- Page 1 Stand-on Floor Scale USER MANUAL MS2504 Please keep the instruction manual at hand and follow instruction for use.
-
Page 3: Table Of Contents
CONTENTS I. Explanation of Text/Symbols on Device Label/Packaging ..4 II. Copyright Notice ..............6 III. Safety Notes ................7 A. General Information ..............7 EMC Guidance and Manufacturer's Declaration ........11 IV. Installation ................15 A. Standard Parts ................15 B. -
Page 4: Explanation Of Text/Symbols On Device Label/Packaging
I. Explanation of Text/Symbols on Device Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...
-
Page 6: Copyright Notice
This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. -
Page 7: Safety Notes
III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. -
Page 8: Safety Instructions
Residual Risk Evaluation (a) All foreseeable risks have been evaluated and considered acceptable. Generally speaking, the most likely risk caused by incorrect usage of the device is less accurate measurement (or inability to use device to acquire measurement), which does not pose imminent physical risk to patient or user. -
Page 9: Maintenance
All maintenance, technical inspections, and repairs should be conducted by an authorized Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Disposal This product is not to be treated as regular household waste, but ... -
Page 10: Incident Reporting
Warning Only the original adapter should be used with the device. Using an adapter other than the one provided by Charder may cause malfunction. Do not touch the power supply with wet hands. Do not crimp the power cable, and avoid sharp edges. -
Page 11: Emc Guidance And Manufacturer's Declaration
EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment-guid... - Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level Electromag test level netic...
- Page 13 NOTE UT is the a.c. mains voltage prior to application of the testlevel. Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance...
- Page 14 Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,amateurradio,AMandFMradiobroadcastandTVbroadcastcannotbepredictedtheore ticallywithaccuracy.To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the product is used exceedstheapplicable RF compliance level above, the product should be observed to verify normal operation.
-
Page 15: Installation
IV. Installation A. Standard Parts Accessories Item Spec. Qty. Adjustable feet SW-8080B Round head hex socket screws M5*0.8*18 (for columns) Washer head screws M5*0.8*38 (for handrail) Locknut M5(T=6.2) (for handrail) screws M4*0.7*8 (for indicator) washer M5x12x1 (for handrail) Rubber washer for SW-8074 handrail screws and nut User Manual... -
Page 16: Attach Columns
B. Attach columns 1. Attach first handrail column to platform 2. Attach second handrail column to platform 3. Attach third handrail column to platform... -
Page 17: Attach Handrail
C. Attach handrail 1. Attach handrail columns 2. Place handrail in position to platform and push down 3. Attach handrail to column with screws Push handrail down into column and The installation is complete insert screws and tighten NOTE: Ensure that screws are securely tightened for patient safety... -
Page 18: Attach Indicator
D. Attach indicator Ensure screws securing indicator to handrail are tight... -
Page 19: Inserting Batteries
E. Inserting Batteries 1. Open battery housing cover 2. Push down tab securing battery housing 3. Remove battery housing 4. Insert battery pack NOTE: Ensure that batteries are installed into housing correctly... -
Page 20: Using Adapter
5. Slide battery housing cover back in place. Turn on power to confirm that battery is correctly installed. F. Using Adapter 1. Connect adapter to indicator before connecting to mains power supply 2. Disconnect adapter from mains power supply before unplugging adapter pin from indicator. -
Page 21: Attaching Height Stadiometer To Column
G. Attaching Height Stadiometer to Column Image Part Qty. Fixing block (WH-8026) Flat head screw (M5*0.8*10) Flat head screw (M5*30) 1. Attach two fixing blocks to column 2. Attach HM200D to blocks using using M5*30 flat-head screws M5*0.8*10 flat-head screws... - Page 22 Connecting Digital Height Stadiometer to indicator Some digital height stadiometers can transfer results directly to indicator. 1. Locate USB port on back of height stadiometer 2. Connect USB cable (9 pin DIN) to USB port on height rod. 3. Locate 9 pin DIN port on bottom of indicator, and connect USB cable. Plug cable into indicator...
- Page 23 Calibrating Height Stadiometer(HM200D) Slide measurement rod down completely. Turn on HM200D using [ON/OFF] key. If height display is not at "120cm", press [Reset] key to calibrate to 120cm. Calibrating Height Stadiometer(HM201D) Slide measurement rod down completely. Turn on device using [ON/OFF] key on indicator.
-
Page 24: Attaching Thermal Printer
H. Attaching Thermal Printer... -
Page 25: Indicator
V. Indicator A. Indicator and Key Functions (300kg model) (350kg model) (Wireless functionality optional) Key Function ON/OFF: Power on or power off. ZERO: Reset display to 0.0 kg display. Press and hold for 3 seconds to enter device settings. M1-5: Saving pre-tare values (up to 5) PRE-TARE: Pre-tare the known weight of an object (ex: chair) before beginning measurement. -
Page 26: Display Layout
B. Display layout Definitions Stable symbol: Indicate that weight is stable. Zero symbol: Weight is at zero Negative weight: Weight under zero. Low battery: Battery needs to be charged or replaced. -
Page 27: Using Device
VI. Using Device A. Basic Operation Switch on the device using key. The device will automatically perform self-calibration, displaying software version. Once "0.00 kg" appears on indicator, device is ready for measurement. Note: If "0.00 kg" does not display on indicator, press key to zero the device. -
Page 28: Bmi
C. BMI 1. In normal mode, press the key to enter BMI mode. 2. Display will show last recorded height. Left-most digit will flash. 3. Enter height using numeral keys (ex: 170 cm). Input will automatically move to next digit. Press key to re-input. -
Page 29: Tare
D. Tare The tare function allows the user to deduct the weight of objects from the device's measurement result. 1. Place object that needs to be tared onto measurement platform. 2. Press key after stable symbol appears on indicator. Display will indicate "0.00 kg". - Page 30 A. Load Weight DESCRIPTION EXAMPLE Press key after loading weight on the platform; the indicator will display blinking "m" symbol. Press numeral key 1 ~ 5 to assign this number with the current pre-tare weight. Press key to store pre-tare weight;...
- Page 31 B. Input Manually DESCRIPTION EXAMPLE Press key. Left-most digit will begin blinking. If no further action is taken within 6 seconds, indicator will return to normal mode While digit is blinking: Enter pre-tare weight using 0~9 keys. Ex: to pre-tare 5.0 kg of weight, press 0-0-5-0.
- Page 32 Press numeral key 1 ~ 5 to assign this number with the current pre-tare weight. Press key to store pre-tare weight; the indicator will make a beep sound.
- Page 33 C. Recall Pre-Tare Weight DESCRIPTION EXAMPLE Press and hold key for 3 seconds. Indicator will display pre-tare value M1 first. The pre-tare value will flash. Press numeral keys 1 ~ 5 to choose pre-tare value Press key to confirm which pre-tare weight to select; the device will automatically deduct pre-tare weight.
-
Page 34: Print
F. Print If thermal printer is connected to indicator, results can be printed by pressing key. USB Port Port Power socket NOTE: Thermal printer needs to be powered by adapter... -
Page 35: Device Setup
VII. Device Setup A. Setting Time & Date Press and hold keyfor 3 seconds to enter Time Setting mode. Example: Inputting2008, Dec 25, 8:00am Year Setting Enter year using numeral keys 0-9. Press key once completed to proceed to month & date setting. Month &... -
Page 36: Device Setup
B. Device Setup When the device is switched on, press and hold the key for about 3 seconds, until the display shows the "SETUP”, followed by "A.OFF” (first option in setting menu). In device setup menu: to toggle next menu option to toggle previous menu option to confirm selection / enter submenu Auto Power-Off: Instruct device to shut off automatically after a certain... - Page 37 Language: Set thermal printer language Press to toggle between English, Italian and Polish. Press key to confirm selection. Font size: Set thermal printer font size. Press to toggle between normal and double (larger). Press key to confirm selection. BT / Wifi (optional) : If device has BT or Wifi module installed,the function can be turned OFF/BT/Wifi.
-
Page 38: Connecting Scale To Receiving Device
Save Changes After completing changes, press until "END" is displayed on screen. Press to save. VIII. Connecting scale to receiving device The device can transfer results to receiving device. Please consult instruction manual for receiving device. Connection directly to Electronic Medical System should be conducted by qualified distributors/administrators only. -
Page 39: Troubleshooting
IX. Troubleshooting Before contacting your local Charder distributor for repair service, we recommend considering the following troubleshooting procedures: Self-inspection 1. Device will not power on If battery power is depleted, replace with new batteries If batteries are not used, check if the power adapter is plugged into ... - Page 40 Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key Broken or damaged wires causing short circuit or faulty connection ...
-
Page 41: Product Specifications
X. Product Specifications Model MS2504 Display DP3710 300 kg x 0.1 kg Capacity 350 kg x 0.1 kg Weight Accuracy ± 2.0e ± 1.5e Measurement non-OIML approved OIML Class III model LCD Screen 1.0-inch LCD screen (5 1/2 digits) Overall... - Page 42 Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________...
- Page 43 Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________...
-
Page 44: Declaration Of Conformity
XI. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
