F&F LK-703K Quick Start Manual

Indicator lamp (red-yellow-green)

Advertisement

Quick Links

LK-703K-24
Indicator lamp
(red-yellow-green)
Do not dispose of this device in the trash along with other waste!
According to the Law on Waste, electro coming from households free of charge and can
give any amount to up to that end point of collecti on, as well as to store the occasion of
the purchase of new equipment (in accordance with the principle of old-for-new, regard-
less of brand). Electro thrown in the trash or abandoned in nature, pose a threat to the
environment and human health.
Purpose
The LK-703K indicator lamp is used to visually signal the pre-
sence of voltage in individual phases of a 3-phase network. The
small size of the housing (width 6.2 mm) allows space-saving in-
stallation in the switchgear.
Functioning
The presence of voltage on a phase is signalled by the illumi-
nation of the corresponding LED included in the circuit of that
phase.
Where an overcurrent fuse equal to or greater than 25 A
is installed upstream of the lamp connection point, the
lamp connection circuit must be fused with a fuse no
greater than 6 A.
F&F Filipowski L.P.
Konstantynowska 79/81, 95-200 Pabianice, POLAND
phone/fax (+48 42) 215 23 83 / (+48 42) 227 09 71
www.fif.com.pl; e-mail: biuro@fif.com.pl
- 1 -
