Instructions for Installation and Care of Polaris Trail S Soft Door Kit
CAUTION: Do not smoke inside the cab or expose the enclosure to direct flames. Product is FLAMMABLE.
Be sure to read these instructions thoroughly before opening and installing the enclosure. The
installation is best done when ambient temperature is 70
weather, warming the adhesive Velcro strips before installation is recommended.
Carefully open the carton and remove the rolled up cab enclosure on a large flat surface that is
clean and free of dirt or other material that may soil or scratch the windows of the Cab.
If any parts are damaged or missing please contact customer service at (606) 845-7439.
1. Hook and Loop Attachment (Passenger Side)
Cut and attach hook and loop to the A pillar and top of roll cage. If you have any clamps
on the machine trim hook and loop around those.
52-10256-Z Polaris Trail S
F or warmer. If installed in cold
°
Advertisement
Related Manuals for FALCON RIDGE 52-10256-Z
Summary of Contents for FALCON RIDGE 52-10256-Z
- Page 1 Instructions for Installation and Care of Polaris Trail S Soft Door Kit 52-10256-Z Polaris Trail S CAUTION: Do not smoke inside the cab or expose the enclosure to direct flames. Product is FLAMMABLE. Be sure to read these instructions thoroughly before opening and installing the enclosure. The installation is best done when ambient temperature is 70 F or warmer.
- Page 2 Secure hook and loop to the B Pillar and trim around any clamps. Repeat for the opposite side and wait 15 minutes for the hook and loop to adheare. Place soft upper door onto the machine and loosely secure straps. Align the door to the machine and when happy, tighten the straps.
- Page 3 2. Hook and Loop Installation section. Cut and secure hook and loop to the inside of the soft cabs lower Peel off the backing from the hook and loop. Fold flap down and firmly press along area where the hook and loop is installed. Wait 15 mins for the adhesive to adhere to the machine.
- Page 4 Snap Installation For best results Outline Snap with a paint marker or chalk, press the snap onto the body to mark location. Install the provided snap and secure the soft door to the snaps. Repeat for all remaining snaps.
-
Page 5: Warranty
Cleaning and Storage Recommendations: 1. Before removing the Falcon Ridge for storage, make sure it is very clean in order to prevent scratching of the window panels. Clean with a soft rag or sponge using a mild liquid detergent soap and warm water solution. Never rub the windows with a dry cloth or rag! Let the Cab dry thoroughly before attempting to roll for storage.
