電控參數說明書
ELECTRONIC CONTROL PARAMETER MANUAL
ASL-PSM101
ASL-PSM102
ASL-PSM103

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ASL-PSM101 and is the answer not in the manual?

Questions and answers

Related Manuals for Siruba ASL-PSM101

Summary of Contents for Siruba ASL-PSM101

  • Page 1 電控參數說明書 ELECTRONIC CONTROL PARAMETER MANUAL ASL-PSM101 ASL-PSM102 ASL-PSM103...
  • Page 2 Foreword Thank you for using our Computerized Control System for Special Sewing Machine. It is appreciated that you do read this manual carefully in order to operate the machine correctly and effectively. If the user operates the machine contrary to regulations herein, thus cause loss to user or third party, we will not take responsibility.
  • Page 3 Safety Matters for Attention 1. Signs & Definitions of Safety Marks This Operation Manual and the Safety Marks printed on the products are to enable you to use this product correctly so as to be away from personal injury. The signs and definitions of Marks are shown in below: The incorrect operation due to negligence will cause the serious personal injury or even death.
  • Page 4 When you tilt or erect the head of sewing machine, please use both of your hand in that operation. And never press the sewing machine with strength. If the sewing machine loses its balance, it will fall into floor thus causes the personal injury or mechanical damage.

  • Page 5: Table Of Contents

    CONTENTS 1.General..................................1 1.1. Overview................................1 1.2. Features and Parameters..........................1 1.3. Precautions for safe use........................... 2 1.4. Precautions for Usage............................4 2. Main Interface Introduction............................6 2.1 Main Interface P1 Function Introduction......................6 2.1.1 Datum..............................8 2.1.2 RFID..............................10 2.1.3 Pattern Preview............................12 2.1.4 Jump..............................13 2.1.5 Whole Image Modification........................13 2.2 Main Interface P2 Function Introduction.......................
  • Page 6 3.5.13 Installment Password.........................41 3.5.14 Work Statistics Function Settings......................46 3.6. User Parameter (U Parameter)........................47 3.6.1 Enter the Function Parameter Setting Interface.................. 47 3.6.2 Parameter Change Method........................47 3.6.3 Parameters Modified..........................48 3.6.4 Parameter Customization Method....................... 49 3.6.5 User Parameter Table...........................49 3.7. Mechanical Parameters (K Parameters)......................59 3.7.1.

  • Page 7: General

    1.General 1.1. Overview In this series of industrial sewing machine computer control system, Main Motor is driven by AC servo control technology of advanced level in the world, which has the characteristics of large torque, high efficiency, stable speed and low noise. The diversified design of the operation panel can meet the supporting requirements of different customers;...

  • Page 8: Precautions For Safe Use

    1.3. Precautions for safe use  Installation Control box   Please follow the instructions to install properly Accessories   Please turn off the power and unplug the power plug before installing other accessorie Power cord   Please do not use gravity to hold down the power cord or excessively distort the pow er cord.
  • Page 9 Customers are kindly requested not to modify or change this control device by themselves.   Disposal Please dispose of them as general industrial waste.   Warning and danger signs Misbehavior may cause danger. The degree of this is explained by the marking distinction ...

  • Page 10: Precautions For Usage

    1.4. Precautions for Usage 1. When pressing the switch [ON], the foot must 2. Be sure to turn off the power before leaving th leave the pedal. e workplace. 3. Be sure to turn off the power when turning th 4.
  • Page 11 10. Users should avoid touching the screen with sharp objects during use, so as not to cause permane nt damage to the touch screen.

  • Page 12: Main Interface Introduction

    2. Main Interface Introduction 2.1 Main Interface P1 Function Introduction Function Description Display interface name, time; Display bar Long press to trigger language selection. Display the current pattern name and pattern number. Pattern name/number display Display the current pattern; Pattern display Click to display the data related to the current pattern.
  • Page 13 Function Description thread trimming length Job Statistics View piece count settings, startup time, detailed statistics Menu Open multi-category function button Reset button Perform back-to-origin operation Datum button Modify the starting point (function shortcut button, can be reset) Start the frame pressing action (function shortcut button, which can be Frame button reset) Set the Middle presser foot to rise (function shortcut buttons, can be...

  • Page 14: Datum

    2.1.1 Datum （1） Enter the modification/Datum position interface Press the datum button on the main interface P1 to open the reference operation interface, as shown in the figure below. Functions Single-step trial sewing mode: Control the cross cursor to move forward or backward along the pattern stitch by long pressing or single clicking the “...
  • Page 15 Note: It is mainly used to verify whether the border of the pattern is aligned with the mold after the benchmark is completed. Click "Confirm" to save all performed operations and return to the main interface. 8-direction moving speed switch button, click this button one by one to switch the moving speed gear, there are three gears in total.

  • Page 16: Rfid

    If there is no such base point (anchor point), move to the starting point process normally and fine-tune through the direction button. Remarks: If the pattern imported into the operation head has Datum 1 (positioning point), but it will automatically move to the starting point for modification, it is necessary to change the menu=operation setting=other=(RFM) starting point to modify the reference setting=(2H ) secondary origin 2.1.2 RFID RFID settings...
  • Page 17 Turn on template recognition: Find the U11-7 [template identification setting] parameter in the other parameter internal setting interface. Press the drop-down button to select whether the template recognition device is enabled and the template recognition method: 0: Off 1: Barcode Scanning Device 2: RFID, pattern number 3: RFI, pattern name After selecting, press the Confirm button...

  • Page 18: Pattern Preview

    2.1.3 Pattern Preview In the main interface P1, click the pattern display area to display the graphics and basic parameters of the pattern. Or click the preview button in the file management interface to display the graphics and basic parameters of the pattern. In the design preview interface, click the display function code button to display the function...

  • Page 19: Jump

    2.1.4 Jump In the main interface P1, click to enter the interface for setting the specified number of stitches for jumping. There are two options for jumping: Stitch jump: jump to the specified stitch Segment Jump: Jump to the specified segment Select the jump mode, use the numeric button board to input the value, click the jump button to jump to the specified position, click...
  • Page 20 Reverse seam conversion: By selecting a single line segment or the entire graph for closed or non-closed graph operations, modify the starting seam and end reinforcement of the overall pattern. Scaling: Conversion/element expansion and contraction settings, set the length or the number of stitches through the keyboard.

  • Page 21: Main Interface P2 Function Introduction

    2、Scale/Size: It can be adjusted to scale according to size or scale through parameter setting. 3、Scale reference point selection: You can choose to scale the pattern with reference to the graphic center, origin or starting point. Backstitch conversion: 1. Backstitch mode: turn off back stitch, turn on back stitch, and turn on overlapping stitch according to the icon sequence.
  • Page 22 Functions Description Enable/disable winding. Enable/disable winding Note: Middle presser foot will drop after pressing Output signal detection: After pressing the corresponding , the output status of the following button output signals can be detected: Press frame Presser foot Trimming Output signal Dial detection Loose thread...
  • Page 23 Functions Description Press the Main Motor button to enter the Main Motor installation Spindle calibration angle setting mode, display and set the Main Motor installation angle. Set the winding Add or subtract winding speed. speed Enable/disable winding. Enable/disable winding Note: Middle presser foot will drop after pressing Output signal detection: After pressing the corresponding , the output status of the following...

  • Page 24: Installation Angle Setting Of Main Motor

    2.2.1 Installation Angle Setting of Main Motor Press the Main Motor installation angle setting button in the main interface P2 interface to enter the Main Motor installation angle setting function. Remove the Main Motor in the current interface, rotate the handwheel to swing the needle bar of the sewing machine to the highest point, and turn the Main Motor coupling by hand to make the displayed electrical angle value within the range of 30 degrees.
  • Page 25 N. Template in place 1 O. Template in place 2 P. Laser protection switch Q. Oil detection R. Reserve 0~5 S. Top rotation origin T. Lower rotation origin U. Safety switch Press the return button to return to the previous screen. Or in debug detection mode, click the input signal button to enter.

  • Page 26: Menu Function Operation Instructions

    3. Menu Function Operation Instructions 3.1. Pattern Access In the main interface P1, click the menu button →file management button to enter the pattern access interface. [Note] If it is not at the origin, the graphics data cannot be read, please perform the back-to-origin operation first.

  • Page 27: Pattern Sorting

    3.1.1 Pattern Sorting Click the sort button to switch the current sorting method of the patterns. The default sorting method is to display the pattern list according to the modification time. After switching, the pattern list is re-displayed according to the number size, as shown in the left figure.

  • Page 28: Pattern Transmission

    name in the U disk" will be displayed during the operation. Press the Confirm button overwrite the file, and press the Cancel button to exit the current operation. Save the pattern to U disk 3.1.4 Pattern Transmission There are two ways to select patterns: single selection and all selection.
  • Page 29 " " icon to find the pattern placed in the U disk. After selecting the desired pattern, click the “ ” icon to copy the pattern to the system memory. During this period, if there are duplicate names or patterns with duplicate numbers, follow the system prompts to click Confirm (to perform overwriting) or...

  • Page 30: Copy Confirmation

    button to overwrite the pattern in the memory, and click Return to pop up the “save mode”, where the pattern number can be modified. [Note] When performing the above operation when the USB disk is not inserted, the message "USB disk has been unplugged"...

  • Page 31: Pattern Editing

    3.2 Pattern Editing In the main interface P1, click the menu button →pattern editing button to enter the pattern edit interface. Whether to re-enter （1） To replace the entered data with new data, press button (to clear the last printing data and re-print).
  • Page 32 Small stitch shape fusion Confirm input （5） After the above data setting is completed, press the button to complete the setting. Presser foot （6） Press to adjust the rise or fall of the middle presser foot. Needle up and down （7）...

  • Page 33: Pattern Modification

    Function Content Various typing input functions. Typing input [Note] Including sewing of various shapes, empty delivery, various function codes, etc. Arrow buttons Move the frame in all directions. Cancel the last input Press this button to cancel the last confirmed input point and return to the data button previous input point.

  • Page 34: Function Code

    : Send the selected sewing segment to other positions; : Modify the selected position to other sewing methods; : Insert any sewing method in the selected position; : Delete the selected sewing segment; : Modify the stitch length of the selected area;...

  • Page 35: Shape

    3.3.3 Shape Modify the type selection shape when entering this interface. : Move the position of any point in the shape of a section of sewing; : Points selected when generating stitches from graphs such as curves, polylines, rectangles, etc. can be deleted (Note: Shape points cannot be added to shapes that have added inflection point deceleration);...
  • Page 36 Function Content Set the center point datum for the pattern by keeping the number of stitches and stitch Zoom distance unchanged, and scale the X and Y directions by percentage or actual size (setting the modification method in the parameters). Increase The start and end stitch length or the number of stitches can be modified by the decrease...

  • Page 37: System Settings

    state, you can click to restore. Confirm Click Confirm to save all modifications and overwrite the original pattern. 3.5 System Settings In the main interface P1, click the menu button →system setting button to enter the system setting interface. Function Content Software version query Query the system software version.

  • Page 38: Software Version

    3.5.1 Software Version Click the software version button the system setting interface to view the current software version. Press the button to export the software version to the root directory of the U disk, the file name is version.png. 3.5.2 Software Upgrade Click the software upgrade button on the system setting interface to enter the software upgrade mode.

  • Page 39: Format

    Click the software version shortcut button to enter the software version interface. Click the software version shortcut button to enter the interface for selecting the boot screen upgrade. 3.5.3 Format In the system setting interface, click the format button to enter the format mode. Click on the content that needs to be upgraded (white text on a blue background is the selected state), and a confirmation window will pop up whether to...

  • Page 40: Combination Pattern

    3.5.4 Combination Pattern Click the combined pattern button in the system setting interface to enter the combined pattern editing mode. The combined pattern editing mode is mainly used to create and edit combined patterns, that is, to perform combined editing on the basis of existing patterns, and the files that constitute combined patterns are called sub-pattern files.
  • Page 41 Instructions: 1、 Select a subfile Click the button to enter the read mode, select the pattern file you want to add (here, pattern 001 is selected), and press the Confirm button to confirm the selection. [Note] The files to be added in the combined pattern must be added in the sequence.
  • Page 42 4、 Return to the main interface When the editing of the combined pattern is finished, press the Confirm button to return to the main interface. As shown in the figure, there are some differences between the combined pattern sewing interface and the ordinary pattern sewing interface: A.

  • Page 43: Function Shortcut Buttons

    3.5.5 Function shortcut buttons Shortcut button location: The shortcut button function is used to set the five function buttons at the bottom of the main interface P1, and users can set the commonly used function buttons by themselves. Enter shortcut button setting mode: Click the function shortcut button the system setting interface, and you will be asked to enter the manufacturer ID.

  • Page 44: Recovery Backup

    3.5.6 Recovery Backup Click the Restore Backup button the System Settings interface to enter the Restore Backup Parameters interface. Save Parameters Enters the restore backup parameter interface, which is backup user parameters by default. Press the Confirm button after inserting the U disk.

  • Page 45: Parameter Encryption

    3.5.8 Parameter Encryption Parameter Encryption: Click parameter encryption button in the system setting interface, and you will be asked to enter the manufacturer ID. After the input is correct, you can enter the parameter encryption interface to set the decryption item. Change Password: Click the Modify Password button enter the new password setting interface, where you...

  • Page 46: Alarm Record

    Panel Parameters: Function Initial Value Range Automatically turn off the backlight Invalid Efficient Invalid Touch button lock Invalid Efficient Invalid Main interface pattern display 0: black 0: Black setting 1: Cyan 2: Red 3: Green 4: Blue 5: Purple 6: Yellow Voice settings Efficient Efficient...

  • Page 47: Date And Clock Settings

    be cleared to zero. Press the boot time button to record the time of each boot, press the delete button and then press the Confirm button to clear the button record. 3.5.12 Date and Clock Settings Date and Clock Settings: Press the date and time setting button in the auxiliary setting interface, it will ask to enter the manufacturer ID, and the password is correct to enter...
  • Page 48 2) Input Board No. Press the board number button to enter the board number input interface, use the button board to input the board number, and press the Confirm button to complete the input. Note: The board number can be set to 1~10 digits or letters.
  • Page 49 the keyboard to enter the password, and press the Enter button to confirm the input. Note: The password can be set to 1~10 digits or letters. 5) Enter the installment password-1 Press the password-1 button to enter the first phase password setting interface, requiring input of the first valid date.
  • Page 50 6) Enter another installment password The setting of other installment passwords is the same as that of installment password-1. Note: The next valid date must be after the previous valid date 7) Save password After entering the password, press the Confirm button to save.
  • Page 51 9) Actively clear the password Actively clearing the password refers to the setting of automatically clearing the password before the instalment password is issued. A. Press the installment password button in the function setting interface to enter the installment password setting interface. B.

  • Page 52: Work Statistics Function Settings

    information interface. 10) Password attack If the system has set a password, it will encounter a password attack when it is used until the password attack date. If you continue to use it at this time, you must enter a valid password. A.

  • Page 53: User Parameter (U Parameter)

    3.6. User Parameter (U Parameter) 3.6.1 Enter the Function Parameter Setting Interface Press the menu button on the main interface P1 (or P2) interface to open the multi-category directory mode, and then press the user parameter button to enter the user parameter mode selection interface.

  • Page 54: Parameters Modified

    Press the U1-6 parameter button to enter the [Stitches for start and release] parameter setting interface, enter the desired value in the value A through the keypad C, and press the Confirm button to complete the setting change of the corresponding parameter.

  • Page 55: Parameter Customization Method

    [U1-6] button to enter the parameter setting interface, and to reset the parameter value. Press the return button to exit this interface. 3.6.4 Parameter Customization Method Press the menu button on the main interface P1 (or P2) interface to open the multi-category directory mode, and then press the user parameter button to enter the user...
  • Page 56 0:0: Straight line to the end point Multi-stage air feed Multi-stage air U1-2 Select 1:1: Follow the action mode feed action mode segmented path to the end point 0:0: Return to the origin Return to directly Return to location U1-3 Select location when 1:1: Return...
  • Page 57 thread clamping thread 0:0: no reinforcement 1:1:1 Needle Condensation Needle 2:2:V Needle reinforcement U1-16 Select reinforcement reinforcement method method 3:3:N-type reinforcement 4:4:W-shaped reinforcement Number of stitches for Only valid for U1-17 Input starting and V,N,W type reinforcing reinforcement 0:0: no reinforcement 1:1:1 Needle Condensation...
  • Page 58 adjustment Frame Pressing Settings Code Description Details Unit Step Range Type ault 0:0: Pneumatic 1:1: Press frame type Press frame type U2-1 Select Electromagnet selection selection 2:2: Motor Do not sew when 0:OFF: No Do not sew when the U2-2 Select the frame is 0:OFF: Yes...
  • Page 59 right 2:2: The platen goes down first to the right and then to the left Reset Settings Code Description Details Unit Step Range Type ault The pressure The pressure frame is frame is automatically reset automatically 0:OFF: No U3-1 Select 0:OFF: Yes when the power is reset when the...
  • Page 60 Number of Number of stitches for stitches for U4-4 0~255 Input thread catch and thread catch and release release Grab the thread Grab the thread and U4-5 ° 0~359 Input and grasp the grasp the angle angle Thread release U4-6 °...
  • Page 61 0:0: Activate the button or lift the pedal Winder stop mode Winder stop U6-1 1:1: Activate Select setting mode setting button or pedal again 2:2: Timing Timing stop Timing stop winding U6-2 2~498 Input winding time time setting setting Winding speed x100RP U6-3 2~27...
  • Page 62 0:0: close 1:1: dialer type U8-5 Electromagnet Select dialer type selection selection 2:2: Air valve 3:3: Motor 0:0: dial in advance 1:1:Main Motor parking dial 2:2: After the presser foot is raised, the auxiliary presser foot is U8-6 Timing selection Timing selection pulled down Select...
  • Page 63 thread End clip angle when End clip angle U8-14 ° 0~359 Input trimming when trimming Main Motor stop Main Motor stop U8-15 ° 0~160 Input needle and needle and retract retract Automatically Automatically add add trimming 0: OFF: Off U8-16 trimming when Select 1:ON: Open...
  • Page 64 head is raised laser head is raised U10-11 Marker X Offset Marker X Offset x0.1mm -5000~5000 Input U10-12 x0.1mm -2000~2000 Input Marker Y offset Marker Y offset U10-13 marker pen speed marker pen speed mm/min 1000~60000 Input Punching X U10-14 x0.1mm -5000~5000 Input...

  • Page 65: Mechanical Parameters (K Parameters)

    1:1:X priority mode 2:2:Y priority 0:0:XY Simultaneous Air shift mode during Air shift mode U11-9 Select 1:1:X priority work during work 2:2:Y priority Did the Middle Did the Middle presser 0:OFF: No presser foot drop U11-10 Select foot drop during trial 0:OFF: Yes during trial sewing?

  • Page 66: Mechanical Parameter Table

    3.7.2 Mechanical Parameter Table Axis angle Code Description Details Unit Step Range Default Type X feeding K1-1 ° 0~359 Input X feeding start angle start angle X feeding K1-2 ° 0~359 Input X feeding range range Y feeding start K1-3 Y feeding start angle °...
  • Page 67 Set the effective Set the effective range in K2-3 0~5000 Input range in the the right direction of x right direction of x Set the effective Set the effective range in K2-4 0~5000 Input range in the the upper y direction upper y direction Set the...
  • Page 68 1:1: motor control, mechanical follow-up 2:2: electromag net control 3:3: motor control, motor follow-up K4-2 0~359 Input Lift start angle Lift start angle Sustained K4-3 0~250 Input Sustained angle of lift angle of lift Drop start K4-4 0~359 Input Drop start angle angle K4-5 0~250...
  • Page 69 Grip settings Code Description Details Unit Step Range Default Type 0:0: mechanical Type of K6-1 Wire grip type 1:1: Select thread catcher electronics 2:2: motor Pedal settings Code Description Details Unit Step Range Default Type 0:0: digital double pedal K7-1 1:1: digital Select Pedal type...
  • Page 70 deceleration Inflection K8-2 X100rpm 2~30 Input Inflection point speed point speed 1st step speed 1st step speed after K8-3 X100rpm 2~30 Input after inflection inflection point point 2nd step speed 2nd step speed after K8-4 after inflection X100rpm 2~30 Input inflection point point 3rd step speed...
  • Page 71 back the handling shuttle 1:1: put in storage 0:0: shuttle Shuttle arm side Shuttle arm parking K9-5 Select parking 1:1: nose position position side Change the shuttle arm to Change the shuttle arm to the fine K9-6 -100~100 Input the fine adjustment of the adjustment of machine head position the machine...
  • Page 72 sound 2: all: operation panel + alarm sound 0:yes:displ Main interface Main interface pattern K10-11 pattern display Select 1:no:do not display function code function code display Communicati 0:off: no Communication speed K10-12 Select on speed 0:off: yes increase increase Menu item 0:off: no Menu item function K10-13...
  • Page 73 1:1: seams generated by head and tail Graphic center 0:0: Whether the graphics setting when reserved K11-6 Select center keeps the initial the pattern is 1:1: empty feed zoomed and removal rotated Whether the origin of the Whether the origin of the 0:0: no rotation K11-7...
  • Page 74 1:1: from zoom function the starting point 0:0: Return mode function after selection Return method after K11-15 Select modification 1:1: modification (point and continue to function code) modify Multi seam, offset seam, 0:0: segment relative insertion modificati Multi-stitch, offset seam, modification K11-16 Select...
  • Page 75 0:off: yes range point range 0:s1:style1 Curve K11-23 Select Curve punching style punching style 1:s2:style 2 Shape outline 0:off: no Shape outline display K11-24 Select display under under punching 0:off: yes punching For straight lines only, shape points within 1mm 0:off: no K11-25 Small stitch shape fusion...
  • Page 76 Replacing the needle Replace the X1000 K12-2 0~9999 Input setting needle setting pins Cleaning time Cleaning time remaining K12-3 Hour 0~9999 Input remaining value value Cleaning time K12-4 Hour 0~9999 Input Cleaning time set value set value Oil change Oil change remaining K12-5 Hour 0~9999...
  • Page 77 Less than Less than 3000 rpm main 3000 rpm K12-18 0~60000 Input motor laps main motor laps Main motor oil supply Main motor K12-19 100~60000 2000 Input laps oil supply laps Fuel supply K12-20 0~9999 Input Fuel supply duration duration Insufficient oil 0:0: no Insufficient oil detection...

  • Page 78: Debug Detection

    3.8 Debug Detection 3.8.1 Enter Debug Detection Mode Press the menu button on the main interface P1 (or P2) interface to open the multi-category directory mode, and then press the debug detection button to enter the debug detection mode interface. Note: Middle presser foot detection, RFID, thread trimming detection can also be turned on according to the parameter settings.

  • Page 79: Lcd Detection

    3.8.2 LCD Detection Press the LCD detection button the debug detection mode interface to enter the LCD detection function, and the LCD detection is now in automatic mode. Detection status: After entering the LCD screen detection function, the LCD screen will automatically switch in turn according to the colors of white, black, red, green, and blue.

  • Page 80: Speed Detection

    3.8.5 Speed Detection Press speed detection button in the debug detection mode interface to enter the Main Motor speed detection function. Set the target speed of the Main Motor through After pressing the run button , the Main Motor will rotate at the set speed. At this time, the actual measured speed will be displayed in the actual speed input field.

  • Page 81: Continuous Operation

    G. OUT1-11 H. presser foot Middle presser foot Auxiliary presser foot K. Thread releaser/large thread tensioner L. Auxiliary frame M. Brush N. Oil supply valve O. Lower thread cover P. Small thread clamp Q. Laser power supply R. Laser light switch S.

  • Page 82: Xy Origin

    3.8.8 XY Origin Press the XY origin detection button in the debug detection mode interface to enter the XY motor origin detection function. In this interface, the XY motor is driven by the direction buttons to move, and the ON/OFF status of the sensor can be displayed in real time during the process.

  • Page 83: Spindle Calibration

    3.8.9 Spindle calibration Press the Spindle calibration button in the debugging and testing mode interface to enter the Main Motor installation angle setting interface. Or press the spindle shortcut button the main interface P2 to enter the Main Motor installation angle setting interface. For details, see 2.2.1 Main Motor Installation Angle Setting.
  • Page 84 1. Turn off the power and check whether the nose is turned over. 2. Check whether the nose flip switch position is normal and [E-003] whether the cable is in good contact. Nose tip over 3. Turn off the parameters of the nose flip switch or change the electric control Please turn off the power and check the system hardware.
  • Page 85 1. Check whether the disconnected detection equipment is in the correct position. 2. Check the disconnection and check whether the cable is connected properly. Thread interruption during [E-017] 3. Appropriately increase the number of broken wire detection sewing needles. 4. If it is still not solved, you can choose to turn off the disconnection detection function or replace the electronic control.
  • Page 86 the electric control box in turn to test. 1. Turn off the power supply, first make sure that the machine can move the jam-free point normally, that the inductor and baffle of Middle presser foot can work normally, and that the motor of Middle presser foot and the inductor cable are well connected.
  • Page 87 1. Turn off the power, first make sure that the machine can move the jam-free point normally, the corresponding motor inductor and baffle can work normally, and the corresponding motor and inductor cable are well connected. 2. Power on and enter the signal detection interface to detect the corresponding motor inductor.
  • Page 88 1. Turn off the power supply and check whether the Y-axis motor connector is firmly connected and whether the cable is intact and [E-051] undamaged. Y-axis motor overcurrent 2. Replace the Y-axis motor. 3. Replace the electric control box 1. Turn off the power supply and confirm that the mechanical X direction can move the card-free point normally.
  • Page 89 2. Replace the medium voltage foot motor. 3. Replace the electric control Trim motor detection [E-094] Please turn off the power. overcurrent 1. Turn off the power and make sure that the mechanical parts of Middle presser foot can move smoothly without sticking points. 2.
  • Page 90 lower rotation axis origin sensor is correct, whether it is reliable, rotation axis is abnormal and whether the connection line is broken. (exceeds the limit number 2.Please check the lower rotation axis origin sensor for damage. of steps) 3. Please check whether the machinery related to the lower rotation shaft is loose, whether the rotation is smooth, and whether there is blocking.
  • Page 91 4. Please check whether the parameters of the upper rotating shaft motor are configured correctly. 1. Please turn off and check whether the machinery related to the upper rotation shaft is loose, whether the rotation is smooth, and whether there is any blocking. 2.Please check whether the connection plug of the upper rotating shaft motor encoder is correct, whether it is secure, and whether the The upper rotating shaft...
  • Page 92 2.Please check whether the rotary shaft motor encoder cable and the upper and lower power cord are normal and damaged. rotation axes 3. Please check whether the parameters of the rotary shaft motor are configured correctly. 1. Please turn off and check whether the machinery related to the upper spindle is loose, whether the rotation is smooth, and whether there is blocking.
  • Page 93 The nose movements are Please check whether the nose lifting mechanism is normal and [E-136] abnormal! whether the electrical wiring is in good condition. 1. Please check whether the power supply of the automatic shuttle changer module is normal. 2. Please turn off and check whether the relevant circuit is correct, Automatic shuttle change [E-137] whether it is reliable, and whether the connection line is broken.
  • Page 94 1. The Middle presser foot (follow-up) fails to complete the lifting or falling action normally, resulting in a height deviation. Abnormal position of 2. Restore the most recently modified parameters to ensure that the presser foot (follow-up) [E-145] parameters change within the appropriate range. during spindle 3.

  • Page 95: List Of Prompt Information

    4.2 List of Prompt Information Name Sub-Information Content M-001 Up counter reaches maximum value Please press Confirm The down counter reaches the M-002 Please press Confirm maximum value M-003 Not at the origin, unable to operate Please go back to the origin M-004 Pattern data does not exist Please re-read or type out the input...
  • Page 96 Confirm button to execute the operation, cancel button to exit M-029 Factory reset? the operation M-030 USB drive removed The USB drive has been pulled out! M-031 No pattern data found in the U disk None M-032 No alarm record The needle replacement setting value has been reached, please M-033 Replace the needle...
  • Page 97 deleted, please shut down M-061 User ID file corrupted M-062 Enter the pattern name M-063 Input can not be empty Please enter password The current password does not M-064 Please re-enter your current password match M-065 The new password does not match Please re-enter the new password and confirm again Touch screen calibration is The calibration is successful, please turn off the power and...
  • Page 98 current pattern current pattern cannot be overwritten The selected pattern is not a standard file format, please use it M-94 Need to convert pattern format after conversion This operation cannot be performed Please enter the combined pattern function, select to close the M-95 for combined patterns combined pattern, and then press the Confirm button to cancel...
  • Page 99 M-122 Number already taken M-123 Unable to generate stitches M-124 Internal data exception M-125 Arc exists Ellipse will be converted to point seam M-126 Clear production records? Sure? M-127 Check in successfully M-128 Failed to punch The condensed seam has become a point seam, and the M-129 Condensation conversion succeeded condensed seam cannot be converted again.
  • Page 100 master is encrypted Panel encryption, master not M-152 Determining button Sync Encryption Status encrypted Remote staging settings already Confirm button to continue the operation, cancel button to exit M-153 exist in the system the operation The system speed is reduced to the minimum, please contact M-154 Wireless module 1 connection failed the manufacturer...
  • Page 101 Return the stiffness of all stitch M-176 Sure? lengths to the initial value? Confirm: The pattern with the same name will be deleted There is a pattern with the same M-177 name on the panel, please select the Return: automatically modify the name of the pattern, and execution method rename it according to the name + number M-178...

  • Page 102: Attachment 2

    5 Attachment 2 5.1 Operating box installation dimensions...

  • Page 103: Electronic Control Box Installation Size

    5.2 Electronic control box installation size 6P Electronic control box installation size：...
  • Page 104 6P plus Electronic control box installation size：...

  • Page 105: System Diagram

    5.3 System Diagram 6P820-2HB3-B System Diagram：...
  • Page 106 6P821-2HB3-B System Diagram：...
  • Page 107 6P822-2HB2-AR System Diagram：...
  • Page 108 由於對產品的改良及更新，本產品使用說明書中與零件圖之產品及外觀的修改恕不事先通知 ! The specification and/or appearances of the equipment described in this instruction book & parts list are subject to change because of modification which will without previous notice. JSL-24AK02.DEC.2024...
