Installation & Operations Manual : FR Flip-Up Windshield, Polaris Full-Size Pro-Fit Ranger
Installation Information:
This product does not require any modifications to your vehicle. Please familiarize yourself with all the steps before
beginning assembly.
Falcon Ridge was established to help UTV owners adapt their vehicles for the great outdoors, Falcon Ridge
provides innovative, practical, and rugged UTV products to provide owners the confidence to work, play, or explore
in whatever conditions they may encounter.
Were fueled by your passion!
Parts List:
1.
50-50219; 50-50837 FS Ranger Windshield
2.
54-91032 Gasket
3.
54-96047 Tube Assembly
4.
54-96061 Brace Mounting Block Cover
5.
54-96064 T Handle
6.
54-96058 Shim (2)
7.
54-96080 Ball Bracket, Driver
8.
54-96081 Ball Bracket, Pass.
9.
54-96086 Gas Spring (2)
10.
54-96071 Center Retainer
11.
54-96072 Rub Plate
12.
54-96082 Strike Plate, Driver
13.
54-96083 Strike Plate, Pass.
14.
54-96085 Hinge Half, Upper (2)
15.
54-96084 Hinge Half, Lower (2)
16.
54-96055 Ball Stud Clamp (2)
17.
54-96056 FS Ranger Hardware Bag
Installation Video
Scan code with your phone's
camera and follow the link
Part Number 50-50219KIT; 50-50837KIT
Tools Needed:
•
4mm, 5mm, 6mm Allen Wrenches
•
10mm, 12mm, 13mm Open End Wrench
•
Socket Wrench with 13mm Socket
•
Small Flathead Screwdriver
