- Page 1 User Manual Industrial Protocols Embedded Ethernet Switch (HiOS-2E EES) UM IndustProtocol HiOS-2E EES Technical Support Release 4.0 07/2014 https://hirschmann-support.belden.eu.com...
- Page 2 The naming of copyrighted trademarks in this manual, even when not specially indicated, should not be taken to mean that these names may be considered as free in the sense of the trademark and tradename protection law and hence that they may be freely used by anyone. ©...
-
Page 3: Table Of Contents
Contents Contents Safety instructions Industry Protocols IEC 61850/MMS Switch model for IEC 61850 Integration into a Control System 2.2.1 Preparation of the device. 2.2.2 Offline configuration 2.2.3 Monitoring the device Readers’ Comments Index Further Support UM IndustProtocol HiOS-2E EES Release 4.0 07/2014... - Page 4 Contents UM IndustProtocol HiOS-2E EES Release 4.0 07/2014...
-
Page 5: Safety Instructions
Safety instructions Safety instructions WARNING UNCONTROLLED MACHINE ACTIONS To avoid uncontrolled machine actions caused by data loss, configure all the data transmission devices individually. Before you start any machine which is controlled via data transmission, be sure to complete the configuration of all data transmission devices. Failure to follow these instructions can result in death, serious injury, or equipment damage. - Page 6 Safety instructions UM IndustProtocol HiOS-2E EES Release 4.0 07/2014...
-
Page 7: Industry Protocols
Industry Protocols 1 Industry Protocols For a long time, automation communication and office communication were on different paths. The requirements and the communication properties were too different. Office communication moves large quantities of data with low demands with respect to the transfer time. Automation communication moves small quantities of data with high demands with respect to the transfer time and availability. - Page 8 Industry Protocols Output Input Input Ethernet Output Figure 1: Example of communication. UM IndustProtocol HiOS-2E EES Release 4.0 07/2014...
-
Page 9: Iec 61850/Mms
IEC 61850/MMS 2 IEC 61850/MMS IEC 61850/MMS is an industrial communication protocol standardized by the International Electrotechnical Commission (IEC). The protocol is to be found in substation automation, e.g. in the control technology of energy suppliers. This protocol, which works in a packet-oriented way, is based on the TCP/IP transport protocol and uses the Manufacturing Messaging Specification (MMS) for the client-server communication. -
Page 10: Switch Model For Iec 61850
IEC 61850/MMS 2.1 Switch model for IEC 61850 2.1 Switch model for IEC 61850 The Technical Report, IEC 61850 90-4, specifies a bridge model. The bridge model represents the functions of a switch as objects of an Intelligent Electronic Device (IED). An MMS client (e.g. the control room software) uses these objects to monitor and configure the device. - Page 11 IEC 61850/MMS 2.1 Switch model for IEC 61850 Class Description LN LCCF “Channel Communication Filtering” logical node: Defines the VLAN and Multicast settings for the higher-level “Communication Channel”. LN LBSP “Port Spanning Tree Protocol” logical node: Defines the Spanning Tree statuses and settings for the respective physical device port.
-
Page 12: Integration Into A Control System
IEC 61850/MMS 2.2 Integration into a Control System 2.2 Integration into a Control System 2.2.1 Preparation of the device. After installing and connecting the device, configure it according to the 'Basic Configuration' user manual: Check that the device has an IP address assigned. ... -
Page 13: Offline Configuration
IEC 61850/MMS 2.2 Integration into a Control System 2.2.2 Offline configuration The device allows you to download the ICD file using the graphical user interface. This file contains the properties of the device described with SCL and enables you to configure the substation without directly connecting to the device. -
Page 14: Monitoring The Device
IEC 61850/MMS 2.2 Integration into a Control System 2.2.3 Monitoring the device The IEC61850/MMS server integrated into the device allows you to monitor multiple statuses of the device by means of the Report Control Block (RCB). Up to 5 MMS clients can register for a Report Control Block at the same time. The device allows the following statuses to be monitored: Class RCB object... -
Page 15: A Readers' Comments
Readers’ Comments A Readers’ Comments What is your opinion of this manual? We are constantly striving to provide as comprehensive a description of our product as possible, as well as important information to assist you in the operation of this product. Your comments and suggestions help us to further improve the quality of our documentation. - Page 16 Readers’ Comments Suggestions for improvement and additional information: General comments: Sender: Company / Department: Name / Telephone number: Street: Zip code / City: E-mail: Date / Signature: Dear User, Please fill out and return this page as a fax to the number +49 (0)7127/14-1600 or ...
-
Page 17: B Index
Index B Index IEC 61850 Technical Questions Training Courses UM IndustProtocol HiOS-2E EES Release 4.0 07/2014... - Page 18 Index UM IndustProtocol HiOS-2E EES Release 4.0 07/2014...
-
Page 19: C Further Support
Contact our support at https://hirschmann-support.belden.eu.com You can contact us in the EMEA region at Tel.: +49 (0)1805 14-1538 E-mail: hac.support@belden.com in the America region at Tel.: +1 (717) 217-2270 E-mail: inet-support.us@belden.com in the Asia-Pacific region at ... - Page 20 Further Support With the Hirschmann Competence Center, you have decided against making any compromises. Our client-customized package leaves you free to choose the service components you want to use. Internet: http://www.hicomcenter.com UM IndustProtocol HiOS-2E EES Release 4.0 07/2014...
- Page 21 Further Support UM IndustProtocol HiOS-2E EES Release 4.0 07/2014...
