Satel AQUA Manual

The microprocessor-based, fully digital
AQUA series detectors feature high
sensitivity and interference resistance.
The AQUA detector employs a dual
pyro electric element,
AQUA Pro - a quad element.
CONTACTS:
NC - alarm relay (NC)
TMP - tamper contact (NC)
COM - ground (0V)
12V - supply input (9-16V DC)
Three pairs of pins are used for setting
the detector working parameters (see
Table).
Low sensitivity
Medium sensitivity
High sensitivity
LED indicator ON
LED indicator OFF
- pins open
ambient disturbances recorded by the detector do not meet the alarm criteria. The
prealarm sensitivity is not affected by the detector sensitivity, which is set with jumpers.
For 30 seconds after the power is turned on, the detector remains in a starting state,
which is signalized by rapid LED blinking. Only then the detector enters its operational
readiness state.
The detector monitors the supply voltage. If the voltage drops below 9V (±5%) for more
than 2 seconds, the detector will signalize a violation state until a voltage of minimum 9V
(±5%) is restored.
INSTALLATION
The detector is designed for indoor installation. It can be mounted on the wall, either
directly or on the included holder. Prior to installation of the detector housing, remove the
electronics board and make adequate openings for screws and cable in the rear panel of
the housing. It is advisable that you exercise particular care to prevent the pyro
element from getting dirty or damaged during installation.
The scale provided on the detector board (see Fig.1) is intended for properly setting the
pyro element against the lens installed in the housing. If the detector is to be mounted at
DIGITAL PASSIVE
INFRARED DETECTORS
®
AQUA & AQUA Pro
and the
positioning scale
JP1 JP2 JP3
- pins shorted
NC NC TMP TMP COM 12V
relay
JP1
JP2
JP3
Figure 1. View of detector electronics board
The LED lights red for approx. 2s when
the detector is actuated, which enables
the installer to check the detector for
correct functioning
approximately determine the protected
area.
The detector features a prealarm
function. The
actuate the relay and is indicated by
a short flash of the LED, lasting
approx. 120ms. It is activated when the
aqua_dwa_e 06/04
LED
pyro element
tamper contact
operating parameter
setting pins
PIR SENS.
LED ON/OFF
and
prealarm does
to
not
