- Page 1 Owner’s Manual & Assembly Guide Model No. 404015DR-M W40’ x L 40’ x H15’ Strong Container Shelter * See Inside for Detailed Safety Information. Gloves must be worn at all times to reduce risk of injury!
-
Page 2: Safety And Maintenance
SAFETY & MAINTENANCE Safety precautions MUST be followed at all times throughout the construction of your building! Care must be taken when handling Do NOT attempt to assemble your Practice caution with the tools being various pieces of your building since used in the assembly of this building. -
Page 3: What You Need
ASSEMBLY TIPS & TOOLS Watch the Weather Closely: Be sure the day you choose to install your building is dry and calm. Do NOT attempt to assemble your building on a windy day. Be careful on wet or muddy ground. Use Teamwork: Two or more people are required to assemble your building. - Page 4 PLEASE READ AND UNDERSTAND INSTRUCTIONS COMPLETELY BEFORE ASSEMBLY. LAY OUT FRAME PARTS AS BELOW: Description Middle Roof Bent Tube Outer tube: φ 60*3260mm Side Upper Bent Tube φ 60*3260mm SideLower Bent Tube Outer tube: φ 60*3260mm Supporting Webbing between the arch φ...
- Page 5 Tension Tube For Roof Cover φ 60*320mm Clamping Piece PVC Protective Cover U-steel For Part No.U6 Left Corner Base Plate Right Corner Base Plate Left Base Plate Right Base Plate Φ 32mm PPR Tube Roof Cover Ratchet Straps Lashing pairs / Winch 18pcs Small Ratchet With...
- Page 6 Carriage Bolt M8x80mm Bolt M20x60mm Bolt M10x30mm Bolt M10x50mm Flange nut M8 Flange nut M10 Flange nut M20 Hex nut M10 Flat washer M10 Flat washer M20 SPECIFICATION Width:12m Length: 12 m Height:4.5m 3m Arch Spacing NOTE:FRME EXTENSION KIT This is the base frame dimension. Your model may have more or less middle ribs than shown in the illustration . You will receive more extra ribs for every extra arch spacing of building length that you purchase.
- Page 7 1.Base Plate Installation: Before building your shelter, you should choose a flat area on your property and plot your shelter. The two containers inner distance is 11600mm. A.Stake out the area for the shelter in the desired spot. The width of the area should be at least equal to the width of the shelter and the length should be equal to the length of the shelter.
-
Page 8: Safety Tips
SAFETY TIPS Always wear proper safety equipment such as safety glasses and gloves 2. ASSEMBLE FRAME Assemble the frame as below figures shown. Securely fasten all of the joints with the hardware indicated. Clamping Piece(Part no.12) to 2.1 As Figure 2 shown to find one Middle Bent Tube, Lower Bent Tube and assemble these arches with Carriage bolt M8x80mm(Part no.S23) and make the first arch group. - Page 9 As Figure 3 shows,install the Supporting Webbing between the arch(No.5)by using Bolt M10x30mm(No.S18).Then put the PVC protective cover on the outer of connection of the arch to protect the roof cover from scratched by the outer joint. Figure 3...
- Page 10 2.3 Lift an assembled arch onto one base plate and connect the arch with the base plate by using Bolt M20x60mm (Part no.S22). and force the other end of the arch onto the opposite base plate by same way as Figure 4 shows. Figure 4...
- Page 11 2.4.After finishing installing the first two arches with the base plates,install middle double trussed purlin (Part no.5)between two arches by using bolt M10x30mm(Part no.S18)and single truss purlin (Part no.6)using between two arches by using bolt M10x30mm(Part no.S18).There are 1 pc Double trussed purlin and 6pcs single truss pulrins between arches.
- Page 12 Figure 6 THINK SAFETY, EVERYDAY!
- Page 13 2.5.Connect the Diagonal Support Tube For purlin(Part no.7) to the arch and purlin (Part no.6) by bolt M10x30mm(Part no.S18) and clips(Part no.10) as below Figure 7 shows. Figure 7...
- Page 14 2.6.Connect the Diagonal Support tubes(Part no.8 and no.8A) by using bolt M10x50mm(Part no.S17),then install the diagonal support tubes to the arches by using clips(Part no9) as below Figure 8 shows.There are total two groups x diagonal support tubes as the figure shows. Figure 8...
- Page 15 3. INSTALLING THE COVER ON THE FRAME NOTE: DO NOT install the cover onto the frame of your building in high wind conditions. A slight breeze is the most advantageous for cover installation. To take advantage of the breeze, pull the cover up over the arches with breeze blowing in the cover like a sail filled with air. Figure 9...
- Page 16 Figure 10 Figure 11 1. Assemble Tension Tube (Part no.11 and 11A)for Roof Cover before installing the cover.Put the black plastic p l u g ( Part no.U18)into the end of tension tube. 2. Roll out the roof cover on a ground sheet. Align the cover evenly to each end of the frame. Note: Be sure doing not pull overthe end of the roof cover.
- Page 17 Figure 12 5. Insert the PPR Tube (Part no.17)into the end of roof cover by using small ratchet with straps(Part no.U2)to the arch as Figure 12 shows.Then cut the lower tension cover pocket according to the base plate location(Please note the Cutting direction,the cutting should be Perpendicular to the cover pocket as the Figure 12 shows). Insert the nylon straps (Part no.U10)into the winch ,drive the ratchet straps lashing winch forth and back and then roof cover is tightened.The roof cover tightening should be properly tightened and not too tight.
- Page 18 Figure 13 U-steel (Part no.14)on the end of shipping container ,install the Finally weld the ratchet straps lashing winch by using bolt M10x30mm(Part no.S18)and insert the roof cover corner straps into the winch and drive the ratchet straps lashing winch forth and back.NOW THE INSTALLATION IS FINISHED. NOTE: Please adjust the roof cover every month.
-
Page 19: Warranty Information
RETURN AND WARRANTY INFORMATION WARRANTY INFORMATION WHAT IS NOT COVERED UNDER WARRANTY: Manufacturers/distributors/retailers of these products are not responsible for the following: (1) Used products; (2) Any product that that been used, altered, or modified in any way; (3) Depreciation; (4) Damage caused by lack of reasonable and proper maintenance;... -
Page 20: Return Information
(15) Loss of income, wages, travel expenses, personal property, equipment rental, fuel, and/or property value are not recoverable (16) Any condensation damage to the product and its contents. End panels are excluded from any warranty regardless of the product series or classification. FAILURE DUE TO IMPROPER INSTALLATION OF THE PRODUCT IS NOT COVERED UNDER WARRANTY If a product/part is deemed to be defective &...
