JOB MEMORY

Retrieve JOB:
-> Briefly press the Job button
-> select job with potentiometer (C1 to C10)
-> Briefly press the Job button
-> Job is called.
Programming a JOB:
-> Briefly press the Job button
-> select job with potentiometer (C1 to C10)
-> Select / set parameters
-> Job button briefly (correct number?) Then for 4 seconds until
Display flashes.
-> Release the Job button and wait until the
Display stops.
The parameters are now stored under the job number.

WELDING METHODS

1.1 CLEANING THE WORKPIECE BEFORE WELDING
TIG welding is very sensitive to surface contamination. Therefore, it is necessary to clean
workpieces of welding grease, paint, and impurities before welding.
1.2 PREPARATION FOR TIG WELDING
1. Connect the shielding gas supply hose to the connection 21 on the back of the
welding machine, use the supplied clamps,
2. Connect the TIG torch to terminals 14, 16 and 17 on the front of the welding
machine, torch assembly according to the picture below,
