery is too plug in AC adapter low to operate device Overload Reduce weight on Total load exceeds measurement device's maximum platform and try again capacity Counting Error (too Error normally caused high)
-
Page 37: Product Specifications
XI. Product Specifications A. Device Information Model MS2350 Display DP3710 Weight Capacity 300 kg x 0.1 kg Measurement Accuracy ± 1.5e OIML Class III LCD Screen 1.0-inch LCD screen (5 1/2 digits) Dimensions Overall 190(W) x 1200(D) x 100(H) mm... -
Page 38: Power Adapter Standards
B. Power Adapter Standards Warning The device is only compatible with the power adapters specified in the dashed block below. DRAWING NO. CE APPROVED TYPE NO. TYPE Adapter plug VOLTAGE / MODEL NO. CD-AD-00041 12V 2A UES24LCP-120200SPA CD-AD-00041 UES24LCP-120200SPA CD-AD-00041 UES24LCP-120200SPA CD-AD-00041 UES24LCP-120200SPA... - Page 39 Notes ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________ ________________________________________________________________________________...
-
Page 40: Declaration Of Conformity
XII. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
