Humanscale Float Micro Assembly Instructions Manual page 2

Tools Required
①
Philips Head Screwdriver
Parts Included
③
Worksurface
⑥
Base Plate with Casters
⑧
14x ST4.2x16mm
Worksurface Mounting Screws
IMPORTANT SAFETY INSTRUCTIONS
• NEVER MOUNT UNAUTHORIZED ITEMS TO THE TABLE (I.E., MONITOR ARMS, CHARGING DEVICES, POWER STRIPS/CORDS, ETC.).
• Before moving the table, clear objects from Worksurface and place the Worksurface in the lowest position.
• Use two hands on the side of the table when raising and lowering the Worksurface.
• Do not raise or lower the table with open beverages on the Worksurface.
• Avoid any fast or hard impacts on the sides of Worksurface to avoid unintentional tipping.
• When in use ensure no blockage or obstruction is near to prevent tipping.
DO NOT:
• Put more than 12 lbs on the Worksurface.
• Lean on the Worksurface when it is in the raised position.
• Move the table in the raised position.
• Move the table over angled surfaces, platforms, coarse/textured/uneven floors.
• Replace the Worksurface with another worksurface.
• Use the table on angled surfaces, platforms, coarse/textured/uneven floors.
• Place the product outside or expose it to outside elements (wind, excessive sunlight, continuous moisture).
• Sit or stand on the Worksurface.
• Stand or ride on the Base Plate.
• Take apart the Lift Column with Actuator.
• Tamper with internal mechanism.
• Use the product on stairs or ramps.
• Modify Casters or Glides, either component or configuration.
• Apply excessive heat to any part of the product.
2
②
2.5mm Hex Key (Included)
④
Top Plate
⑦
4x Glides
⑨
4x M6x35mm
Top Plate Mounting Screws
⑤
Lift Column
with Actuator
⑩
3x M6x25mm
Base Plate Mounting Screws
