ASSEMBLY

TOOLS NEEDED FOR MOUNTING OF THE INSERT

¬ Spirit level
¬ Cross tip screwdriver
¬ Ø10 wall drill

LOOSE PARTS

The trim is packed separately.
In the insert's combustion chamber you will find the following loose parts:
¬ Bricks for the bottom of the burn chamber
¬ Baffle plate in steel
(Must only be used on Scan 1006/Scan 1006 HE)
¬ Glove
¬ Bag containing loose parts:
4 x self-tapping screws 4.2 x 6.5 mm
(for fastening the sleeve Ø100 mm)
4 x rawlplugs10 x 50 mm (for fastening the cassette)
4 x discs Ø6.5 / Ø16 x 1.1 (for fastening the cassette)
Ø100 mm sleeve with flange
Combustion chamber package contains:
¬ Baffle plates
Flue pipe package contains:
¬ 2 x flue pipe 1000 mm (Ø150 mm)
Catalyst package contains:
¬ Box for catalyst
¬ Locking shaft
Folder for Scan 1006 HE + contains:
¬ Energy label

ADDITIONAL ACCESSORIES

¬ Convection adaptors Ø149 mm (see page 18)

DISPOSAL OF PACKAGING

Your Scan built-in stove may come supplied with the following packaging:
Wood packaging
Foam
Plastic bags
Stretch/plastic film
10
The wood packaging can be reused and after final use can be incinerated as a CO
product or sent for recycling.
Send for recycling or waste disposal
Send for recycling or waste disposal
Send for recycling or waste disposal
¬ Cutting nippers
¬ Flat head screwdriver
¬ Open-end spanner
¬ Log guard
¬ Folder with labels for Scan 1006 CS
(Use folder for Scan 1006 HE + instead)
¬ 3 pins Ø6 x 40 mm (for baffle plates)
8 x 3 mm black self-adhesive gasket (2 m)
(Ø100 mm sleeve, connecting piece and cassette)
4 x torx screws M6 x 50 (for fastening the cassette)
Torx key T30
2 x screws M5x6 mm (Only used in Norway)
¬ Burn chamber plates (side and rear)
¬ Catalyst
¬ Type plate
¬ Convection grates (See page 24)
neutral
2
