Input Impedance

[:SENSe]:CORRection:IMPedance[:INPut][:MAGNitude] <integer>
[:SENSe]:CORRection:IMPedance[:INPut][:MAGNitude]?
Sets the input impedance that will be used for amplitude correction and conversion
between units (dBm vs. dBV vs. Volts, etc.).
If the value of <integer> is 50 no correction will be performed.
If the value of <integer> is 75 correction will be done based on Anritsu adapter
12N50-75B.
If the value of <integer> is anything else it will look to the value set by
[:SENSe]:CORRection:IMPedance[:INPut]:OFFSet for the amplitude
correction value. Unit conversion will be done as if the impedance is 75Ω.
If a value other than 50 or 75 is set, it will be returned as 2 by the query form of this
command.
Factory Preset /
*RST:
Range:
Front Panel Access:
See Also:

"Other" Input Impedance Loss

[:SENSe]:CORRection:IMPedance[:INPut]:OFFSet <rel ampl>
[:SENSe]:CORRection:IMPedance[:INPut]:OFFSet?
Sets the value that will be used for amplitude correction when the value set by
[:SENSe]:CORRection:IMPedance[:INPut][:MAGNitude] is something
other than 50 or 75. This value is not applied if the impedance is set to either 50 or 75.
Factory
Preset /
*RST:
Range:
Default Unit:
Front Panel
Access:
See Also:

:SENSe:DETector Subsystem

This subsystem includes commands that affect acquisition data points on the instrument.

Detection Type

[:SENSe]:DETector[:FUNCtion] POSitive|RMS|NEGative|SAMPle
[:SENSe]:DETector[:FUNCtion]?
Sets the detection method for calculating each display point.
www.valuetronics.com
MS2721A: 50
MS2721A: 50, 75 all other values will be treated as described
above
Shift-8 (System), Application Options, Impedance
[:SENSe]:CORRection:IMPedance[:INPut]:OFFSet
MS2721A: 0
MS2721A: 0 dB to 100 dB
dB
Shift-8 (System), Application Options, Impedance
[:SENSe]:CORRection:IMPedance[:INPut][:MAGNitude]
