Summary of Contents for KTM F5303T5
- Page 1 SETUP INSTRUCTIONS 2020 390 Adventure Art. no. 3214254en...
- Page 3 KTM accepts no liability for delivery options, deviations from fig- ures and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not belong to the regular scope of supply.
-
Page 4: Means Of Representation
1 MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 To operate the vehicle, the vehicle electronics must be enabled. This process is conducted during initial setup in KTM Dealer.net. Enabling ensures that the initial setup in KTM Dealer.net is docu- mented. Enabling can be performed either temporarily, e.g. for a test ride, or permanently for vehicle handover.
- Page 6 2 SETUP – Roll down the film at the sides. Info To avoid damaging the motorcycle during unpacking, leave the other films on the vehicle until you have fin- ished work on the vehicle. – Remove the separate enclosure and unpack it. Check the sepa- rate enclosure for completeness.
- Page 7 SETUP 2 – Attach the outer clutch cable. S04205-01 – Plug in the connector of the brake light switch. S04207-01 – Fit the hand guard and rear mirror on both sides. Guideline Nut, left rear mirror M10x1.25 16 Nm (11.8 lbf ft) Nut, right rear mirror M10LHx1.25 16 Nm (11.8 lbf ft)
- Page 8 Remove the remaining film, padding, the corrugated card- board, and the other packaging material. – Refuel. ( p. 14) – Check the headlight setting. ( p. 15) – Prepare the vehicle according to the specifications in the KTM Dealer.net for handover to the customer.
- Page 9 WORK 3 Checking the clutch lever play Note Clutch damage If there is no free travel by the clutch lever, the clutch will begin to slip. – Check the free travel of the clutch lever each time before using the motorcycle. –...
- Page 10 3 WORK Removing the passenger seat – Insert the ignition key in seat lock and turn it clockwise. – Raise the rear of the seat, push it towards the rear, and lift it off. – Remove the ignition key from the seat lock. H01991-10 Mounting the passenger seat –...
-
Page 11: Charging The 12-V Battery
WORK 3 Mounting the front rider's seat Main work – Attach the front rider's seat in area and lower at the rear. – Finally, check that the front rider's seat is correctly mounted. H01994-01 Finishing work – Mount the passenger seat. ( p. - Page 12 3 WORK – Remove the front rider's seat. ( p. 8) – Disconnect the negative cable of the 12-V battery. ( p. 10) Main work – Connect a battery charger to the 12-V battery. Adjust the bat- tery charger. EU battery charger XCharge‑professional (00029095050) Alternative 1 US battery charger XCharge‑professional (00029095051)
- Page 13 WORK 3 Connecting the negative cable of the 12-V battery Main work – Connect negative cable of the 12-V battery. S04165-12 Finishing work – Mount the front rider's seat. ( p. 9) – Mount the passenger seat. ( p. 8) –...
- Page 14 3 WORK 3.11 Setting the time and date Condition The motorcycle is stationary. – Press the SET button when the menu is closed. – Press the UP or DOWN button until Preferences appears. Press the SET button to open the menu. –...
- Page 15 WORK 3 3.12 Opening fuel tank filler cap Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not fuel the vehicle in the vicinity of open flames or lit cigarettes. –...
- Page 16 3 WORK – Fold down the fuel tank filler cap. – Turn the ignition key 90° clockwise. – Push down the fuel tank filler cap and turn the ignition key counterclockwise until the fuel tank filler cap lock engages. – Remove the ignition key and close the cover.
- Page 17 Fill the fuel tank with fuel up to the lower edge of the fuel filler. Total fuel tank 14.5 l Super unleaded capacity, approx. (3.83 US gal) (ROZ 95) p. 20) (KTM 390 Duke EU/AU/JP/US, AR/CN/CO, MY/PH) Total fuel tank Gasohol 95 E20 capacity, approx. (RON 95) p. 20)
- Page 18 3 WORK 3.16 Adjusting the headlight range Preparatory work – Check the headlight setting. ( p. 15) Main work – Turn adjusting screw to adjust the headlight range. Info Turn clockwise to increase the headlight range; turn counterclockwise to reduce the headlight range. If you have a payload, you may have to correct the headlight range.
-
Page 19: Technical Data
TECHNICAL DATA 4 Chassis tightening torques EJOT PT Screw, chain guard ® K60x30 3 Nm (2.2 lbf ft) Remaining screws, chassis 4 Nm (3 lbf ft) Screw, tail light 2 Nm (1.5 lbf ft) Remaining nuts, chassis 5 Nm (3.7 lbf ft) Remaining screws, chassis 5 Nm (3.7 lbf ft) Screw, chain guard... - Page 20 4 TECHNICAL DATA Screw, lower rear panel 7 Nm (5.2 lbf ft) Screw, magnetic holder on side 5 Nm (3.7 lbf ft) Loctite ® 243™ stand Screw, main silencer 12 Nm (8.9 lbf ft) Screw, main silencer retaining 9 Nm (6.6 lbf ft) bracket Screw, protective plate 8 Nm (5.9 lbf ft)
- Page 21 TECHNICAL DATA 4 Fitting side stand 35 Nm (25.8 lbf ft) Loctite ® 243™ Remaining nuts, chassis 50 Nm (36.9 lbf ft) Remaining screws, chassis 45 Nm (33.2 lbf ft) Screw, engine bearer 49 Nm (36.1 lbf ft) Loctite ® 243™...
- Page 22 5 SUBSTANCES Gasohol 95 E20 (RON 95) Standard/classification – Gasohol 95 E20 (RON 95) Guideline – Only use super unleaded fuel that matches or is equivalent to the specifications. – Super unleaded fuel with an ethanol content of 19 to 20% is permissible. Info Do not use fuel made of methanol (e.g., M15, M85, M100).
- Page 23 *3214254en* 3214254en 07/2021 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KISKA/KTM KTM.COM...
