Contents
1 Introduction ............................................................................................................................................. 1
2 I/O Descriptions ....................................................................................................................................... 2
3 EVB Usage Descriptions ........................................................................................................................... 3
3.1 EVB Configurations........................................................................................................................ 3
2
3.1.1 I
C Support ....................................................................................................................... 4
3.2 Waveform Capturing Using Active Probe ..................................................................................... 4
3.3 Measuring Jitter and Phase Noise ................................................................................................. 5
3.4 Current Measurement .................................................................................................................. 6
Appendix A .................................................................................................................................................... 7
1
Introduction
The SiT6723EBB evaluation board (EVB) is designed for use with SiTime's Elite
pin, 7.0 x 5.0 mm x mm ceramic packages and LVCMOS output type. It enables the evaluation of key
functionalities of these precision Super-TCXOs in two configuration modes: TCXO and DCTCXO with I
The SiT6723EBB supports 7.0 x 5.0 mm x mm package size including the following products:
Base Part Number
SiT5501
SiT5503
SiT5541
SiT5543
SiT6723EBB User Manual | Rev 1.1
Type
Super-TCXO
Super-TCXO
Ruggedized Super-TCXO
Ruggedized Super-TCXO
Page 1 of 10
X™
Super-TCXOs in the 10-
Output frequency
1 MHz - 60 MHz
1 MHz - 60 MHz
1 MHz - 60 MHz
1 MHz - 60 MHz
2
C.
Package
7.0 x 5.0 CQFN
7.0 x 5.0 CQFN
7.0 x 5.0 CQFN
7.0 x 5.0 CQFN
www.sitime.com
Advertisement
Related Manuals for SiTime SiT6723EBB
Summary of Contents for SiTime SiT6723EBB
-
Page 1: Table Of Contents
7.0 x 5.0 mm x mm ceramic packages and LVCMOS output type. It enables the evaluation of key functionalities of these precision Super-TCXOs in two configuration modes: TCXO and DCTCXO with I The SiT6723EBB supports 7.0 x 5.0 mm x mm package size including the following products: Base Part Number... -
Page 2: O Descriptions
Probing points for accurate waveform measurement Connector access for controlling the output frequency via I SiTime typically ships the EVB with the Super-TCXO mounted using SiTime recommended reflow profile. The Super-TCXO device should only be evaluated in its original soldered down state for best signal integrity and frequency stability. -
Page 3: Evb Usage Descriptions
“DNP” are not assembled. Shipment Configuration SiT6723EBB is shipped configured for buffered output allowing connecting it to the instrument input using 50 Ω coax cable. Details on the board assembly for shipment configuration can be found on the schematic (see... -
Page 4: C Support
For waveform measurement, it's recommended to remove resistor R26. Please refer to Figure A2 for test point locations on the SiT6723EBB. If the soldering probe is used, it is recommended to use R28 resistor pads or solder it over it if necessary (Figure 1). -
Page 5: Measuring Jitter And Phase Noise
Figure 2: Signal measurement using probe Measuring Jitter and Phase Noise For jitter and phase noise measurements, buffered output configuration is recommended. SiTime TCXO was not designed to drive 50 Ω load directly so buffer avoids excessive current draw from the device output. -
Page 6: Sit6723Ebb Evaluation Board User Manual
It is recommended to measure the voltage on DUT VDD and adjust for any drop on the DMM to ensure known VDD voltage on the device. VDD adjustment must be completed before every current measurement. SiT6723EBB User Manual | Rev 1.1 Page 6 of 10 www.sitime.com... - Page 7 CLK_IN Buff_VCC Buff_Out 0.1uF LMK1C1102PWR Buff_Out Output Pad5 DUT_Vdd Vdd_sense 0.1uF Pad6 LVCMOS-to-sine wave filter option Pad7 Pad8 Pad9 Pad10 Pad11 Pad12 Pad13 Pad14 Figure A1: SiT6723EBB electrical schematics SiT6723EBB User Manual | Rev 1.1 Page 7 of 10 www.sitime.com...
- Page 8 Connectors part number mating connector associated products Power/Power adjust WM10299-ND WM2002-ND WM1114TR-ND Buffer power WM10297-ND WM2011-ND Buffer power supply jumper Z5275-ND S9342-ND Frequency control via I2C 2057-PH1RB-05-UA-ND SiT6723EBB User Manual | Rev 1.1 Page 8 of 10 www.sitime.com...
- Page 9 SiT6723EBB Evaluation Board User Manual Probe test points VDD sense Signal Figure A2: SiT6723EBB layout SiT6723EBB User Manual | Rev 1.1 Page 9 of 10 www.sitime.com...
- Page 10 © SiTime Corporation, January 2025. The information contained herein is subject to change at any time without notice. SiTime assumes no responsibility or liability for any loss, damage or defect of a Product which is caused in whole or in part by (i) use of any circuitry other than circuitry embodied in a SiTime product, (ii) misuse or abuse including static discharge, neglect or accident, (iii) unauthorized modification or repairs which have been soldered or altered during assembly and are not capable of being tested by SiTime under its normal test conditions, or (iv) improper installation, storage, handling, warehousing or transportation, or (v) being subjected to unusual physical, thermal, or electrical stress.
