Factory Preset / *RST:
Front Panel Access:
See Also:

:SENSe:CHPower Subsystem

This subsystem includes commands related to configuring the channel power
measurement.

Channel Power Integration Bandwidth

[:SENSe]:CHPower:BANDwidth|BWIDth:INTegration <freq>
[:SENSe]:CHPower:BANDwidth|BWIDth:INTegration?
Sets the integration bandwidth for the channel power measurement.
Integration bandwidth must be less than or equal to the frequency span.
Factory Preset / *RST:
Range:
Default Unit:
Front Panel Access:
See Also:

Channel Power Measurement State

[:SENSe]:CHPower:STATe OFF|ON|0|1
[:SENSe]:CHPower:STATe?
Sets the state of the channel power measurement, ON or OFF.
When using :CONFigure:CHPower, the state is automatically set to ON.
Factory Preset / *RST:
Front Panel Access:
See Also:

:SENSe:OBWidth Subsystem

This subsystem includes commands related to configuring the occupied bandwidth
measurement.

Occupied Bandwidth Measurement Method

[:SENSe]:OBWidth:METHod XDB|PERCent
[:SENSe]:OBWidth:METHod?
Sets the method for calculating occupied bandwidth.
XDB calculates the occupied bandwidth based on points a specified number of dB below
the carrier. Issue command [:SENSe]:OBWidth:XDB to set the number of dB to be
used.
PERCent calculates the occupied bandwidth based on points a specified percentage of the
carrier power below the carrier. Issue command [:SENSe]:OBWidth:PERCent to
set the percentage to be used.
www.valuetronics.com
MS2721A: OFF
Shift-4 (Measure), ACPR, On/Off
:CONFigure:ACPower
MS2721A: 10.35 MHz
MS2721A: 10 Hz to 7.1 GHz
Hz
Shift-4 (Measure), Channel Power, Int BW
[:SENSe]:FREQuency:SPAN
MS2721A: OFF
Shift-4 (Measure), Channel Power, On/Off
:CONFigure:CHPower
