WARNING: The tool runs for approximately 4 seconds after it has been
switched off. Let the motor come to a complete standstill before setting the
tool down.
T
RIMMING FUNCTION
1. Adjusting the cutting height
WARNING: Do not try to adjust the telescopic shaft while the trimming tine is
rotating.
• Unscrew the lock sleeve on the shaft and
adjust the length of the telescopic shaft (K) to
the most comfortable operation position (See
fig.11). Tum the lock sleeve anti-clockwise to
lock the shaft in position.
2. Adjusting the front handle
WARNING: Remove the battery from string
trimmer before performing adjustments.
• While gripping the adjustment button
(J) on front handle (C) tightly and turn it with
downward direction (See fig. 12), push the
front handle down until the desired angle is
set. Then release the adjustment button on
front handle.
• There are 8 angles for you to choose the
preferred one. Note: There's a downward
arrow marked on this handle. You can
follow the direction of the arrow to adjust
the angle (See fig. 13).
3. Adjusting the angle of motor housing
WARNING: Remove the battery from string trimmer before performing
adjustments.
While firmly holding the main handle in one hand
and press the button on the motor housing, push
back and forth the shaft to adjust the motor
housing (4 positions-0 ,30º, 60º ,90º) (See fig. 14).
Fig. 11
Fig. 12
Fig. 14
