PRO15.0 TREADMILL

U S E R M A N UAL

NOTE!

Read all instructions carefully before using this product. Retain this owner's manual

for future reference. The specifications of this product may vary and are subject to

change without further notice.

TM-PRO15.0

GYMSTICK.COM

Table of Contents

Need help?

Do you have a question about the PRO15.0 and is the answer not in the manual?

Questions and answers

Summary of Contents for Gymstick PRO15.0

Page 1 TM-PRO15.0 PRO15.0 TREADMILL U S E R M A N UAL NOTE! Read all instructions carefully before using this product. Retain this owner’s manual for future reference. The specifications of this product may vary and are subject to change without further notice.
Page 2: Table Of Contents
U S ER MAN UAL | PRO15 .0 T REA DM I LL BEFORE YOU BEGIN Thank you for choosing Gymstick training equipment. We take great pride in producing this high- quality product and hope it will make you feel better and enjoy life to the fullest. Please read this manual in its enterity before beginning to use this product.
Page 3: Safety Instructions
TM-PRO15.0 SAFETY INSTRUCTIONS Basic precautions should always be followed when using this product. In order to ensure safe read and follow all safety instructions included in this user manual. Failure to do so could result in serious injury. WARNING Before using this product, consult your physician first. This is especially important for individuals over the age of 35 or persons with pre-existing health problems.
Page 4: Exploded Drawing
U S ER MAN UAL | PRO15 .0 T REA DM I LL EXPLODED DRAWING info@gymstick.com +358 10 229 3040...
Page 5: Checking List
TM-PRO15.0 CHECKING LIST IMPORTANT Before assembly, please ensure all parts are included in the package. In case any parts are missing, contact our customer service to resolve the issue. www.gymstick.com...
Page 6: Parts List
Allen bolt M10*1.5*50L Rear roller set Plastic flat washer D10*D24*0.4T Inner hex head screw Incline Rear cover Allen bolt M10*1.5*65L Buffer(1) Wheel Nylon universal adjusting feet Allen bolt M8*1.25*20L Front roller set Flat washer D21*D8.5*1.5T info@gymstick.com +358 10 229 3040...
Page 7 TM-PRO15.0 PARTS LIST PART DESCRIPTION QTY. PART DESCRIPTION QTY. End cap Inner case of safety key Axle Computer fixing plate Nylon washer D21*D37*3T Safety key board Flat washer D25xD8.5x2T Upper cover for handling tube Buffer Lower cover for handling tube...
Page 8 Nut M8*1.25*6T Spacer Adjustment round wheel "Grounding cable 1 Speaker plate Speaker cable Upper cable of LED light Middle cable of LED light Lower cable of LED light LED light strap connecting plate PC spacer column info@gymstick.com +358 10 229 3040...
Page 9: Assembly Instructions
TM-PRO15.0 ASSEMBLY WARNING IMPORTANT Only adults are allowed to lift and Complete each assembly stage completely before assemble this equipment to avoid advancing on to the next. risk of injury. Assemble with nuts and bolts loose at first. Tighten only after completing assembly step.
Page 10 2. Connect the two cables (120 and 121), (156 and 157) with one another. Note! Be careful not to pinch the cables in the following step. 3. Fix the handlebar (4) to the two handlebar posts (2 and 3) with four allen screws (91). info@gymstick.com +358 10 229 3040...
Page 11 TM-PRO15.0 ASSEMBLY STEP 3. 1. Fix the supporting tube (7) to the handlebar (4) with two allen bolts (142), two spring washers (143) and two flat washers (27). 2. Connect the cables (118, 98, 156, 120 and 93) with their counterparts of the console (84).
Page 12 2. Fix the covers (8L and 8R) to the main frame (1) by pressing the lugs on the inside of the covers into the corresponding drill holes of the main frame until they engage audibly. 3. Finally fix the covers (8L and 8R) to the handlebar posts (2 and 3) with two cross bolts (11). info@gymstick.com +358 10 229 3040...
Page 13 TM-PRO15.0 ASSEMBLY STEP 5. If the floor is uneven, you can stabilize the treadmill by turning the two setting screws under the main frame. 1. Lift the treadmill on the desired side and rotate the setting screws under the main frame.
Page 14: Adjustment Instructions
Store the device in a clean, warm and dry environment, away from childred. • Allowed storage temperatures 5-40°C. IMPORTANT Turn off the device if you are not going to use it for a long time. info@gymstick.com +358 10 229 3040...
Page 15: Important Electrical Information
TM-PRO15.0 IMPORTANT ELECTRICAL INFORMATION WARNING This machine requires a right power source in order to properly operate. For your safety, as well as the safety of others, please verify that the power source is correct before plugging the equipment. Any incorrect power source could cause significant damage to the equipment and or user.
Page 16: Maintenance & Care
Left & Right side adjustment bolts one full turn clockwise, check the tension of the belt. Continue this process until belt is at the correct tension. Make sure to adjust both sides equally to ensure correct belt alignment. Refer to figure C. info@gymstick.com +358 10 229 3040...
Page 17: Lubricating The Treadmill
TM-PRO15.0 LUBRICATING THE TREADMILL IMPORTANT It’s highly recommended to lubricate the treadmill before the first use. Lubricating the running board and running belt is essential as the friction between the two affects the life span and function of the treadmill, therefore it is suggested that the running board and belt be inspected regularly.
Page 18: Console Operation Instructions
Console will display all windows for 2 seconds after inserting the safety key. All preset data will be cleared except USER 1 - USER 4. STANDBY Under non-active condition for 5 minutes, the device will enter into STANDBY mode automatically. info@gymstick.com +358 10 229 3040...
Page 19: Button Functions
TM-PRO15.0 CONSOLE OPERATION INSTRUCTIONS BUTTON FUNCTIONS Button Description START 1.1 Press the START key during setting, the setting data will be received and start the workout. 1.2 Press the START key to start program, main window will display "3-2-1-GO". 1.3 Press the START key during PAUSE mode to continue the workout.
Page 20: Media Hub
MEDIA HUB Button Description Insert AUX/MP3 cable into the console to playback music from your own device through the integrated speakers of the treadmill. Insert USB cable into the console to charge your mobile device. info@gymstick.com +358 10 229 3040...
Page 21: Console Functions
TM-PRO15.0 CONSOLE OPERATION INSTRUCTIONS CONSOLE FUNCTIONS Function Description QUICK START Press START in STANDBY mode to start QUICK START. Adjust the time, incline and other data from 0, speed from 0.5 KMH. MANUAL 2.1 Select MANUAL mode, select one of your target: TIME, CAL or DISTANCE by using SPEED+/- or INCLINE+/- and then press START key to begin the workout.
Page 22 7.7 End of count down, the training is finished with 3 times of buzzer sound and then middle window will display “FINISH XX:XX” for 3 seconds, and then after the summary of training result, enter into STANDBY mode. info@gymstick.com +358 10 229 3040...
Page 23: App Connection
TM-PRO15.0 CONSOLE OPERATION INSTRUCTIONS BLUETOOTH This device is equipped with Bluetooth® connectivity which allows it to work with interactive Bluetooth® applications. Under standby mode, press SPEED+/- or INCLINE +/- to choose BT MODE, press ENTER key and choose ON to turn on Bluetooth. Press ENTER key to confirm. Main window will return to STANDBY display.
Page 24: Warm Up & Cool Down
Open your arms to the side and lift them until they are over your head. Reach your right arm as far toward the ceiling as you can for one count. Repeat this action with your left arm. info@gymstick.com +358 10 229 3040...
Page 25 TM-PRO15.0 WARM-UP & COOL DOWN QUADRICEPS STRETCH With one hand against a wall for balance, reach behind you and pull your right foot up. Bring your heel as close to your glute as possible. Hold for 15 counts and repeat with left foot.
Page 26: Implied Warranty
• Improper use and handling of the equipment • Improper storage of the equipment • Non-compliance of the operating instructions MANUFACTURED FOR Gymstick International Oy Ratavartijankatu 11 15170 Lahti, FINLAND DISCLAIMER The manufacturer and its associates and partners have no liability, obligation or responsibility to any person or entity for any loss, damages or adverse consequence alleges to have happened directly or indirectly as a consequent of this product.
