- Page 1 SETUP INSTRUCTIONS 2022 RC 125 Art. no. 3214678en...
- Page 3 KTM accepts no liability for delivery options, deviations from fig- ures and descriptions, misprints, and other errors. The models portrayed partly contain special equipment that does not belong to the regular scope of supply.
-
Page 4: Means Of Representation
1 MEANS OF REPRESENTATION Symbols used The meaning of specific symbols is described below. Indicates an expected reaction (e.g. of a work step or a function). Indicates an unexpected reaction (e.g. of a work step or a function). Indicates a page reference (more information is provided on the specified page). Indicates information with more details or tips. - Page 5 To operate the vehicle, the vehicle electronics must be enabled. This process is conducted during initial setup in KTM Dealer.net. Enabling ensures that the initial setup in KTM Dealer.net is docu- mented. Enabling can be performed either temporarily, e.g. for a test ride, or permanently for vehicle handover.
- Page 6 2 SETUP – Turn the rear mirror to the correct position on both sides. V02670-01 – Make sure that the clutch cable is attached to the clutch release lever and secured. – Check the clutch lever play. ( p. 6) –...
- Page 7 Mount the front rider's seat. ( p. 8) – Refuel. ( p. 14) – Prepare the vehicle according to the specifications in KTM Dealer.net for handover to the customer. Info Transport mode must be deactivated to be able to start the motorcycle.
- Page 8 3 WORK Checking the clutch lever play Note Clutch damage If there is no free travel by the clutch lever, the clutch will begin to slip. – Check the free travel of the clutch lever each time before using the motorcycle. –...
- Page 9 WORK 3 Checking the play in the throttle cable – Check the throttle grip for smooth operation. – Move the handlebar to the straight-ahead position. Turn the throttle grip back and forth slightly and determine the play in throttle cable 3 …...
-
Page 10: Remove Screws
3 WORK Mounting the front rider's seat – Attach recesses on the front rider's seat to the fuel tank, push the front rider's seat forward, and lower at the rear. The pin locks audibly in place. – Check that the front rider's seat is mounted correctly. H04979-10 Removing the fuel tank cover Preparatory work... - Page 11 WORK 3 Mounting the fuel tank cover Main work – Position the fuel tank cover and slide it forward. Holding lugs engage in the brackets. – Position brackets with rubber bushings on holding lugs and slide down. V02501-10 – Mount and tighten screws Guideline Remaining screws, 6 Nm (4.4 lbf ft)
- Page 12 3 WORK Note Environmental hazard 12 V batteries contain environmentally hazardous materials. – Do not dispose of 12 V batteries as household waste. – Dispose of 12 V batteries at a collection point for used batteries. Note Environmental hazard Hazardous substances cause environmental damage. –...
- Page 13 WORK 3 3.10 Disconnecting the negative cable of the 12-V battery Preparatory work – Remove the front rider's seat. ( p. 7) – Remove the fuel tank cover. ( p. 8) Main work – Disconnect negative cable of the 12-V battery. V02521-10 3.11 Connecting the negative cable of the 12-V battery...
- Page 14 3 WORK – Position negative cable and mount and tighten the screw. V02521-11 Finishing work – Mount the fuel tank cover. ( p. 9) – Mount the front rider's seat. ( p. 8) – Set time and date. ( p. 12) 3.13 Setting the time and date Condition...
- Page 15 WORK 3 – Press the SET button. The date is stored. 3.14 Opening the fuel tank filler cap Danger Fire hazard Fuel is highly flammable. The fuel in the fuel tank expands when warm and can escape if overfilled. – Do not fuel the vehicle in the vicinity of open flames or lit cigarettes. –...
- Page 16 3 WORK 3.15 Closing the fuel tank filler cap Warning Fire hazard Fuel is highly flammable, toxic and a health hazard. – Check that the fuel tank filler cap is locked cor- rectly after closing. – Change your clothing if fuel spills on them. –...
- Page 17 WORK 3 – Switch off the engine. – Open the fuel tank filler cap. ( p. 13) – Fill the fuel tank with fuel up to the lower edge of the fuel filler. Total fuel tank 13.7 l Super unleaded capacity, approx.
-
Page 18: Technical Data
4 TECHNICAL DATA chassis tightening torques Remaining screws, chassis 4 Nm (3 lbf ft) Remaining screws, chassis 5 Nm (3.7 lbf ft) Remaining screws, trim 4 Nm (3 lbf ft) Screw, anti-rotation lock, handle- 4 Nm (3 lbf ft) bar stub Screw, side stand sensor 5 Nm (3.7 lbf ft) Loctite... - Page 19 TECHNICAL DATA 4 Screw, subframe bottom 25 Nm (18.4 lbf ft) Loctite ® 243™ Screw, top triple clamp 15 Nm (11.1 lbf ft) Screw, front brake caliper M8x1 32 Nm (23.6 lbf ft) Loctite ® 243™ Banjo bolt, brake line 24 Nm (17.7 lbf ft) Nut, engine bearer, front 48 Nm (35.4 lbf ft)
- Page 20 5 SUBSTANCES Super unleaded (ROZ 95) Standard/classification – DIN EN 228 (ROZ 95) Guideline – Only use super unleaded fuel that matches or is equivalent to the specified standard. – Fuel with an ethanol content of up to 10% (E10 fuel) is safe to use. Info Do not use fuel containing methanol (e.g., M15, M85, M100) or more than 10% ethanol (e.g., E15, E25, E85, E100).
- Page 21 *3214678en* 3214678en 04/2022 KTM Sportmotorcycle GmbH 5230 Mattighofen/Austria Photo: Mitterbauer/KISKA/KTM KTM.COM...
