DISPlay Subsystem

This subsystem provides commands that modify the display of data for the user. They do
not modify the way in which data is returned to the controller.

Scale

:DISPlay:WINDow:TRACe:Y[:SCALe]:PDIVision <rel ampl>
:DISPlay:WINDow:TRACe:Y[:SCALe]:PDIVision?
Sets the scale (dB/division) for the y-axis.
Factory Preset /
*RST:
Range:
Default Unit:
Front Panel Access: Amplitude, Scale

Reference Level

:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel <amplitude>
:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel?
Sets the reference level amplitude value for the y-axis.
Note that this may cause a change in attenuation if the automatic input attenuation
coupling is enabled.
Factory Preset /
*RST:
Range:
Default Unit:
Front Panel Access: Amplitude, Reference Level
See Also:

Reference Level Offset

:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel:OFFSet <rel ampl>
:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel:OFFSet?
Sets the reference level offset value for the y-axis.
Factory Preset /
*RST:
Range:
Default Unit:
Front Panel Access: Amplitude, RL Offset
www.valuetronics.com
MS2721A: 10 dB/div
MS2721A: 1 dB to 15 dB
dB
MS2721A: 10 dBm
With reference level offset = 0 dB:
MS2721A: 30 dBm to -130 dBm
Current active amplitude unit
:DISPlay:WINDow:TRACe:Y[:SCALe]:RLEVel:OFFset
<rel ampl>
:UNIT:POWer
MS2721A: 0 dB
MS2721A: 0 dB to 100 dB
dB
15
