Chapter 2: Jumpers and Connectors
Internal Jumpers & DIP Switches
Clear CMOS
Connector type: 1 x 3-pin header, 2.0mm pitch
Connector location: CLRCMOS
1
3
Pin
Settings
1-2 On
Normal (Default)
2-3 On
Clear CMOS
Copyright © 2022 NEXCOM International Co., Ltd. All Rights Reserved.
LVDS Panel Voltage Select
Connector type: 1 x 3-pin header, 2.54mm pitch
Connector location: LCD_PWR
1
3
Pin
Settings
1-2 On
3.3V (Default)
2-3 On
5V
12
NDiS B339 User Manual
