CALCulate Subsystem

The commands in this subsystem process data that has been collected via the SENSe
subsystem.

:CALCulate:MARKer Subsystem

This subsystem contains commands related to the function and display of trace markers.

Marker (Maximum) Peak Search

:CALCulate:MARKer[1]|2|3|4|5|6:MAXimum
Puts the specified marker at the maximum amplitude in the trace.
Front Panel Access:

Marker (Maximum) Peak Search Left

:CALCulate:MARKer[1]|2|3|4|5|6:MAXimum:LEFT
Puts the specified marker on the next highest peak to the left of the current peak.
The next highest peak must be above the peak threshold. If no point meets that criterion,
the marker is set to the first point on the trace.
Front Panel Access:
See Also:

Marker (Maximum) Peak Search Right

:CALCulate:MARKer[1]|2|3|4|5|6:MAXimum:RIGHt
Puts the specified marker on the next highest peak to the right of the current peak.
The next highest peak must be above the peak threshold. If no point meets that criterion,
the marker is set to the last point on the trace.
Front Panel Access:
See Also:

Peak Threshold

:CALCulate:MARKer:PEAK:THReshold <percentage>
:CALCulate:MARKer:PEAK:THReshold?
Sets the peak threshold as a percentage of the display.
:CALCulate:MARKer:MAXimum:LEFT and
:CALCulate:MARKer:MAXimum:RIGHt use this value to determine whether a
particular display point qualifies as a peak.
Factory Preset / *RST:
Range:
Default Unit:
Front Panel Access:
www.valuetronics.com
Marker, [Marker 1/2/3/4/5/6/,] Peak Search
Marker, More Peak Options, Peak Search
Marker, More Peak Options, Next Peak Left
:CALCulate:MARKer:PEAK:THReshold
Marker, More Peak Options, Next Peak Right
:CALCulate:MARKer:PEAK:THReshold
MS2721A: 10%
MS2721A: 0% to 100%
%
Marker, More Peak Options, Peak Threshold
