MADER POWER SF8A220 Manual page 51

C
HARGING THE BATTERY
A factory-new battery is not fully charged.
Recommendation: Fully charge the battery before using it for the first time.
• Connect the charger to the power supply - mains voltage and operation voltage
of the charger must be the same - see "Connecting Charger to Power Supply".
Operate the charger only in enclosed and dry rooms at ambient temperatures
between +5 ºC to +40 ºC.
Only charge dry batteries. Allow a damp battery to dry before charging.
• Push the battery into the charger until noticeable resistance is felt - then push
it as far as stop.
• Charging begins as soon as the red light on the charger turns up.
The charging time dependent on a number of factors, including battery condition,
ambient temperature, etc., and may therefore vary from the times specified.
The battery heats up during operation in the power tool. If a hot battery is inserted in
the charger, it may be necessary to cool it down before charging. The charging process
begins only after the battery has cooled down. The time required for cooling may
prolong the charge time.
The battery and charger heat up during the charging process.
E
ND OF CHARGE
• The green light turns up when the charger is fully charged.
• Remove the fully charged battery from the charger.
OPERATING INSTRUCTIONS
WARNING: Read and thoroughly understand all instructions and safety
information before operating this string trimmer. Failure to do so may cause
serious injury or death. Do not allow anyone to operate this string trimmer
who has not read this manual. a string trimmer can be dangerous if assembled or used
improperly. Do not operate this string trimmer if you have doubts or questions
concerning safe operation.
S /
TARTING STOPPING THE STRING TRIMMER
• Install the battery pack. (Refer to
Installing the battery pack)
• Depress the lock off button (1)
and at the same time press the
trigger switch (2). (See fig. 10)
• To switch off, release the trigger
switch.
1
50
Fig. 10
2
