- Page 1 BXP-A101 Series Quick Installation Guide Embedded Computers Version 1.0, December 2024 Technical Support Contact Information www.moxa.com/support 2024 Moxa Inc. All rights reserved. P/N: 1802001018010 *1802001018010*...
-
Page 2: Package Checklist
Overview The BXP-A101 Series wall-mount computers are powered by an Intel Atom quad-core or dual-core processor. The computers come with a ® rich set of interface options including two software-selectable RS- 232/422/485 serial ports, two gigabit Ethernet ports, four digital inputs, and four digital outputs. -
Page 3: Led Indicators
Dimensions LED Indicators The LED indicators are located on the front panel of BXP-A101 computers. For details of the LED functions, see the following table: LED Name Status Description Power Green Power is on (S5 state) Power is off and the device is in S5 state Ethernet Green Steady on: 10/100 Mbps Ethernet link... -
Page 4: Connecting The Power
The four screws to mount the BXP computer to a wall are not included in the product package. You need to purchase them separately. Refer to the illustration for the screw dimensions. Push the computer downwards to ensure that the device is securely fixed to the mounting surface. -
Page 5: Connecting Displays
NOTE This computer is intended to be supplied by a UL Listed Power Unit “LPS” (or “Limited Power Source”) rated 12 V @ 3.4 A min. or 24 V @ 1.7 A min., and minimum Tma = 70°C. If you need assistance with purchasing a power adapter, contact the Moxa technical support team. -
Page 6: Digital Inputs/Digital Outputs
0 to 24 VDC, Typ. (Source to DI) 30 V Max. Logic 1: +3 V Max. Logic (Source to DI) The wiring method is illustrated in the following diagram: For additional details, refer to BXP-A101 Series Hardware User Manual. - 6 -... -
Page 7: Connecting Usb Devices
Connecting USB Devices The BXP-A101 Series computer comes with 2 USB 3.0 ports on the front panel. The USB ports can be used to connect to peripherals, such as keyboard, mouse, or flash drives for expanding the system’s storage capacity. -
Page 8: Installing The Mini Pcie Card
Installing the Mini PCIe Card The BXP-A101 series computers come with one Mini PCIe socket. Follow these instructions. 1. Unfasten the three screws on the top panel, and another three screws on the rear panel. 2. Remove the rear cover of the computer. - Page 9 WARNING You must purchase the battery from Moxa. Contact the Moxa Technical Support Team before replacing the battery. To reduce the risk of fire or burns, do not disassemble, crush, or puncture the battery; do not dispose of in fire or water and do not short external contacts.
- Page 10 限用物質含有情況標示聲明書- BSMI Declaration of the Presence Condition of the Restricted Substances Marking 型號（型式）: BXP-A101-E4-T, BXP-A101-E2-T (及其型號) 設備名稱: 嵌入式計算機 Equipment name Type designation (Type) 限用物質及其化學符號 Restricted substances and its chemical symbols 單元 Unit 六價鉻 多溴聯苯 多溴二苯醚 鉛 汞 鎘 Hexavalent Polybrominat Polybrominated Lead Mercury...
- Page 11 製造商資訊 Moxa 四零四科技股份有限公司 +886-3-2737575 桃園市八德區和平路 1111 號 產品型號 BXP-A101-E4-T BXP-A101-E2-T - 11 -...
