Chapter 2: Jumpers and Connectors

Locations of the Jumpers and Connectors for NDiS B339

The following figures show the motherboard used in the DNiS B339, and indicate the locations of the jumpers and connectors. Refer to this chapter for detailed
pin settings and definitions of the connectors marked in pink on the figures.

Top View

CPU_FAN
SATA1
RESET_BTN
JP1
DEBUG
GPIO
USB2_57P
CLRCMOS
BAT
