- Page 1 Cubit Locker - 4 Door Assembly Guide Need a hand? knightgroup.co.nz Contact us at info@knightgroup.co.nz or 0800 143 143 for assistance.
- Page 2 Place the product a safe distance from window frames, radiators, furniture etc. so that persons cannot become trapped. Any questions contact Knight on 0800 143 143 Due to continuous improvement of our products, our assembly instructions may not be in complete accordance with the product and we apologise in advance.
- Page 3 Right Side Panel 4*16 Screw Batten Hinge Door Panel Lock Fixed Shelf Lock Catch Back Panel 6*35 Cam Bolt 4*16 Screw 8*30 Dowel Pin Cam Cover Lock Lock Catch Hinge Adjustable Foot knightgroup.co.nz Assembly Guide - Cubit Locker 4 Door...
- Page 4 X, Z, A and G. lnsert dowel pins d1 into panels F, X, Z and G. Fix lock catch L2 to panel X with screw s1. Assembly Guide - Cubit Locker 4 Door 0800 143 143...
- Page 5 D. lnsert dowel pins d1 into panels D and O. Fix lock L1 to panel V with screw 3.5*20. Fix hinge bodies h1 to panel V with screws s1. knightgroup.co.nz Assembly Guide - Cubit Locker 4 Door...
- Page 6 O into cams on panels G and tighten in a clockwise direction. lnsert cam bolts c1 on panel F and G into cams on panels D and tighten in a clockwise direction. Assembly Guide - Cubit Locker 4 Door 0800 143 143...
- Page 7 Step 4 Panel X and Z assembly lnsert cam bolts c1 on panel X and Z into cams on panels O, G, F and D and tighten in a clockwise direction. knightgroup.co.nz Assembly Guide - Cubit Locker 4 Door...
- Page 8 A into cams on panels X, Z and D and tighten in a clockwise direction. Fix adjustable foot to panel G with screws s1. Assembly Guide - Cubit Locker 4 Door 0800 143 143...
- Page 9 Assembly Guide - Cubit Locker 4 Door...
- Page 10 Rotate the knob back to the closed position to Turn the key to the close position and pull the key out. complete the process. The lock can now be used normally. Assembly Guide - Cubit Locker 4 Door 0800 143 143...
-
Page 11: Care And Maintenance
Melamine furniture is a durable and versatile material that requires proper care and maintenance to ensure longevity. By following the tips outlined above, you can maintain the quality of your melamine furniture and enjoy it for many years to come. knightgroup.co.nz Assembly Guide - Cubit Locker 4 Door... - Page 12 0800 143 143 info@knightgroup.co.nz knightgroup.co.nz...
