Frecon FR500T Series Manual

Solar pumping drive

Advertisement

Quick Links

FR500T special drives are developed for power supply of water pumps, based on the core control
arithmetic of FR500 vector control drives, combined with the control requirements of PV water pump
application. The function of maximum power tracking, dormant at weak light, wake up at strong light,
high water level dormant, under-load pre-warning and other control protection functions can ensure
normal operation of water pumps according to the customers' requirements to switch to the grid power
supply.
Please refer to this manual to commission the drive, product maintenance refer to FR500 user
manual.
IMPORTANT NOTES
◆To illustrate the details of the products,pictures in this manual based on products with outer
casing or safety cover being removed. When using this product, please be sure to well install
outer casing or covering by the rules, and operating in accordance with the manual contents.
◆The illustrations in this manual are for illustration only and may vary with different products
you have ordered.
◆The company is committed to continuous improvement of products, product features will
continue to upgrade, the information provided is subject to change without notice.
◆If there is any questions when using, please contact our regional agents or our customer
service center:(+86-0755-88605930)
◆For other products, please visit our website. http://www.frecon.com.cn
FR500T&FR150TSeries Solar Pumping Drive
Preface
- 1 -

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FR500T Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Frecon FR500T Series

  • Page 1 ◆If there is any questions when using, please contact our regional agents or our customer service center:(+86-0755-88605930) ◆For other products, please visit our website. http://www.frecon.com.cn - 1 -...
  • Page 2 FR500T&FR150TSeries Solar Pumping Drive - 2 -...
  • Page 3: Table Of Contents

    ANEL OWER UPPLY OMMISSIONING 2.2 G ................. - 20 - RID OR ENERATOR POWER SUPPLY WIRINGS 2.3 W FRECON VFD ........- 22 - IRING DIAGRAM BETWEEN AND SINGLE PHASE MOTOR 2.4 P ..................- 26 - RODUCT ERMINAL ONFIGURATION CHAPTER 3 FUNCTION PARAMETERS ...................
  • Page 4: Chapter1 Productoverview

    FR500T&FR150TSeries Solar Pumping Drive Chapter1 ProductOverview 1.1 Name Plate Figure 1-1 Name Plate Model Instruction Model numbers on name plate consist of numbers, symbols, and letters, to express its respective series, suitable power type, power level and other information. FR500T-4T-2.2B-IN Products series Number Economical FR500T: Solar Pump...
  • Page 5: Product Specifications

    FR500T&FR150TSeries Solar Pumping Drive 1.2 Product Specifications 1.2.1 Electric specification of AC110V Input product Table 1-1Electric specification of AC110V Input product Recommend Maximum Rated Input Rated ed Solar Input DC AC Current Output Adaptive Model Power (kW) Current (A) Current (A) Motor (kW) FR150T-1S-0.7B 0.25...
  • Page 6 FR500T&FR150TSeries Solar Pumping Drive 1.2.2 Electric specification of AC220 Input product Table 1-2Electric specification of AC220 Input product Recommen Maximum Rated Rated Adaptive Model ded Solar Input DC Input AC Output Motor Power (kW) Current (A) Current (A) Current (A) (kW) FR150T-2S-0.4B 10.6...
  • Page 7 FR500T&FR150TSeries Solar Pumping Drive 2S: 1PH220V(-15%~20%) Input voltage 2T: 3PH 220V(-15%~20%) Output specification Rated output voltage 3PH 220V Output frequency 0~600.00Hz(default: 0~50.00Hz) Protection Lighting Protection, over-current, overvoltage, output phase-lose, Built-in Protection under-load, under-voltage, short circuit, overheating, water pump run dry etc. 1.2.3 Electric specification of AC 380V&DC 540V Input product Table 1-3 Electric specification of AC 380V&DC 540V Input product Recommen...
  • Page 8 FR500T&FR150TSeries Solar Pumping Drive 48.1 116.2 FR500T-4T-037 58.5 137.3 FR500T-4T-045 71.5 169.0 FR500T-4T-055 97.5 232.3 FR500T-4T-075 117.0 274.6 FR500T-4T-090 143.0 337.9 210.0 FR500T-4T-110 171.6 401.3 253.0 FR500T-4T-132 208.0 485.8 304.0 FR500T-4T-160 559.7 350.0 FR500T-4T-185 612.5 377.0 FR500T-4T-200 FR500T-4T-220 286.0 675.8 426.0 FR500T-4T-250 325.0...
  • Page 9 FR500T&FR150TSeries Solar Pumping Drive Starting Voltage Range 230~900VDC Grid or backup generator input Input Voltage 3PH 380V(-15%~30%) Output specification Rated output voltage 3PH 380V Output frequency 0~600.00Hz(Default 0~50.00Hz) Protection Lighting Protection, over-current, overvoltage, output phase-lose, Built-in Protection under-load, under-voltage, short circuit, overheating, water pump run dry etc.
  • Page 10 FR500T&FR150TSeries Solar Pumping Drive 31.7 31.3 FR150I-2S-4.0B 42.2 40.0 FR150I-2S-5.5B Input specification Solar Power Input Maximum Input DC 450VDC Voltage Recommended Voc 360~430VDC Range Recommended MPPT 250~350VDC Voltage Range Starting Voltage Range 80~450VDC Grid or backup generator input Input voltage 1PH220V(-15%~20%) Output specification Rated output voltage...
  • Page 11 FR500T&FR150TSeries Solar Pumping Drive Output specification Rated output voltage 3PH 220V Output frequency 0~600.00Hz(default: 0~50.00Hz) Protection Lighting Protection, over-current, overvoltage, output phase-lose, Built-in Protection under-load, under-voltage, short circuit, overheating, water pump run dry etc. - 11 -...
  • Page 12: Dimension Drawing

    FR500T&FR150TSeries Solar Pumping Drive 1.3 Dimension Drawing ◆FR150T(0.2~22KW) Fig 1-3Product size chart ◆FR150T(30~160KW) Fig 1-4Product size chart Table 1-6 Configuration, mounting dimensions and weight External and installation dimensions (mm) Install Install Model (kg) hole hole FR150T-1S-0.7B FR150T-2S-0.2B FR150T-2S-0.4B 38.5 0.95 FR150T-2S-0.7B FR150T-4T-0.7B FR150T-4T-1.5B...
  • Page 13 FR500T&FR150TSeries Solar Pumping Drive FR150T-2S-2.2B-IN FR150T-4T-2.2B FR150T-4T-4.0B FR150T-4T-5.5B FR150T-4T-7.5B FR150T-4T-011B FR150T-4T-015B FR150T-4T-018B FR150T-4T-022B FR150T-4T-030B 11.6 - 13 -...
  • Page 14 FR500T&FR150TSeries Solar Pumping Drive 1.3.2 FR500T ◆4~22kW Dimensions and wall mounting dimensions ~ Figure 1-4 4 22kW Wall Installation Diagram ◆30~450kW Dimensions and installation dimensions Figure 1-5 30~450kw Wall Mounting Diagram - 14 -...
  • Page 15 FR500T&FR150TSeries Solar Pumping Drive table 1-6 Configuration, mounting dimensions and weight External and installation dimensions(mm) Weight Mounting Model NO. (Kg) Hole Diameter 3-Phase:380V,50/60Hz Range:-15%~+30% FR500T-4T-4.0B 116.6 106.6 186.6 176.6 FR500T-4T-5.5B FR500T-4T-7.5B FR500T-4T-011B (177) FR500T-4T-015B FR500T-4T-018B (185) FR500T-4T-022B FR500T-4T-030B 12.9 FR500T-4T-037 FR500T-4T-045 FR500T-4T-055 FR500T-4T-075...
  • Page 16 FR500T&FR150TSeries Solar Pumping Drive 1.3.3 FR150I ◆Dimensions and wall mounting dimensions Figure 1-7Product size chart Table1-6Configuration, mounting dimensions and weight External and installation dimensions (mm) Install Install Model (kg) hole hole FR150I-2S-0.4B 38.5 FR150I-2S-0.7B FR150I-2S-1.5B FR150I-2S-2.2B FR150I-2S-4.0B FR150I-2S-5.5B - 16 -...
  • Page 17: Chapter 2 Commissioning Guide

    FR500T&FR150TSeries Solar Pumping Drive Chapter 2 Commissioning Guide 2.1 SolarPanel Power Supply Commissioning 1. Wiring drawings of below drives shown as Figure 2-1&2-2: FR150T series, FR500T series. Solar panels U/T1 R/L1 V/T2 S/L2 FR500T W/T3 T/L3 +24V Short film +24V...
  • Page 18 FR500T&FR150TSeries Solar Pumping Drive Solar panels ( - ) + 24 V Short film + 24 V FR 150 T RUN / STOP DI 1 DI 2 DI 3 Y 2 / HO DI 4 R 1 A R 1 B R 1 C DI 7 / HI Note : The common...
  • Page 19 FR500T&FR150TSeries Solar Pumping Drive Commissioning steps: 1. Please wirings as Figure2-1&Figure2-2 according to different drive powers, check and confirm the wirings to be correct, and then close Q1. 2. Setting the Motor Parameters Setting the parameter of name plate on motor F08.01~F08.05。 3.
  • Page 20: Grid Or Generator Power Supply Wirings

    FR500T&FR150TSeries Solar Pumping Drive Grid or Generator power supply wirings Wiring drawings of below drives shown as below Solar panels U/T1 R/L1 Grid or V/T2 S/L2 generator set FR500T W/T3 T/L3 +24V +24V RUN/STOP Operation panel PV Voltage Given selection Y2/HO DI7/HI Note: The common...
  • Page 21 FR500T&FR150TSeries Solar Pumping Drive Solar panels Solar panels Grid or Grid or generator set generator set +24V +24V Short film Short film +24V +24V FR150T FR150T RUN/STOP RUN/STOP Y2/HO Y2/HO DI7/HI DI7/HI Note: The common Note: The common terminal of PV100 is terminal of PV100 is Tank Tank...
  • Page 22: Wiring Diagram Between Frecon Vfd And Single Phase Motor

    FR500T&FR150TSeries Solar Pumping Drive 2.3Wiring diagram between FRECON VFD and single phase motor 2.3.1 Single phase motor introduction Single phase motor generally means asynchronous single phase motor powered by single phase AC 220V, there’re two phase winding in motor stator and motor rotor is common squirrel cage. The...
  • Page 23 FR500T&FR150TSeries Solar Pumping Drive Internal wiring of single phase motor with double capacitors is as below: Running capacitor Centrifugal Starting switch capacitor Secondary Main winding 220VAC winding Figure 2-8 Internal wiring of motor with double capacitors Resistor starting mode single phase motor, and internal wiring is as below: Centrifugal switch Secondary...
  • Page 24 FR500T&FR150TSeries Solar Pumping Drive 2.3.2 Wiring between VFD and motor(Capacitor removable) Connect main and secondary winding of motor to drive UVW, then drive can work. But due to the motor winding difference, motor forward wiring must be as below, if not cause motor too heat 220VAC Secondary Main winding...
  • Page 25 FR500T&FR150TSeries Solar Pumping Drive 220VAC Secondary Main winding winding FR500T Figure 2-14 Reverse wiring between VFD FR500T and motor Note: After wiring completed, need to set F08.00=2. 2.3.3 Wiring between VFD and motor(Capacitor is not removable) If the capacitor in motor is not removable, the wiring is as below. The forward and reverse is determined by VW wiring sequence.
  • Page 26: Product Terminal Configuration

    FR500T&FR150TSeries Solar Pumping Drive Product Terminal Configuration 2.4.1 FR150T Main Circuit Terminals a: Single-phaseMain Circuit Terminals (≤2.2kW) Fig.2-17(a) Single-phase main circuit terminals(≤2.2kW) Fig.2-17(b) Single-phase main circuit terminals(FR150T-2s-2.2-IN) b: Three-phase Main Circuit Terminals ◆New design: Fig.2-18aThree-phase Main Circuit Terminals (new design) ◆Old solution Fig.2-18bThree-phase Main Circuit Terminals (old solution) - 26 -...
  • Page 27 FR500T&FR150TSeries Solar Pumping Drive ◆0.7~4.0kWMain Circuit Terminals (4T) Fig.2-19a0.7~4.0kWMain Circuit Terminals (4T) ◆5.5~7.5 kW Main Circuit Terminals (4T): T U V (+) (-) POWER Fig.2-19b 5.5~7.5kW Main Circuit Terminals(4T) ◆11~22 kW Main Circuit Terminals (4T) (+) (-) Fig.2-19c 11~22kW Main Circuit Terminals(4T) ◆30~37kW Main Circuit Terminals (4T): (+) (-) Fig.2-19d 30~37kW Main Circuit Terminals (4T)
  • Page 28 FR500T&FR150TSeries Solar Pumping Drive T U V (+) (-) POWER Fig.2-204~5.5kW Schematic of main circuit terminals ◆7.5~22KW Main Circuit Terminals (+) (-) Fig.2-217.5~22kW Schematic of main circuit terminals ◆30~37KW Main Circuit Terminals (+) (-) Fig.2-2230~37kW Schematic of main circuit terminals - 28 -...
  • Page 29 FR500T&FR150TSeries Solar Pumping Drive ◆45~90KW Main Circuit Terminals: (+) (-) Fig.2-2345~90kW Schematic of main circuit terminals ◆110~132KW, 250~280KW,315~450KW Main Circuit Terminals: Fig.2-24110~132KW, 250~280KW,315~450KW Main Circuit Terminals ◆160~220KW Main Circuit Terminals: Fig.2-25160~220KW Main Circuit Terminals - 29 -...
  • Page 30 FR500T&FR150TSeries Solar Pumping Drive 2.4.3FR150I Main Circuit Terminals ◆ FR150I(0.4~1.5kW) Main Circuit Terminals FR150I(0.4~1.5kW) Main Circuit Terminals Fig.2-26 ◆ FR150I(2.2kW) Main Circuit Terminals T U V (+) (-) POWER FR150I(2.2kW) Main Circuit Terminals Fig.2-27 ◆FR150I4.0~5.5kW) Main Circuit Terminals: (+) (-) FR150I(4.0~5.5kW) Main Circuit Terminals Fig.2-28 - 30 -...
  • Page 31 FR500T&FR150TSeries Solar Pumping Drive Table 2-1Main Circuit Terminal Functions Terminal marks Designation and function of terminals. AC power input terminals for connecting to 3-phase R, S, T AC380V power supply. L, N AC220V power supply. AC output terminals of drive for connecting to 3-phase U, V, W induction motor.
  • Page 32 FR500T&FR150TSeries Solar Pumping Drive 2.4.4 Control Circuit Terminals ◆A: FR150T & FR150I(0.4~1.5kW) Control Circuit Terminals 485+ 485- R1A R1B R1C DI7/HI +24V +10V Figure 2-28a FR150T & FR150I(0.4~1.5kW) Control Circuit Terminals ◆B: FR150I(2.2~5.5kW) Control Circuit Terminals 485+ DI7/HI 485- R1A R1B R1C +24V +10V Figure 2-28b FR150I(2.2~5.5kW) Control Circuit Terminals...
  • Page 33 FR500T&FR150TSeries Solar Pumping Drive Table 2-2 Control Circuit Terminal Functions Terminal Symbol Terminal Name Description Power Supply Output +10V Power Supply, Maximum Output Current: 10mA. Generally use for power supply of +10V Power +10V-GND external potentiometer, resistance range of Supply potentiometer: 1~5kΩ...
  • Page 34 FR500T&FR150TSeries Solar Pumping Drive 485+-485- Communication Speed: Terminals 4800/9600/19200/38400/57600/115200bps. RS485 toggle switch on control board, setting the Communication terminal matching-resister Shield Ground Others Shield Grounding It’s use for grounding the shield of terminal-wire When connected to operation board, the longest External Keyboard communication distance is up to 50m, adopt the Interface...
  • Page 35: Chapter 3 Function Parameters

    FR500T&FR150TSeries Solar Pumping Drive Chapter 3 Function Parameters 3.1 The Basic Function Parameters Table 3-1 Basic Function Parameters Param. Parameter Name Setting Range Default Group F00: System Parameters Setting of User F00.00 0~65535 × Password 0: Display all parameters 1: Only display F00.00, F00.01 and user-defined parameters F00.01 Display of Parameters...
  • Page 36 FR500T&FR150TSeries Solar Pumping Drive Hundreds place: AI3 (same as AI1) 0: Digital 0utput terminal 2 F00.11 Y2/HO input mode × 1: Pulse output Unit' place: PWM modulation mode 0: Fixed carrier 1: Random carrier 2: Derating of fixed carrier 3: Derating of random carrier Ten’...
  • Page 37 FR500T&FR150TSeries Solar Pumping Drive Command Source 1: keypad potentiometer 2: Analog input AI1 3: Communication 4: Multi-reference 5: PLC 6: Process PID output 7: X7/HI pulse input 8:AI2 9:AI3 Digital Setting of Master F01.02 50.00Hz △ 0.00~Fmax Frequency 0: Auxiliary digital setting (F01.04) 1: keypad potentiometer 2: Analog input AI1 3: Communication...
  • Page 38 FR500T&FR150TSeries Solar Pumping Drive 1:Rotational speed track and restart Ten’s digit: 0:Ungrounded short-circuit detection 1:Grounding short-circuit detection before the first starts 2:Grounding short-circuit detection before each starts Hundred’s digit 0:Track from zero speed 1:Track from max frequency Thousand’s:Select if Jog function takes the priority 0:Disable 1:Enable...
  • Page 39 FR500T&FR150TSeries Solar Pumping Drive F03.03 Decel time 2 15.0s △ 0.0~6000.0s △ F03.04 Accel time 3 0.0~6000.0s 15.0s △ F03.05 Decel time 3 0.0~6000.0s 15.0s △ F03.06 Accel time 4 0.0~6000.0s 15.0s F03.07 Decel time 4 15.0s △ 0.0~6000.0s F03.08 Jog accel time 15.0s △...
  • Page 40 FR500T&FR150TSeries Solar Pumping Drive 24: PID adjustment direction 25: PID integration paused 26: PID parameter switch 27: Swing frequency pause(output the currentfrequency) 28: Swing frequency reset(output the central frequency) 29: Run command switched to keypad contro 30: Run command switched to terminal control 31: Run command switched to communication control...
  • Page 41 FR500T&FR150TSeries Solar Pumping Drive action can clear UP/DOWN or not 0: Not zero-clearing 1: Zero-clearing Terminal UP/DOWN 1.00Hz/ F04.17 frequency change step △ 0.00~50.00Hz 0.00:Disabled 200ms size 0: Level effective 1: Edge trigger +Level Terminal action selection F04.18 effective(When power on) ×...
  • Page 42 FR500T&FR150TSeries Solar Pumping Drive F05.06 R1 output delay time 0.0s △ 0.0~6000.0s △ F05.07 R2 output delay time 0.0~6000.0s 0.0s Unit's place: Y1 0: Positive logic 1: Negative logic Enabled state of digital Decade: Y2 (same as unit's place) F05.08 0000 ×...
  • Page 43 FR500T&FR150TSeries Solar Pumping Drive Set value corresponding F06.09 to minimum input of 0.0% △ -100.0~100.0% curve AI2 Input of inflection point Minimum input of curve AI1~Input △ F06.10 100.0% 1 of curve AI2 of inflection point 2 of curve AI2 Set value corresponding △...
  • Page 44 FR500T&FR150TSeries Solar Pumping Drive Set value corresponding F06.33 to minimum input of curve 0.0% △ -100.0~100.0% Maximum input of curve 50.00kH Minimum input of curve HI~ △ F06.34 100.00kHz Set value corresponding △ F06.35 to maximum input of curve -100.0~100.0% 100.0% △...
  • Page 45 FR500T&FR150TSeries Solar Pumping Drive async motor 1 defined Rotor resistance R2 of Model F08.09 0.001~65.535Ω × async motor 1 defined Leakage inductance L1 Model F08.10 0.01~655.35mH × of async motor 1 defined Mutual inductance L2 of Model F08.11 0.1~6553.5mH × asynchronous motor 1 defined No-load current of...
  • Page 46 FR500T&FR150TSeries Solar Pumping Drive Multi-point V/F voltage 2 △ F09.06 0.0~100.0 14.0% (V2) Multi-point V/F frequency △ F09.07 F09.05~F09.09 25.00Hz 3(F3) Multi-point V/F voltage 3 F09.08 50.0% △ 0.0~100.0 (V3) Multi-point V/F frequency △ F09.09 F09.07~rated motor frequency 50.00Hz 4(F4) Multi-point V/F voltage 4 F09.10 100.0%...
  • Page 47 FR500T&FR150TSeries Solar Pumping Drive ASR high-speed △ F10.05 0.001~30.000s 0.100s integration time Ti2 ASR switching △ F10.06 F10.03~Fmax 10.00Hz frequency 2 F10.07 ASR input filtering time 3.0ms △ 0.0~500.0ms F10.08 ASR output filtering time 0.0ms △ 0.0~500.0ms △ F10.09 Vector control slip gain 50~200% 100% Digital setting of torque...
  • Page 48 FR500T&FR150TSeries Solar Pumping Drive PMSM r flux-weakening △ F10.30 0.0~500.0% 50.0% gain Kp PMSM flux-weakening △ F10.31 0.00~60.00s 0.50s integral Ti PMSM flux-weakening F10.32 100.0% △ 0.0~200.0% limit PMSM excitation current F10.33 F10.34~600.00Hz 15.00Hz △ frequency high point PMSM excitation current F10.34 10.00Hz 0.0~F10.33...
  • Page 49 FR500T&FR150TSeries Solar Pumping Drive Ten's digit: EEPROM read/write fault (Err15) (Same as unit's place) Hundred's digit: Communication overtime error (Err18) (Same as unit's place) Thousand's digit: PID feedback loss (Err19) (Same as unit's place) Ten thousand's digit: Continuous running time reached (Err20) (Same as unit's place) Unit's place: Module temperature detection disconnection(Err24)
  • Page 50 FR500T&FR150TSeries Solar Pumping Drive 0: Disabled Action selection at F11.24 instantaneous power 1: Deceleration × failure 2: Bus voltage constant control Decel time at F11.25 instantaneous power 5.0s △ 0.0~6000.0s failure 0: Disabled F11.26 Rapid current limit × 1: Enabled Times of automatic F11.27 0~20...
  • Page 51 FR500T&FR150TSeries Solar Pumping Drive 1:keypad potentiometer 2: AI1 3: Process PID output 4: X7/HI pulse input 5: AI2 6: AI3 Unit's place: PLC running mode 0: Stop after a single cycle 1: Continue to run with the last frequency after a single cycle 2: Repeat cycles Decade: started mode 0: Continue to run from the step of...
  • Page 52 FR500T&FR150TSeries Solar Pumping Drive time of simple PLC reference 3 Acceleration/deceleration △ F12.38 time of simple PLC 0~3 reference 4 Acceleration/deceleration F12.39 time of simple PLC △ 0~3 reference 5 Acceleration/deceleration F12.40 time of simple PLC △ 0~3 reference 6 Acceleration/deceleration F12.41 time of simple PLC...
  • Page 53 FR500T&FR150TSeries Solar Pumping Drive F13.01 PID digital setting 50.0% △ 0.0~100.0% 0: AI1 1: AI2 2: Communication 3: AI1+AI2 4: AI1-AI2 F13.02 PID feedback × 5: Max{AI1,AI2} 6: Min{AI1,AI2} 7: DI7/HI pulse input 8: AI3 PID setting feedback △ F13.03 0.0~6000.0 100.0 range...
  • Page 54 FR500T&FR150TSeries Solar Pumping Drive 0.0%: Not judging feedback loss Detection time for F13.25 down limit of PID 1.0s × 0.0~30.0s feedback loss Unit’s digit:PID operation selection when stop 0:Do not operate when stop 1:Operate when stop Ten’s digit:output is limited by output frequency 0:No limited 1:limited...
  • Page 55 FR500T&FR150TSeries Solar Pumping Drive Number of pulses per F14.06 0.1~6553.5 100.0 × meter Unit’s place: stop when the length reaches 0: Not stop 1: Stop Ten’s place: length calculation Command when the F14.07 × method length attained 0: pulse by pulse 1: Reference maximum frequency 2: Refer to Ai1 channel 3: Refer to AI2 channel...
  • Page 56 FR500T&FR150TSeries Solar Pumping Drive Communication Mode 1:The drive is the master The Master 0: Set frequency F15.06 Communication × 1: Current running frequency Sending Data 0: No return Message return when F15.07 communication error 1: Return 0: Positive and negative △...
  • Page 57 FR500T&FR150TSeries Solar Pumping Drive stop status LED displayed 0~99(correspond U00.00~ F16.10 parameters setting 4 on △ U00.99) stop status F16.11 Speed display coefficient 0.00~100.00 1.00 △ F16.12 Power display coefficient 0.0~300.0% 100.0% △ Display error between F16.13 0.00Hz~5.00Hz 0.10Hz △ U00.00 and U00.01 Group F17 User-defined Display Parameters User-defined Display...
  • Page 58 FR500T&FR150TSeries Solar Pumping Drive User-defined Display △ F17.24 00.00~49.99 13.02 Parameter 24 User-defined Display △ F17.25 00.00~49.99 13.08 Parameter 25 User-defined Display F17.26 13.09 △ 00.00~49.99 Parameter 26 User-defined Display △ F17.27 00.00~49.99 00.00 Parameter 27 User-defined Display F17.28 00.00 △...
  • Page 59 FR500T&FR150TSeries Solar Pumping Drive Virtual VDO4 output F22.15 0.0s~6000.0s 0.0s △ delay time Virtual VDO5 output F22.16 0.0s~6000.0s 0.0s △ delay time VDO5、 VDO4、 VDO3、 VDO2、 VDO1 VDO output terminal F22.17 positive and negative 00000 0: Positive logic △ logic 1: Negtive logic U00 Group: Status Monitoring U00.00...
  • Page 60 FR500T&FR150TSeries Solar Pumping Drive extension card monitoring U01 Group: Failure Record U01.00 Current Fault Category Err00~Err41 Err00 ⊙ Output frequency of the U01.01 0.00~Fup 0.00Hz ⊙ current fault Output current of the U01.02 0.0A 0.0~3000.0A ⊙ current fault U01.03 c of the current fault 0~1200V ⊙...
  • Page 61 FR500T&FR150TSeries Solar Pumping Drive Voltage Given Mode (Constant Voltage appr Given) 1:Tracking of Max Power Point (MPPT) 2:Automatic MPPT 3:Fast MPPT 4:Quick start MPPT H00.03 Vmpp voltage CVT setting 540V △ 0~750V Mini voltage reference of H00.04 0~Max Voltage 500V ×...
  • Page 62 FR500T&FR150TSeries Solar Pumping Drive Power automatic switch 0:disable H00.27 × function 1:Enable Time of automatic switch △ H00.28 1~600Min 60Min to solar power H00.29 Automatic switch delay 3.0s △ 0.1~10.0s Current power source in 0: Grid power H00.30 ⊙ automatic switch function 1: Solar power Pump rated flow H00.31...
  • Page 63: H00 Group: Detailed Explanation Of Function Code

    FR500T&FR150TSeries Solar Pumping Drive 3.2 H00 Group: Detailed Explanation of Function Code 0:Null Pump Machine Control H00.00 × 1:Valid 0:Null For standard model 1:Valid For PV pumps special drive,H00 Group: Invalid 0:Mains Selection of Drive Power H00.01 × 1:Solar Panel 0:Mains Drive power supply through the grid, frequency given refer to group of F01, HOO.02~H00.12 invalid.
  • Page 64 FR500T&FR150TSeries Solar Pumping Drive △ H00.03 Vmpp voltage CVT setting 0~750V 540V When H00.02 is zero, reference voltage will be given by this function code. MPPT mini voltage H00.04 0~Max Voltage 500V × reference MPPT max voltage H00.05 Max Voltage~750V 600V ×...
  • Page 65 FR500T&FR150TSeries Solar Pumping Drive 0:Null Feedback channel selection of 1:AI1 H00.15 × reservoir water level 2:AI2 3:AI3 0:Null Control of water level is invalid. 1:AI1 AI1 for analog signal source of water-level control 2:AI2 AI2 for analog signal source of water-level control 3:AI3 AI3 for analog signal source of water-level control Clean up the delay time of...
  • Page 66 FR500T&FR150TSeries Solar Pumping Drive 0:Positive direction,higher detection value higher water Water level direction level H00.24 × detection 1:Negative position,higher detection value lower water level To set the relationship between hydraulic probe detected signal and water level 0: Positive direction, higher detection value higher water level 1: Negative position, higher detection value lower water level H00.25 Weak light voltage...
  • Page 67 FR500T&FR150TSeries Solar Pumping Drive Solar panels Grid +24V DI7/HI Figure 3-2 Automatic switch between grid and solar power wiring Pump rated flow △ H00.31 0.0~1000.0 m3/h 6.0 m3/h Pump rated head H00.32 △ 0.0~500.0m Pump cumulative flow 0: Invalid H00.33 △...
  • Page 68: Chapter4 Troubleshooting And Countermeasures

    Before asking support, users can self-check according to this chapter tips, and analyze the fault reasons, get the solutions. If fault still can’t be solved, please ask for service, contact with agents or directly to FRECON Operator...
  • Page 69 FR500T&FR150TSeries Solar Pumping Drive during deceleration dragging 2、Cancel the external the motor to work power or install braking 3、Deceleration time is too resistor short 3、Prolong the deceleration 4、No installation of braking time resistor 4、Install braking resistor 1、 The voltage adjusted to a 1、Input voltage is too high normal range Constant-speed...
  • Page 70 FR500T&FR150TSeries Solar Pumping Drive mechanical 2、Drive selection is too small 2、Select drive with a larger power Fault protection 1、 Input the external fault signal Err13 1、Reset to run of external input by multi-function terminal 1、Ambient temperature is too 1、Lowering the ambient high temperature 2、Air-channel blocked...
  • Page 71 FR500T&FR150TSeries Solar Pumping Drive conditions. 1、Reduce the load or 1、Load is too large or motor check the conditions of With-wave Err26 rocked-rotor motor or mechanical current limit fault 2、Drive selection is too small 2、Select the drive with larger power 1、Grid voltage is too low 1、Check the grid voltage Soft-start relay Err27...
